W480D2I
Z490D2I
User Manual
Version 1.0
Published January 2021
Copyright©2021 ASRock Rack INC. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W480D2I and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK W480D2I

Summary of Contents for ASROCK W480D2I

  • Page 1 W480D2I Z490D2I User Manual Version 1.0 Published January 2021 Copyright©2021 ASRock Rack INC. All rights reserved.
  • Page 2 In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of profits, loss of business, loss of data, interruption of business and the like), even if ASRock Rack has been advised of the possibility of such damages arising from any defect or error in the documentation or product.
  • Page 3 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at www.ASRockRack.com; or you may contact your dealer for further information. ASRock Rack Incorporation 6F., No.37, Sec. 2, Jhongyang S. Rd., Beitou District,...

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installing the CPU Fan and Heatsink Installation of Memory Modules (DIMM) Expansion Slot (PCI Express Slot) Jumper Setup Onboard Headers and Connectors ATX PSU / DC-IN Power Connections...
  • Page 5 Chapter 3 UEFI Setup Utility Introduction 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen OC Tweaker Screen Advanced Screen 3.4.1 CPU Configuration 3.4.2 Chipset Configuration 3.4.3 Storage Configuration 3.4.4 ACPI Configuration 3.4.5 USB Configuration 3.4.6 Super IO Configuration 3.4.7 Serial Port Console Redirection 3.4.8 H/W Monitor 3.4.9 Intel ME Configuration 3.4.10 Instant Flash...
  • Page 6 3.7.3 BMC Tools Event Logs Exit Screen Chapter 4 Software Support Install Operating System Support CD Information 4.2.1 Running The Support CD 4.2.2 Drivers Menu 4.2.3 Utilities Menu 4.2.4 Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 8: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. You may find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com If you require technical support related to this motherboard, please visit our website for specific information about the model you are using.

  • Page 9: Specifications

    1.2 Specifications W480D2I / Z490D2I MB Physical Status Form Factor Mini ITX Dimension 6.7'' x 6.7'' (17.02cm x17.02 cm) Processor System Supports Intel® 11 Gen. Core™ i9/i7/i5/i3, Pentium, Celeron series Socket Single Socket LGA1200 Chipset Intel® W480 / Z490 Thermal Design...
  • Page 10 256Mb AMI UEFI Legal BIOS BIOS Features - Plug and Play (PnP) - ACPI 2.0 Compliance Wake Up Events - SMBIOS 2.8.0 Support - ASRock Rack Instant Flash Hardware Monitor Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing - MB/Card side/TR1 Temperature Sensing...
  • Page 11 Support OS Microsoft® Windows® -Windows 10 (64 bit) Linux® - RedHat Enterprise Linux Server 7.9 (64 bit) / 8.2 (64 bit) - CentOs 7.9 (64 bit) / 8.2 (64 bit) - SUSE Enterprise Linux Server 12 SP5 (64 bit) / 15 SP2 (64 bit) - Ubuntu 19.04 (64 bit) / 20.04.1 (64 bit) Hypervisor - VMWare®...

  • Page 12: Unique Features

    POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to your USB flash drive, floppy disk or hard drive, then you can update your BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 13: Motherboard Layout

    1.4 Motherboard Layout W480D2I / Z490D2I 17.0cm (6.7 in) ATX12V1 ATX4PIN1 DDR4_B1 (64 bit, 288-pin module) DDR4_A1 (64 bit, 288-pin module) W480D2I / M2_1 Z490D2I Super RoHS COM1 LAN1 LAN2 Intel I210 USB 3.2 Gen2 T: USB31_1 B: USB31_2 USB 3.2 Gen1...
  • Page 14 W480D2I / Z490D2I Description ATX 12V Power Connector (ATX12V1) ATX 4-PIN Power Connector (ATX4PIN1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1) Thermal Sensor Header (TR1) PSU SMBus (PSU_SMB1) M.2 Socket (M2_1) (Type 2280) System Fan Connector (FAN1) System Fan Connector (FAN2)

  • Page 15: Onboard Led Indicators

    1.5 Onboard LED Indicators DDR4_B1 (64 bit, 288-pin module) DDR4_A1 (64 bit, 288-pin module) W480D2I / Z490D2I Super RoHS Intel W480/Z490 PLED PWRBTN HDLED RESET CLRMOS1 Item Status Description SB_PWR1 Green STB PWR ready FAN_LED1 Amber FAN1 failed FAN_LED2 Amber...

  • Page 16: I/O Panel

    W480D2I / Z490D2I 1.6 I/O Panel No. Description No. Description VGA Port (VGA1) USB 3.2 Gen1 Ports (USB3_1_2) LAN RJ-45 Port (LAN1)** LAN RJ-45 Port (IPMI_LAN1)* LAN RJ-45 Port (LAN2)** UID Switch (UID1) USB 3.2 Gen2 Ports (USB31_1_2) LAN Port LED Indications *There are two LEDs on each LAN port.
  • Page 17 **There are two LEDs on each LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port ACT/LINK LED SPEED LED LAN Port LED Indications Activity / Link LED Speed LED Status Description Status...

  • Page 18: Block Diagram

    W480D2I / Z490D2I 1.7 Block Diagram W480D2I Channel A DDR4 up to 2933 INTEL Channel B DDR4 up to 2933 Processor PCI-E X16 SLOT 7 PCI-E Gen3 BUS LGA-1200 Pin Socket USB3.1 SuperSpeed USB USB3.1 10 Gb/s HSIO 0-1 2 rear ports Type A...
  • Page 19 Z490D2I Channel A DDR4 up to 2933 INTEL Channel B DDR4 up to 2933 Processor PCI-E X16 SLOT 7 PCI-E Gen3 BUS LGA-1200 Pin Socket USB3.1 SuperSpeed USB USB3.1 10 Gb/s HSIO 0-1 2 rear ports Type A HSIO 14-17 INTEL I210 HSIO 11 (LAN1 NCSI)

  • Page 20: Chapter 2 Installation

    W480D2I / Z490D2I Chapter 2 Installation This is a mini ITX form factor (6.7'' x 6.7'', 17.02 cm x 17.02 cm) motherboard. Before you install the motherboard, study the configuration of your chassis to ensure that the motherboard fits into it.

  • Page 21: Installing The Cpu

    2.3 Installing the CPU 1. Before you insert the 1151-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 22 W480D2I / Z490D2I Please save and replace the cover if the processor is removed. The cover must be placed if you wish to return the motherboard for after service.

  • Page 23: Installing The Cpu Fan And Heatsink

    2.4 Installing the CPU Fan and Heatsink...

  • Page 24: Installation Of Memory Modules (Dimm)

    W480D2I / Z490D2I 2.5 Installation of Memory Modules (DIMM) This motherboard provides two 288-pin DDR4 (Double Data Rate 4) DIMM slots. The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if you force the DIMM into the slot at incorrect orientation.

  • Page 25: Expansion Slot (Pci Express Slot)

    2.6 Expansion Slot (PCI Express Slot) There is a PCI Express slot on this motherboard. PCIE slot: PCIE7 (PCIe 3.0 x16 slot) is used for PCI Express x16 lane width cards. Slot Generation Mechanical Electrical Source PCIE 7 Installing an expansion card Step 1.

  • Page 26: Jumper Setup

    W480D2I / Z490D2I 2.7 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short”...

  • Page 27: Onboard Headers And Connectors

    2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header C onnec t t he power sw itch, PLED+ PLED-...
  • Page 28 W480D2I / Z490D2I USB 3.2 Gen1 Header Dummy Besides two default USB 3.2 IntA_PA_D+ IntA_PB_D+ IntA_PA_D- (19-pin USB3_5_6) Gen1 ports on the I/O panel, IntA_PB_D- IntA_PA_SSTX+ (see p.6, No. 20) there is one USB 3.2 Gen1 IntA_PB_SSTX+ IntA_PA_SSTX- header on this motherboard.
  • Page 29 ATX 4-PIN Power The motherboard provides one Connector 4-pin power/signal connector ATX_PG (4-pin ATX4PIN1 which is a required input for +5VSB PSON# ATX power source. (ATX 24pin-to-4pin) (see p.6, No. 2) When using ATX power, it is necessary to use a 24pin-to- 4pin power cable to connect between the 24pin power connector of PSU and the...
  • Page 30 W480D2I / Z490D2I SPI TPM Header This connector supports SPI (13-pin SPI_TPM_J1) Trusted Platform Module SPI_DQ3 SPI_DQ2 SPI_CS0 SPI_PWR (see p.6, No. 18) (TPM) system, which can Dummy SPI_MISO securely store keys, digital RSMRST# SPI_MOSI certificates, passwords, and RST# SPI_TPM_CS# data.
  • Page 31 Serial Port Header This COM header supports a RRI#1 (9-pin COM1) serial port module. RRTS#1 CCTS# (see p.6, No. 23) DDSR#1 DDTR#1 TTXD1 RRXD1 DDCD#1 Clear CMOS Pad CLRMOS1 allows you to clear (CLRMOS1) the data in CMOS. To clear (see p.6, No.

  • Page 32: Atx Psu / Dc-In Power Connections

    W480D2I / Z490D2I 2.9 ATX PSU / DC-IN Power Connections This motherboard supports both +12V DC and ATX power input. Please refer to the table below for the required connections between the motherboard and the power supply. Connector DC-IN ATX PSU...

  • Page 33: Unit Identification Purpose Led/Switch

    2.10 Unit Identification purpose LED/Switch With the UID button, You are able to locate the server you’re working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be turned on.

  • Page 34: Dual Lan And Teaming Operation Guide

    W480D2I / Z490D2I 2.12 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images.
  • Page 35 2.13 M.2_SSD (NGFF) Module Installation Guide (M2_1) The M.2, also known as the Next Generation Form Factor (NGFF), is a small size and versatile card edge connector that aims to replace mPCIe and mSATA. This M.2_SSD (NGFF) Socket 3 can accommodate a M.2 PCI Express module up to Gen3 x4 (32 Gb/s) only.

  • Page 36: Chapter 3 Uefi Setup Utility

    W480D2I / Z490D2I Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure your system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. You may run the UEFI SETUP UTILITY when you start up the computer.

  • Page 37: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 38: Main Screen

    W480D2I / Z490D2I 3.2 Main Screen Once you enter the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows you to set the system time and date.

  • Page 39: Oc Tweaker Screen

    3.3 OC Tweaker Screen CPU Configuration CPU Ratio The CPU speed is determined by the CPU Ratio multiplied with the BCLK. Increasing the CPU Ratio will increase the internal CPU clock speed without affecting the clock speed of other components. AVX2 Ratio Offset AVX2 Ratio Offset specifies a negative offset from the CPU Ratio for AVX workloads.
  • Page 40 W480D2I / Z490D2I BCLK Frequency The CPU speed is determined by the CPU Ratio multiplied with the BCLK. Increas- ing the BCLK will increase the internal CPU clock speed but also affect the clock speed of other components. BCLK PCIE/DMI Frequency The CPU speed is determined by the CPU Ratio multiplied with the BCLK.
  • Page 41 100MHz Slew Rate Adjust the BCLK signal by defining the maximum change rate of the output voltage. Higher values will result ina shorter signal rising time. CPU PLL ORT Overshoot Reduction Technology improves the BCLK signal to decrease overshoot/ undershoot. Default is Level 3. PCIE PLL ORT Overshoot Reduction Technology improves the BCLK signal to decrease overshoot/ undershoot.
  • Page 42 W480D2I / Z490D2I Intel SpeedStep Technology Intel SpeedStep technology allows processors to switch between multiple frequen- cies and voltage points for better power saving and heat dissipation. Intel Turbo Boost Technology Intel Turbo Boost Technology enables the processor to run above its base operating frequency when the operating system requests the highest performance state.
  • Page 43 ratio will be lowered immediately. A lower limit can protect the CPU and save power, while a higher limit may improve performance. CPU Core Limit Configure the limit of the CPU core. A lower limit can protect the CPU and save power, while a higher limit may improve performance.
  • Page 44 W480D2I / Z490D2I RAS# to CAS# Delay and Row Precharge (tRCDtRP) RAS# to CAS# Delay : The number of clock cycles required between the opening of a row of memory and accessing columns within it. Row Precharge: The number of clock cycles required between the issuing of the precharge command and opening the next row.
  • Page 45 Write to Read Delay (tWTR_S) The number of clocks between the last valid write operation and the next read command to the same internal bank. Read to Precharge (tRTP) The number of clocks that are inserted between a read command to a row pre- charge command to the same rank.
  • Page 46 W480D2I / Z490D2I tRDRD_dd Configure between module read to read delay. tRDWR_sg Configure between module read to write delay. tRDWR_dg Configure between module read to write delay. tRDWR_dr Configure between module read to write delay. tRDWR_dd Configure between module read to write delay.
  • Page 47 tWRWR_dd Configure between module write to write delay. Round Trip Timing Round Trip Timing Optimization Auto is enabled in general case. RTL Init Value Configure round trip latency init value for tround trip latency training. IOL Init Value Configure IO latency init value for IO latency training. RTL (CH A) Configure round trip latency for Channel A.
  • Page 48 W480D2I / Z490D2I ODT WR (A1) Configure the memory on die termination resistors' WR for channel A1. ODT WR (B1) Configure the memory on die termination resistors' WR for channel B1. ODT NOM (A1) Use this to change ODT (CH A1) Auto/Manual settings. The default is [Auto].
  • Page 49 ASRock Timing Optimization Configure the fast path through the MRC. ASRock Second Timing Optimization Configure the second fast path through the MRC. Realtime Memory Timing Configure the realtime memory timings. [Enabled] The system will allow performing realtime memory timing changes after MRC_DONE.
  • Page 50 W480D2I / Z490D2I CPU CORE/Cache Over Current Protection Use this item to configure CPU CORE/Cache Over Current Protection. CPU CORE/Cache Over Voltage Protection Use this item to configure CPU CORE/Cache Over Voltage Protection. CPU CORE/Cache Under Voltage Protection Use this item to configure CPU CORE/Cache Under Current Protection.
  • Page 51 VCCSA Voltage Input voltage for the processor by the external voltage regulator. VCCSA Load-Line Calibration VCCSA Load-Line Calibration helps prevent VCCSA voltage droop when the system is under heavy loading. VCCSA Over Current Protection Use this item to configure VCCSA Over Current Protection. VCCSA Over Voltage Protection Use this item to configure VCCSA Over Voltage Protection.
  • Page 52 W480D2I / Z490D2I GT PLL Voltage Default is 0.900V. Each step is 0.0175V. Adding 9~15 steps will help CPU PLL to lock internal clock during High frequency under Ln2 cooling. For Example: 1.0575V ~ 1.1625V will be proper value. But the voltage level will be different on each processor.

  • Page 53: Advanced Screen

    3.4 Advanced Screen In this section, you may set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, Intel ME Con- figuration, and Instant Flash. Setting wrong values in this section may cause the system to malfunction.

  • Page 54: Cpu Configuration

    W480D2I / Z490D2I 3.4.1 CPU Configuration Intel Hyper Threading Technology Intel Hyper Threading Technology allows multiple threads to run on each core, so that the overall performance on threaded software is improved. Pre-Core Hyper Threading The Per-Core Hyper Threading feature allows you to disable Hyper Threading on specific cores.
  • Page 55 CPU C3 State Support Enable C3 deep sleep state for lower power consumption. CPU C6 State Support Enable C6 deep sleep state for lower power consumption. CPU C7 State Support Enable C7 deep sleep state for lower power consumption. Package C State Support Enable CPU, PCIe, Memory, Graphics C State Support for power saving.

  • Page 56: Chipset Configuration

    W480D2I / Z490D2I 3.4.2 Chipset Configuration Above 4G Decoding Enable or disable 64bit capable Devices to be decoded in Above 4G Address Space (only if the system supports 64 bit PCI decoding). Primary Graphics Adapter If PCI Express graphics card is installed on the motherboard, you may use this option to select PCI Express or Onboard as the primary graphics adapter.
  • Page 57 Onboard LAN I219 Use this to enable or disable the Onboard LAN2 function. The default value is [Auto]. Onboard HDMI HD Audio Enable audio for the onboard digital outputs. Front Panel Enable/disable front panel HD audio. VT-d Intel® Virtualization Technology for Directed I/O helps your virtual machine monitor better utilize hardware by improving application compatibility and reliability, and providing additional levels of manageability, security, isolation, and I/O performance.
  • Page 58 W480D2I / Z490D2I AC/power resumes and the system starts to boot up when the power recovers. If [Last State] is selected, it will recover to the state before AC/power loss. Restore AC Power Current State This allows you to restore AC Power Current State.

  • Page 59: Storage Configuration

    3.4.3 Storage Configuration SATA Controller(s) Use this item to enable or disable SATA Controllers. SATA/M.2_SATA Mode Selection Identify the SATA/M.2_SATA port is connected to Solid State Drive or Hard Disk Drive. Press <Ctrl+I> to enter RAID ROM during UEFI POST process. Support Aggressive Link Power Management Use this item to enable or disable SALP.

  • Page 60: Acpi Configuration

    W480D2I / Z490D2I 3.4.4 ACPI Configuration Suspend to RAM Select disable for ACPI suspend type S1. It is recommended to select auto for ACPI S3 power saving. PCIE Devices Power On Use this item to enable or disable PCIE devices to turn on the system from the power-soft- off mode.

  • Page 61: Usb Configuration

    3.4.5 USB Configuration Legacy USB Support Use this option to enable or disable legacy support for USB devices. The default value is [Enabled].

  • Page 62: Super Io Configuration

    W480D2I / Z490D2I 3.4.6 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the onboard serial port. Change Settings Use this item to select an optimal setting for Super IO device.

  • Page 63: Serial Port Console Redirection

    3.4.7 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, you can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how your computer and the host computer to which you are connected exchange information.
  • Page 64 W480D2I / Z490D2I Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [57600] and [115200].
  • Page 65 Redirect After POST When Bootloader is selected, then Legacy Console Redirection is disabled before booting to legacy OS. When Always Enable is selected, then Legacy Console Redirection is enabled for legacy OS. Default setting for this option is set to Always Enable. Serial Port for Out-of-Band Management/Windows Emergency Management Services (EMS) Console Redirection EMS...

  • Page 66: H/W Monitor

    W480D2I / Z490D2I 3.4.8 H/W Monitor In this section, it allows you to monitor the status of the hardware on your system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 67: Intel Me Configuration

    3.4.9 Intel ME Configuration Intel ME Information screen displays the Intel ME Configuration information, suchas Operational Firmware Version and Firmware State.

  • Page 68: Instant Flash

    W480D2I / Z490D2I 3.4.10 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows you to update system UEFI without entering operating systems ® first like MS-DOS or Windows . Just save the new UEFI file to your USB flash drive,...

  • Page 69: Security

    3.5 Security In this section, you may set or change the supervisor/user password for the system. For the user password, you may also clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 70: Key Management

    W480D2I / Z490D2I 3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Install factory default Secure Boot keys after the platform reset and while the System is in Setup mode.
  • Page 71 Remove ‘UEFI CA’ from DB Device Guard ready system must not list ‘Microsoft UEFI CA’ Certificate in Autho Restore DB defaults Restore DB variable to factory defaults. Platform Key(PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin)
  • Page 72 W480D2I / Z490D2I 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed Forbidden Signatures Enroll Factory Defaults or load certificates from a file: 1.
  • Page 73 OsRecovery Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, External, Mixed...

  • Page 74: Boot Screen

    W480D2I / Z490D2I 3.6 Boot Screen In this section, it will display the available devices on your system for you to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order.
  • Page 75 Setup Prompt Timeout This shows the number of seconds to wait for setup activation key. 65535(0XFFFF) means indefinite waiting. Bootup Num-Lock If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up. Full Screen Logo Use this item to enable or disable OEM Logo.

  • Page 76: Csm Parameters

    W480D2I / Z490D2I 3.6.1 CSM Parameters Enable to launch the Compatibility Support Module. Please do not disable unless you’re running a WHCK test. If you are using Windows 8.1 64-bit and all of your devices support UEFI, you may also disable CSM for faster boot speed.
  • Page 77 OCU1 Slot OpROM This option controls Legacy/UEFI ROMs priority. OCU2 Slot OpROM This option controls Legacy/UEFI ROMs priority.

  • Page 78: Server Mgmt

    W480D2I / Z490D2I 3.7 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC...

  • Page 79: System Event Log

    3.7.1 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 80: Bmc Network Configuration

    W480D2I / Z490D2I 3.7.2 BMC Network Configuration Lan Channel (Failover) IPMI(eth0) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No].
  • Page 81 The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/ipmi.asp VLAN Enabled/Disabled Virtual Local Area Network.
  • Page 82 W480D2I / Z490D2I VLAN VLAN Enabled/Disabled Virtual Local Area Network. LAN Channel 1 / LAN Channel 2 IPV6 Support Enable or Disable LAN1 IPV6 Support. Manual Setting IPMI LAN(IPV6) Use this item to enable or disable PCIe Device Degrade Error Logging Support.

  • Page 83: Bmc Tools

    3.7.3 BMC Tools Load BMC Default Settings Use this item to load BMC default settings. KCS control Select the KSC interface state after POST end. If [Enabled] is selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage.

  • Page 84: Event Logs

    W480D2I / Z490D2I 3.8 Event Logs Change Smbios Event Log Settings This allows you to configure the Smbios Event Log Settings. When entering the item, you will see the followings: Smbios Event Log Use this item to enable or disable all features of the SMBIOS Event Logging during system boot.

  • Page 85: Exit Screen

    3.9 Exit Screen Save Changes and Exit When you select this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When you select this option, the following message “Discard changes and exit setup?”...

  • Page 86: Chapter 4 Software Support

    4.2.4 Contact Information If you need to contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or you may contact your...

  • Page 87: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot your system. Always unplug the power cord before adding, removing or changing any hardware com- ponents. Failure to do so may cause physical injuries to you and damages to motherboard components.
  • Page 88 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether your power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to your problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 89: Technical Support Procedures

    5.2 Technical Support Procedures If you have tried the troubleshooting procedures mentioned above and the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Your contact information 2. Model name, BIOS version and problem type.
