- Page 2 1. In the event that your gazebo needs replacement parts, repairs or you require assistance with regards to assembly; please contact our customer sales team by email info@royalcraft.co.uk 2. For cleaning: Use a mild domestic soap or soft detergent and wash with warm water using a sponge or microfibre fabric.
- Page 3 - 3 -...
- Page 4 STEP ONE: BOLTS NEEDED: H1 CONNECT PART A TO PART U STEP TWO: BOLTS NEEDED: H 2A. SLIDE 6 PART O INTO PARTS A1, A2, B1 AND B2 2B. CONNECT PART A1 WITH PART K 2C. CONNECT PART B1 WITH PART K - 4 -...
- Page 5 STEP THREE: BOLTS NEEDED: H, H1, H2, H3 3A. CONNECT A1 TO B2 USING LEG A, PLACE YOUR J1 CORNER BRACKET OVER ALL PARTS AND SECURE USING H3 (AS PER DIAGRAM) 3B. CONNECT A2 TO B1 USING LEG A, PLACE YOUR J1 CORNER BRACKET OVER ALL PARTS AND SECURE USING H3 (AS PER DIAGRAM) 3C.
- Page 6 STEP FOUR: BOLTS NEEDED: H1 4A. CONNECT PART I TO PART C 4B. CONNECT PART G TO PART B 4C. CONNECT ALL PARTS B AND C TO PART F AND E (F IS TOP E IS BOTTOM AS PER DIAGRAM) STEP FIVE: CONNECT YOUR BUILT ROOF SECTION TO YOUR BUILT FRAME SECTION USING H1 BOLTS (AS PER DIAGRAM BELOW)
- Page 7 STEP SIX: BOLTS NEEDED: H3, H4 SECTIONS 6A – 6C 3.6M SIDE 6A. SLIDE PANEL 1 THEN PART C1 THEN PANEL 3 INTO YOUR FRAME AND CLOSE OFF WITH PART D2 (LEFT SIDE) 6B. SLIDE PANEL 5, THEN C2 AND THEN PANEL 6 INTO THE MIDDLE SECTION AND CLOSE OFF WITH PART D 6C.
- Page 8 STEP SEVEN: 7A. SLIDE PART X INTO THE INSIDE TRACK 7B. SLIDE PART W INTO THE OUTSIDE TRACK 7C. SECURE YOUR FRAME INTO THE GROUND USING PART Y (ONLY AVAILABLE FOR GRASS) IF YOU WISH TO SECURE TO CONCRETE YOU WILL NEED TO PURCHASE BOLTS FOR THIS.
