OSD Menu_Motion
The camera can detect movement and display an alarm on the screen when movement is detected.
1
2
3
DET WINDOW
SENSITIVITY
MOTION OSD
TEXT ALARM
SIGNAL OUT
RETURN
DET window
1
- Window use: Select which one of the motion areas to enable.
- Window zone: The camera supports up to 4 different masks. Select which ones to display.
- DET H-POS:
- DET V-POS:
- DET H-Size:
- DET V-Size:
Sensitivity
2
The smaller the movement you want to detect, the higher the sensitivity value must be.
Motion OSD
3
Enable or disable showing the motion detection on the camera's OSD.
MOTION
MOTI
5
OFF
OFF
ON
Move the zone's position left or right. The higher the number,
the zone will move to the right.
Move the zone's position up or down. The higher the number,
the zone will move down.
Adjust the zone's width. The higher the number, the right-side
panel of the zone will move further to the right.
Adjust the zone's height. The higher the number, the bottom
side panel of the zone will move further down.
24
DET WINDOW
WINDOW USE
0
WINDOW ZONE
ON
DET H-POS
1
DET V-POS
1
DET H-SIZE
77
DET V-SIZE
58
RETURN
