TRIO PACK
Instructions and warnings
IE
Installer
ELECTRIC
User
Maintenance technician
4 - 6 - 9
Heat pump consisting of:
- indoor unit
UI TPE
- outdoor condensing unit
AUDAX PRO 4 - 6 - 9 V2
