restart the oscilloscope.
(Unless you confirm that the oscilloscope does have a large zero offset,
calibration is generally not recommended)
After the FFT option is turned on, it can perform FFT calculation on the screen
waveform and display the waveform after FFT. FFT display mode can be selected as:
"logarithmic", linear and "music" (music spectrum).
In this menu, long press the ↑ button to enter the overclocking mode (for
measuring 100M-120M signal), and press ↓ to return to the normal mode.

7.6 Settings

1. In this menu, you can set whether to shut down automatically. If you choose
to shut down automatically, the oscilloscope will automatically shut down 15
minutes after no button operation.
2. You can choose whether to turn on the sound.
3. Language selection: Chinese or English.
4. In this menu, long press the "ns" button to enter the usb connection state,
long press "s" to change the background color of the measure.
Parameters
Model
Channels
Screen size
Resolution
Bandwidth
Sampling rate
Rise time
Storage depth
Impedance
Time base
Ver sensitivity
Max voltae
Trigger mode
Trigger type
Display mode
Persistence
DSO1511G
1
2.4 inch
320*240
120M
500M
<3ns
128Kbit
1MΩ
5ns – 10s
10mV/div-10V/div
±40V（x1）
±400V（x10）
Auto/Normal
rise/fall
YT / Roll
None/1s / ∞
Coupling
AUTO
Measurement
Precision of V
Reference
Screenshot
Frequency
Single
FFT
Generator 0-2Mhz / 2.5V±0.1V
50%
Shell size width*hight* thickness
73 mm *93 mm *32mm
Language
Charging USB TypeC-5V 1A/2A/5A
15
AC/DC
Support
14 types
±2%
Support
Support
±0.01%
Support
Support
Support
CN/EN
