864 HO GreenSmart™ Fireplace
WARNING:
If the information in these instructions is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of
life.
f i r e - p a r t s . c o m
-
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this
or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Immediately call gas supplier from a neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the fire department.
-
Installation and service must be performed by a qualified installer, service agency or the
gas supplier.
This appliance may be installed in
an aftermarket permanently
located, manufactured home (USA
only) or mobile home, where not
prohibited by local codes.
This appliance is only for use
with the type(s) of gas indicated
on the rating plate. A conversion
kit is supplied with the appliance.
Owner's Manual
© Copyright 2010, T.I.
•
$10.00
100-01253_000
Tested and Listed by
Report # B0516PRT-001
• Operation
• Maintenance
www.travisproducts.com
4800 Harbour Pointe Blvd. SW
4100730
Mukilteo, WA 98275
ANSI Z21.88
Advertisement
Table of Contents
Related Manuals for Travis Industries GreenSmart 864 HO
Summary of Contents for Travis Industries GreenSmart 864 HO
- Page 1 864 HO GreenSmart™ Fireplace Tested and Listed by Report # B0516PRT-001 ANSI Z21.88 • Operation • Maintenance • WARNING: If the information in these instructions is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
-
Page 2: Introduction
Or, mail your warranty card to: Model: 864 HO GS Fireplace Travis Industries House of Fire 4800 Harbour Pointe Blvd. SW Mukilteo, WA 98275 Serial Number: Save Your Bill of Sale. -
Page 3: Table Of Contents
Heating Specifications Natural Gas Propane Approximate Heating Capacity (in square feet)* Up to 2,500 Up to 2,500 Maximum BTU Input Per Hour 46,700 46,700 Heating capacity will vary with floor plan, insulation, and outside temperature. 4100730 © Travis Industries 100-01253_000... -
Page 4: Safety Precautions
Immediately call a qualified vicinity of this heater. service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water. 4100730 © Travis Industries 100-01253_000... - Page 5 If the fiber logs become damaged, replace with Travis Industries log set. Children and adults should be Travis Industries, Inc. grants alerted to the hazards of high no warranty, implied or stated, surface temperature and should for the installation or...
-
Page 6: Operation
This switch turns the rear burner on and off. AA Battery Holder This holder contains 4 AA batteries that allow the fireplace to operate during power outages. This switch turns the fireplace burners on and off. Main Burner 4100730 © Travis Industries 100-01253_000... -
Page 7: Starting The Fireplace For The First Time
The rear portion of the burner may be shut off to lower the heat output and flame size from the burner (this is called the comfort control). Use the comfort control switch to adjust this as desired. COMFORT CONTROL 4100730 © Travis Industries 100-01253_000... -
Page 8: Adjusting The Flame Height
This fireplace has a built-in accent light that may be turned on and off and dimmed to your preference. Turn the knob to achieve the desired light output. f i r e - p a r t s . c o m HIGH ACCENT LIGHT HIGH 4100730 © Travis Industries 100-01253_000... -
Page 9: Adjusting The Blower Speed
Frequent On / Off Operation – if you are frequently turning the fireplace on and off, you may wish to leave it in continuous pilot. This allows the burner to turn on more quickly, without pilot ignition delay. CONTINUOUS PILOT GREEN SMART PILOT 4100730 © Travis Industries 100-01253_000... -
Page 10: Normal Operating Sounds
This appliance has several areas that reach high temperatures. Dust or other particles on these areas may burn and create an odor. This is normal during start-up. You may notice the smell is more acute if the appliance was left idle for a long period. 4100730 © Travis Industries 100-01253_000... -
Page 11: Maintenance
Panel Lights Lift up and swing the lower grill down to acces the area below the Swing the concealment cover firebox. up and slide it back to expose AA Battery the controls. Holder AA Battery Tray 4100730 © Travis Industries 100-01253_000... -
Page 12: Accent Light Replacement
Monitor blower operation. Remove any debris or vegetation near the vent termination. Contact your dealer if any sooting or deterioration is found near the vent termination. Venting system should be examined by a qualified agency. 4100730 © Travis Industries 100-01253_000... -
Page 13: Grill Installation And Removal
(this prevents the it allows the grill to swing bushing. Once in place the grill is grill from accidentally falling off). forward. held in place by gravity. 4100730 © Travis Industries 100-01253_000... -
Page 14: Face Installation And Removal
- p a r t s . c o m Phillips Screwdriver Four screws hold the face in place. The screws are accessed through the grills on the face. 4100730 © Travis Industries 100-01253_000... -
Page 15: Glass Frame Removal And Installation
Lift the glass frame slightly and attach the lower latches. NOTE: Make sure the glass frame is all the way in place - it should be flush with the front of the fireplace when installed. 4100730 © Travis Industries 100-01253_000... - Page 16 - p a r t s . c o m Note how the washer on the latch fits behind the flange on the glass frame anchor. Once fully inserted, turn the latch until it is upright. 4100730 © Travis Industries 100-01253_000...
- Page 17 On LP units, the log must locate within ½” (13mm) to 1” (26mm) of the back wall of the firebox. Positioning the log incorrectly may lead to sooting and insufficient flame quality. 4100730 © Travis Industries 100-01253_000...
- Page 18 Maintenance Right Log Install the right log as shown below. f i r e - p a r t s . c o m 4100730 © Travis Industries 100-01253_000...
- Page 19 Maintenance Center Log Install the center log as shown below. Position the log so it does not cover any burner holes. f i r e - p a r t s . c o m 4100730 © Travis Industries 100-01253_000...
- Page 20 Maintenance Left Log Install the left log as shown below. f i r e - p a r t s . c o m Left Twig Install the left twig as shown below. 4100730 © Travis Industries 100-01253_000...
- Page 21 Maintenance Right Twig Install the right twig as shown below. Right Branch f i r e - p a r t s . c o m Install the right branch as shown below. 4100730 © Travis Industries 100-01253_000...
- Page 22 Use a stiff brush to apply a thin layer of rockwool fibers onto the burner. Do not use the entire bag of rockwool. Use only a small amount and save the remainder. Over-use of rockwool will diminish the glow and may cause sooting or other adverse conditions. 4100730 © Travis Industries 100-01253_000...
-
Page 23: Glass Cleaning
WARNING: do not operate the fireplace without the glass frame in place. f i r e - p a r t s . c o m 4100730 © Travis Industries 100-01253_000... -
Page 24: Troubleshooting Table
Replace the AA batteries (see page 11) Comfort Control Does not Work The logs or coals are placed incorrectly See "Log Set Installation" Thin Layer of Soot Improper air shutter adjustment Adjust Air Shutter - contact your dealer Covers the Glass 4100730 © Travis Industries 100-01253_000... -
Page 25: Wiring Diagram
BATTERY COMFORT MAIN BURNER TRAY GREENSMART CONTROL PILOT Accent Thermodisk Light (s) Optional Blower(s) Accent Light Rheostat Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4100730 © Travis Industries 100-01253_000... - Page 26 INTERMITTENT Power In 110V OUT AUX OUT PILOT Accent Thermodisk Light (s) Optional Blower(s) Accent Light Rheostat Caution: Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation. 4100730 © Travis Industries 100-01253_000...
-
Page 27: Replacement Parts List
Maintenance Replacement Parts List Caution: Use only Travis Industries replacement parts. Do not use substitute materials. Warning: Do not operate appliance with the glass front removed, cracked, or broken. Replacement of the glass should be done by a licensed or qualified service person. -
Page 28: Warranty
2. Travis Industries has the option of either repairing or replacing the defective component. 3. If your dealer is unable to repair your appliance’s defect, he may process a warranty claim through TRAVIS INDUSTRIES, INC., including the name of the dealership where you purchased the appliance, a copy of your receipt showing the date of the appliance’s purchase, and the serial number on your appliance. -
Page 29: Optional Equipment
- p a r t s . c o m Firebacks There are several styles of decorative firebacks that fit inside the firebox and enhance the area behind the flames. 4100730 © Travis Industries 100-01253_000... -
Page 30: Index
Safety Precautions .............. 4 Starting the Fireplace for the First Time ......7 Troubleshooting Table ............24 Turning the Fireplace On and Off ........7 Warranty ................27 Wiring Diagram ..............25 Yearly Service Procedure ........... 12 4100730 © Travis Industries 100-01253_000...
