- Page 2 1. In the event that your gazebo needs replacement parts, repairs or you require assistance with regards to assembly; please contact our customer sales team by email info@royalcraft.co.uk 2. For cleaning: Use a mild domestic soap or soft detergent and wash with warm water using a sponge or microfibre fabric.
- Page 3 - 3 -...
- Page 4 STEP ONE: 1A. CONNECT PART 2 x PART A IN THE MIDDLE USING H2 BOLTS. 1B. CONNECT PART C UNDERNEATH YOUR TWO PART A’S USING H5 BOLTS STEP TWO: CONNECT PART J TO PART A USING PART L AND H6 BOLTS (AS PER DIAGRAM BELOW) - 4 -...
- Page 5 STEP THREE: CONNECT ALL PARTS A TO PARTS A1 USING H BOLTS STEP FOUR & FIVE: 4. CONNECT PARTS B1 TO B2 WITH PART K USING H1 BOLTS (AS PER DIAGRAM) 5A. CONNECT PART G TO ALL PARTS B2 5B. CONNECT PART I TO ALL PARTS D 5C.
- Page 6 STEP SIX: CONNECT YOUR BUILT ROOF SECTION TO THE TOP OF YOUR BUILT FRAME USING H1 BOLTS STEP SEVEN (1&2): 7-1A. SLIDE PANEL ONE INTO YOUR FRAME FOLLOWED BY PART C1, PANEL 3 AND PART D2 (AS PER DIAGRAM) 7-1B. SLIDE PANEL TWO INTO YOUR FRAME FOLLOWED BY PART C1, PANEL 3 AND PART D1 (AS PER DIAGRAM) THEN SECURE ALL PARTS WITH H4 BOLT 7-2.
- Page 7 STEP EIGHT & NINE: 8. CONNECT PART A2 WITH PART B USING H1 BOLTS 9. LIFT YOUR BUILT TOP FRAME (USING MIN 4 PEOPLE) ONTO YOUR A2 (B) AND SECURE THE JOIN WITH H4 BOLTS - 7 -...
- Page 8 STEP TEN: HOOK PARTS W ONTO PART J USING PART O (AS PER BELOW DIAGRAM) AND THEN SECURE YOUR FRAME TO THE GROUND USING PART Y (ONLY APPLICABLE FOR GRASS) - 8 -...
