M-system R7I4DML3-DC32A Instruction Manual page 3

• e-CON connector
Recommended cable connector: 37104-( )-000FL (3M Company)
(The cable connector is not included in the package.
Specify wire size instead of ( ); refer to the specifications of the product.)
Y0 Y1
Y10 Y11
PIN
ID FUNCTION
No.
Y0 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y0 Output 0
Y1 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y1 Output 1
Y2 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y2 Output 2
Y3 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y3 Output 3
Y4 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y4 Output 4
Y5 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y5 Output 5
Y6 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y6 Output 6
Y7 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y7 Output 7
Y2 Y3 Y4 Y5 Y6
Y12 Y13 Y14 Y15 Y16
PIN
ID FUNCTION
No.
Y8 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y8 Output 8
Y9 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 Y9 Output 9
YA 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YA Output 10
YB 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YB Output 11
YC 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YC Output 12
YD 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YD Output 13
YE 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YE Output 14
YF 1 +24V 24V DC
2 NC Unused
3 NC Unused
4 YF Output 15
5-2-55, Minamitsumori, Nishinari-ku, Osaka 557-0063 JAPAN
Phone: +81(6)6659-8201 Fax: +81(6)6659-8510 E-mail: info@m-system.co.jp
Y7 Y8 Y9 YA YB YC
Y17 Y18 Y19 Y1A Y1B Y1C Y1D Y1E Y1F
PIN
ID FUNCTION
No.
Y10 1 +24V
2 NC
3 NC
4 Y10
Y11 1 +24V
2 NC
3 NC
4 Y11
Y12 1 +24V
2 NC
3 NC
4 Y12
Y13 1 +24V
2 NC
3 NC
4 Y13
Y14 1 +24V
2 NC
3 NC
4 Y14
Y15 1 +24V
2 NC
3 NC
4 Y15
Y16 1 +24V
2 NC
3 NC
4 Y16
Y17 1 +24V
2 NC
3 NC
4 Y17
R7I4DML3-DC32A
YD YE YF
1
4
1
4
PIN
ID
No.
24V DC Y18 1 +24V
Unused 2 NC
Unused 3 NC
Output 16 4 Y18
24V DC Y19 1 +24V
Unused 2 NC
Unused 3 NC
Output 17 4 Y19
24V DC Y1A 1 +24V
Unused 2 NC
Unused 3 NC
Output 18 4 Y1A
24V DC Y1B 1 +24V
Unused 2 NC
Unused 3 NC
Output 19 4 Y1B
24V DC Y1C 1 +24V
Unused 2 NC
Unused 3 NC
Output 20 4 Y1C
24V DC Y1D 1 +24V
Unused 2 NC
Unused 3 NC
Output 21 4 Y1D
24V DC Y1E 1 +24V
Unused 2 NC
Unused 3 NC
Output 22 4 Y1E
24V DC Y1F 1 +24V
Unused 2 NC
Unused 3 NC
Output 23 4 Y1F
EM-8008-C P. 3 / 12
FUNCTION
24V DC
Unused
Unused
Output 24
24V DC
Unused
Unused
Output 25
24V DC
Unused
Unused
Output 26
24V DC
Unused
Unused
Output 27
24V DC
Unused
Unused
Output 28
24V DC
Unused
Unused
Output 29
24V DC
Unused
Unused
Output 30
24V DC
Unused
Unused
Output 31
