3. Pin Definitions
Note:
1. Firmware can configure register bits to change the settings of "VDD_SDIO Voltage".
2. Internal pull-up resistor (R1) for IO45 is not populated in the module, as the flash and SRAM in ESP32-S2-WROVER
work at 3.3 V by default (output by VDD_SPI). Please make sure IO45 will not be pulled high when the module is
powered up by external circuit.
3. ROM code can be printed over TXD0 (by default) or DAC_1 (IO17), depending on the eFuse bit.
4. When eFuse UART_PRINT_CONTROL value is:
0, print is normal during boot and not controlled by IO46.
1 and IO46 is 0, print is normal during boot; but if IO46 is 1, print is disabled.
2 and IO46 is 0, print is disabled; but if IO46 is 1, print is normal.
3, print is disabled and not controlled by IO46.
