Room Thermostat
• "6. ROOM THERMOSTAT" menu information.
The "6. ROOM THERMOSTAT" menu is used if the room thermostat is available.
• How to set the "6. ROOM THERMOSTAT" menu.
Go to > FOR SERVICEMAN > 6. ROOM THERMOSTAT.
Press . The following page will be displayed:
ROOM THERMOSTAT = NON,no room thermostat.
ROOM THERMOSTAT = MODE SET, wiring of the room thermostat must follow method A.
ROOM THERMOSTAT = ONE ZONE, wiring of the room thermostat must follow method B.
ROOM THERMOSTAT = DOUBLE ZONE, wiring of the room thermostat must follow method C.
(see chapter 9.7 Par. "For room thermostat:).
Other Heating Source.
"7. OTHER HEATING SOURCE" is used to set the parameters of the indoor unit backup heater (IBH).
Go to > FOR SERVICEMAN > 7. OTHER HEATING SOURCE.
Press . The following pages will be displayed:
7. OTHER HEATING SOURCE
7.1 dT1_IBH_ON
7.2 t_IBH_DELAY
7.3 T4_IBH_ON
7.4 dT1_AHS_ON
7.5 t_AHS_DELAY
ADJUST
90
6. ROOM THERMOSTAT
