Model No. 831.297670
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
CAUTION
Read all precautions and in-
structions in this manual before
using this equipment. Save this
USER'S MANUAL
manual for future reference.
SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PRO-FORM 585 and is the answer not in the manual?

Questions and answers

Related Manuals for Sears PRO-FORM 585

Summary of Contents for Sears PRO-FORM 585

  • Page 1 Write the serial number in the space above for future reference. Serial Number Decal CAUTION Read all precautions and in- structions in this manual before using this equipment. Save this USER'S MANUAL manual for future reference. SEARS, ROEBUCK AND CO., HOFFMAN ESTATES, IL 60179...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............2 BEFORE YOU BEGIN .
  • Page 3 35 or persons with pre-existing health problems. Read all instructions before using. SEARS assumes no responsibility for personal injury or property damage sustained by or through the use of this product.

  • Page 4: Before You Begin

    BEFORE YOU BEGIN Thank you for selecting the innovative PROFORM ¨ until 7 p.m. Central Time (excluding holidays). To help 585 treadmill. The 585 treadmill blends advanced us assist you, please note the product model number technology with innovative design to let you enjoy an and serial number before calling.

  • Page 5: Assembly

    ASSEMBLY Assembly requires two people. Set the treadmill in a cleared area and remove the packing materials. Do not dispose of the packing materials until assembly is completed. Assembly requires the included allen wrench , and your own adjustable wrench , and a phillips screwdriver 1.
  • Page 6 4. See HOW TO LOWER THE TREADMILL FOR USE on page 11. Follow the instructions on page 11 to lower the treadmill. Align the hole in the lower end of the right Handrail Arm (10) with the hole in the frame tab as shown. Attach the Handrail Arm with a Handrail Bolt (7) and a Handrail Nut (8).

  • Page 7: Operation And Adjustment

    OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT This product is for use on a nominal 120-volt circuit, and has a grounding plug that looks like the plug illus- Your treadmill features a walking belt coated with trated in drawing 1 below. A temporary adapter that PERFORMANT LUBE , a high-performance lubricant.
  • Page 8 DIAGRAM OF THE CONSOLE Monitor Displays LED Track Incline Control Speed Control Clip Pulse Sensor CAUTION: Before operating the ¥ Adjust the speed in small increments. console, read the following precautions. ¥ The settings marked above the speed control (warm-up/cool-down, fat burn, aerobic, and ¥...
  • Page 9 Follow your progress with the LED track and To reset the displays, the four displays. press the START/ RESET button. The dis- The LED plays will darken for a TrackÑThe LED moment and then light. track represents a distance of 1/4 Measure your pulse, if desired.

  • Page 10: How To Fold And Move The Treadmill

    HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Before folding the treadmill, adjust the incline to the lowest position. If the incline is not at the lowest position, the treadmill will be permanently damaged. Next, unplug the power cord. Caution: You must be able to safely lift 45 pounds (20 kg) in order to raise, lower, or move the treadmill.
  • Page 11 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left thumb, slide open the storage latch and hold it open. Pivot the treadmill until the frame is past the storage latch.

  • Page 12: Maintenance And Trouble-Shooting

    MAINTENANCE AND TROUBLE-SHOOTING For your convenience, a maintenance kit is included with this treadmill. Read and follow the instructions included with the maintenance kit to keep your treadmill in top condition. Most treadmill problems can be solved by following the simple steps below.
  • Page 13 PROBLEM: The walking belt is off-center or slips when walked on SOLUTION: a. If the walking belt has shifted to the left, first re- move the key and UNPLUG THE POWER CORD. Using the allen wrench, turn the left rear roller adjust- ment bolt clockwise, and the right bolt counterclock- wise, 1/4 of a turn each.

  • Page 14: Conditioning Guidelines

    CONDITIONING GUIDELINES adjust the speed and incline of the treadmill until your heart rate is near one of the lower two numbers in your WARNING: Before beginning training zone. It may also be helpful to set the speed this or any exercise program, consult your control on the console to FAT BURN to help you main- physician.

  • Page 15: Part List

    PART LISTÑModel No. 831.297670 R0598A To identify the parts listed below, refer to the EXPLODED DRAWING attached in the center of this manual. No. Qty. Description No. Qty. Description No. Qty. Description Frame Belly Pan 8Ó Cable Tie Rear Isolator Handrail Washer Cable Tie Clamp Rear Platform Screw...

  • Page 18: Full 90 Day Warranty

    SEARS TREADMILL EXERCISER, contact the nearest SEARS Service Center throughout the United States and SEARS will repair or replace the TREADMILL EXERCISER, free of charge. This warranty does not apply when the TREADMILL EXERCISER is used commercially or for rental pur- poses.

This manual is also suitable for:

831.297670
