Samsung SCC-B9371 Specifications

SCC-B9371
1/3" High Resolution, Day/Night, Vari-Focal, Weather
Resistant, Bullet IR Camera
Dimensions (unit : in)
Front/Rear Panel
2.87
3.36 4.8
Summary
The SCC-B9371 Vari-Focal bullet camera with infrared illuminators is the
perfect choice for installations where night lighting is very low or does not
exist at all. The 36 LEDs provide powerful illumination that have a range of
up to 75 feet to light up the night and maintain a clear sharp picture.
The camera comes equipped with a 3.8 ~ 9.5mm Vari-Focal DC auto iris
lens and a mounting bracket.
The externally adjustable variable focal length and focus functions of the
camera make the installation more fast and convenient. The camera is IP66
rated for weather resistance that allows it to be used for both indoor and
outdoor applications.
Features
• 1/3 Inch Super HAD CCD
• 540TV Lines (Color) / 570TV Lines (B/W) Resolution
• Minimum Scene Illumination: 0.4 Lux Color/ 0 Lux B/W @ 15IRE, (F1.2)
• 3.8~9.5mm Vari-Focal, DC Auto Iris Lens
• Color & B/W Auto Switchable By Photocell and Sensitivity
• Externally Adjustable Focal Length & Focus By Side Screws
• Externally Adjustable DC Iris Level
• 36 IR LED with CDS Photocell Auto Switch
• 55~75ft range effective IR illumination
• Weather Resistant (IP66)
• AC24V/DC12V

Recommended Accessories

GV-TRAN-24-40LED, 24VAC, 40VA, Class II plug in transformer
*See accessories page for more options
SAMSUNG | GVI Security • Toll Free: 888-595-2288 • Fax: 972-245-7333
This product specifications and manual are also available in pdf format at www.gviss.com
The information is subject to change without notice • v2.6.09
Day/Night Function
The Day/Night function automatically switches to color mode during the day and to
black and white mode during the night depending on the level of illumination which
makes it ideally suitable for 24/7 surveillance.
Day Night
Weather Resistant (IP66)
The SCC-B9371 is suited for external installation, thanks to its special structure that
resists water and dust

Specifications

Camera Type Color/BW
Image Device
Size
Pixels – Effective
Scanning System
Min. Scene Illumination Color
B/W
Shutter speed
Functions AGC
IR
CDS
Lens Size
Resolution Horizontal
Video Output VBS 1.0Vp-p
S/N Ratio S/N Ratio
Environmental Conditions Operating Temperature
Power Power Requirement
Power Consumption
Physical Specification Dimensions (øxL)
Weight
Bullet IR Camera
Super HAD Sony CCD
1/3"
768 (H) x 492 (V)-380K Pixels
525 lines, 2:1 Interlace
0.4 Lux @ 15IRE (F1.2)
1.3 Lux @ 50IRE (F1.2)
0 Lux @ 15IRE (F1.2)
0 Lux @ 50IRE (F1.2)
1/60 sec
Built In
36
Photocell Auto Switch
3.8~9.5mmVarifocal, DC Auto
Iris F1.2
540(Color) / 570(B/W) TVL
VBS 1.0Vp-p (75 Ohm Load)
Greater Than 48dB (AGC off)
-10˚ ~ 50˚C (14˚ ~ 122˚F)
12VDC/ AC24V
AC24V 2.5VA~7.2VA max./
IR LED On
12VDC 240mA~600mA max/
IR LED On
2.87 x 4.80 in / 73 x 122 mm
3.2 Ib / 1.45 kg
GVI Security
