Cooper Lighting GPF15SPW764 Specification Sheet

F L O O D L I G H T I N G
GPF GENERAL PURPOSE FLOOD
S L I P F I T T E R , Y O K E , O R T R U N N I O N - M O U N T E D F L O O D L I G H T
STREETWORKS ™
L AT C H E S O R D E R I N G I N F O R M AT I O N
Formed aluminum flush
S A M P L E N U M B E R
draw-action latches offer easy
access to lamp compartment
PRODUCT
without tools.
FAMILY
GPF=General
H O U S I N G
Purpose
Aerodynamically designed,
Flood
architecturally styled die-cast
aluminum housing. Standard dark
bronze polyester powder finish.
Other finish colors available.
Consult your Streetworks
Representative. ANSI
wattage/source label. Optional
NEMA twistlock photocontrol
receptacle.
O P T I O N S + A C C E S S O R I E S
D O O R
Spring-loaded die-cast aluminum
OPTIONS (add as suffix)
door with integral cast hinges for
1=Single Fuse, Internally Mounted (120 or 277V)
removal without tools. Door gasket
2=Double Fuse, Internally Mounted (208, 240, or 480V)
is closed-cell silicone, providing
4=Photocontrol Receptacle
maximum protection of interior
BK=Black
components from the elements.
AP=Grey
A=Captive Door Screws
L E N S
C=Slipfitter 2 3/8" to 3" O.D.—cord thru housing
Heat- and impact-resistant
H=Plug-in Starter Receptacle
tempered glass lens.
M=MOV Lightning Surge Protectors
R=Removable Power Tray
R E F L E C T O R
S=Slipfitter 2 3/8" to 3" O.D. with leads thru fitter
Computer designed precision
T=Trunnion Mount
formed reflector system delivers
U=UL/CSA Listed
superior beam control and
W=Wall Mount
efficiency.
B A L L A S T
O P T I O N A L C O L O R S
Ballast components are hard
mounted to fixture housing for
maximum heat dissipation and
extended component and lamp life.
Plastic terminal block. Prewired
BK
with 3' 14/3 STWA cord.
Black
M O U N T I N G
Heavy-duty steel yoke provides flex-
ibility in mounting to a variety of
surfaces. Slipfitter for 2 3/8" to 3"
O.D. tenon and trunnion mount also
available.
E P A :
Effective Projective Area: 2.7
S H I P P I N G D ATA
NOTE: 1 Refer to technical section for lamp/ballast/voltage compatibility. 2 250/400W, 400/250W MH, HPS, and 400W MH only. 3 1000W only. 4 Available in MH only. 1000W requires reduced envelope lamp. 5 Available in HPS
Approximate Net Weight:
only. 6 Not available in 1000W. 7 MOV option is not available for any system requiring a three position terminal block (Example—120/240V incoming line). In order for MOV option to function center terminal of three position
59 lbs. (27 kgs.)
terminal block must be connected to "Earth" ground. 8 400W or below, except for 400W Mag. Reg.
142 S T R E E T W O R K S O u t d o o r L i g h t i n g S o l u t i o n s
Fixture
Yoke
S
Trunnion
Slipfitter
NOTE: Depth Dimension: 150-400W HPS and MH, 1000W HPS 9 1/2" [241]. 1000W MH 10 1/2" [267].
: G P F 1 5 S P W 7 6 4
LAMP WATTAGE LAMP TYPE 1
15=150W S=High Pressure
20=200W Sodium
25=250W V=Mercury
40=400W M=Metal Halide
75=750W R=Super Metal Halide
91=1000W
24=250/400
wired 250W
42=400/250
wired 400W
[ M u s t b e l i s t e d i n t h e o r d e r s h o w n a n d s e p a r a t e d b y a d a s h ]
6
7
8
[ S t a n d a r d c o l o r i s b r o n z e , o t h e r f i n i s h c o l o r s a v a i l a b l e . C o n s u l t y o u r C o o p e r L i g h t i n g r e p r e s e n t a t i v e ]
AP
Grey
B
C
D
A
Y O K E M O U N T T R U N N I O N M O U N T
A B
(in.) 20 1/2 18 1/2
(mm) 521 470
(in.) 20 1/2 18 1/2
(mm) 521 470
(in.) 20 1/2 18 1/2
(mm) 521 470
BALLAST TYPE 1 VOLTAGE
H=Reac./HPF 2=120V
N=Hi. Reac./NPF 0=208V
P=Hi. Reac./HPF 4=240V
R=Reac./NPF 7=277V
W=CWA 8=480V
C=CWI 9=347V
M=Mag. Reg. W=Multi-Tap wired 120V
K=10KV CWA N=Multi-Tap wired 277V
5T=5-Tap wired 277V
ACCESSORIES (order separately)
OA1179=Top/Bottom Visor
OA1180=Side Visor
OA1181=Wire Guard
OA1182=Vandal Shield
OA1208=TufGuard Vandal Shield
VS/NK=Vandal Shield (For Wattages Below 1000W)
VS/NK/1000=Vandal Shield (For 1000W Units)
150-1000W MH/HPS/MERCURY
B
C
D
E
A
A
S L I P F I T T E R M O U N T
C D
22 1/2 4
572 102
24 3/8 2 9/16
619 65
28 1/32 5 3/16
712 132
1 DISTRIBUTION
76=7x6
77=7x7 3
12=1x2 4
23=2x3 4
24=2x4 5
43=4x3 4
44=4x4 5
55=5x5 5
2 62=6x2 4
65=6x5 4
C o o p e r L i g h t i n g
B
C
D
E
E
3 5/16
84
4 11/32
110
OPTIONS +
ACCESSORIES
(See Below)
