AINSWORTH A600-H Service Manual

Pari-mutuel wagering terminal
Hide thumbs
Table of Contents

Advertisement

Quick Links

Pari-Mutuel
Wagering Terminal
Service Manual
985 108 – 28 Rev A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the A600-H and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AINSWORTH A600-H

Summary of Contents for AINSWORTH A600-H

  • Page 1 Pari-Mutuel Wagering Terminal Service Manual 985 108 – 28 Rev A...

  • Page 2: Copyright Information

    985 108 – 28 Rev A COPYRIGHT INFORMATION Ainsworth Game Technology Limited claims copyright on each page of this document. The right to reproduce, distribute, display and make derivative works from this document, or any portion thereof requires approval from Ainsworth Game Technology Limited.

  • Page 3: Table Of Contents

    A600-H Wagering Terminal Dimensions ..........................27 Inspection ....................................28 Exterior ....................................28 Interior ....................................28 A600-H Wagering Terminal Mounting Instructions ......................29 Terminal Installation ................................31 Chapter 3 Technician Maintenance and Troubleshooting ....................33 System Maintenance / Audit ..............................34 Bill Acceptor Validator Test ..............................
  • Page 4 Logic Cage and Backplane Board Replacement ........................87 RAM Clear ....................................89 BASE Change ..................................92 Error Messages ..................................94 Troubleshooting ..................................98 Note Validator Error Display ..............................99 Spare Parts List ................................... 100 A600-H Wagering Terminal Wiring Diagram ........................108 Page 4 of 108...

  • Page 5: Introduction

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A INTRODUCTION This Service Manual is intended for use by the appropriate service personnel servicing the approved Historical Horse Racing Pari-Mutuel Wagering Terminal (Wagering Terminal, which is identified on the cover page.

  • Page 6: Chapter 1 Wagering Terminal Physical Components/Basic Operation

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Chapter 1 Wagering Terminal Physical Components/Basic Operation Page 6 of 108...

  • Page 7: Terminal Body Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Terminal Body Assembly The Terminal Body Assembly consists of four major assemblies: The Main Terminal Assembly, the Main Door, the Belly Door Assembly and the Monitor Door Assembly.

  • Page 8: Dual 24" Monitor Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Dual 24” Monitor Assembly The Dual Monitor Assembly comprises of a Monitor Mask, a Monitor Control Panel and a Frame that includes the 2 x 24” monitors. To access the Monitor Frame and the Monitor Control Panels it is required to open the Monitor Door Assembly.
  • Page 9 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Lift Knob to Unlock Monitor Door MEI Bill Acceptor Monitor Door Release Power LED on Monitor Control Panel Power and DVI Connections Monitor Door Opened. Monitor Controls Page 9 of 108...
  • Page 10 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Power LED (Turned Off Monitor Control Panel Note: The monitor control panel is located at the rear of the LCD assembly on the bottom left hand side and has an LED to show power is applied to the monitor.

  • Page 11: Main Door Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Main Door Assembly The Main Door is situated at the front of the Terminal Body and includes the Belly Door Assembly, the Coin Validator and Chute Mechanism, the Chip Tray, the Patron Tracking Module (where fitted) and the speakers.

  • Page 12: Button Panel

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Button Panel The button panel consists of an LCD touchscreen with one (1) mechanical play button to allow the patron to interact with the Wagering Terminal. The buttons also allow the operator and service technician to carry out testing and audit functions on the terminal.

  • Page 13: Belly Panel Door Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Belly Panel Door Assembly The Belly Panel Door is situated at the front of the Main Door and includes the LCD touchscreen with Bash Button Panel assembly, the Belly Panel Artwork and LED Belly Panel lighting. The Belly Panel assembly is also used to access the BACC Stacker Assembly during cash clearances by venue staff.
  • Page 14 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Belly Panel Door Assembly (con’t) Button Panel and Access to Stacker Backlight Door Connector through Harness Belly Panel Door Belly Door Open Detection Switch Belly Panel Door Open...

  • Page 15: Internal Components

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Internal Components Thermal Ticket 2 x 24” LCD Printer Monitor Assemblies Hard Patron Meter Tracking Assembly Blank / Light Panel Assembly Power Switch Logic Cage Assembly Bill Validator &...

  • Page 16: Note Validator Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Note Validator Assembly Note Validator Diagnostic LED’s Note Validator Note Validator locking lever Note Note Door Stacker Security Lock Housing Note Validator Note Validator The Note Validator receives notes that are entered through the Note Bezel and accepts or rejects notes by testing them.

  • Page 17: Note Stacker

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A The Note Validator incorporates an illuminated bezel that indicates to the patron whether the Note Validator can accept notes and a label showing which denominations. The illuminated bezel incorporates rows of LED’s which normally illuminate sequentially, indicating that notes may be...

  • Page 18: Printer (Optional)

    985 108 – 28 Rev A Printer (Optional) The Printer is an optional device which is fitted to our A600-H Wagering Terminal. The Printer is located beside the Logic Cage and the tickets exit through the top of the main door.

  • Page 19: Patron Tracking Module Provision

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Patron Tracking Module Provision Space is provided above the Note, Printer and Coin in Bezels in the door for a Patron Tracking Module to be fitted. The Patron tracking can be mounted on the door or in a tray (preferred). Note: To access this space the Main Door assembly must be open.
  • Page 20 985 108 – 28 Rev A Logic Cage Mainboard Security Handle Switch (Pull to remove Mainboard) CFast Mainboard Card Slots Tray Mainboard Status LEDs Logic Cage Security Door Open A600-H Wagering Terminal Motherboard Front Panel Layout Page 20 of 108...

  • Page 21: Mainboard Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Mainboard Assembly Heat Sink and Fans Assembly Mainboard Mainboard Tray Status LEDs Synergy XLR Mainboard Assembly The major circuit boards within the Logic Cage are: Mainboard The Main Board provides the controlling and operating function of the terminal. The Compact Flash Cards and system memory are all fitted to the Main Board and together incorporate the Main Board Assembly.

  • Page 22: Backplane Board

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Backplane Board The Main Board Assembly is connected to the Backplane Board. All peripherals and I/O Devices in turn are also connected to the Backplane Board. In summary the role of the Backplane Board is to link the software to all physical devices.

  • Page 23: Basic Operation

    Game Theme Display All game theme displays are for entertainment purposes only. Actual results are determined by the server system and jurisdictional requirements. The A600-H Wagering Terminal has dual 24” LCD Panels and an optional LCD topper display. Page 23 of 108...

  • Page 24: Specifications

    The terminal is 1374 mm high by 620 mm wide by 600 mm deep. It weighs +/- 120 kg. See also Chapter 2: A600-H Wagering Terminal Dimensions. Note: The weight is for the basic configuration only. Where options have been fitted their individual weights must be added.

  • Page 25: Environmental

    This will protect the user, installation technician and the terminal(s) from faulty mains supply. Environmental Standards of Compliance The A600-H Wagering Terminal complies with the mandated standards for the jurisdictions in which it is approved for operation. Page 25 of 108...

  • Page 26: Chapter 2 Wagering Terminal Installation / Conversions

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Chapter 2 Wagering Terminal Installation / Conversions Page 26 of 108...

  • Page 27: A600-H Wagering Terminal Dimensions

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A A600-H Wagering Terminal Dimensions Page 27 of 108...

  • Page 28: Inspection

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Inspection After securing the terminal on its bench, perform a detailed inspection to ensure that the terminal has not sustained any damage during transit. Exterior Carry out a detailed visual inspection of the exterior of the terminal to verify the following: 1.

  • Page 29: A600-H Wagering Terminal Mounting Instructions

    985 108 – 28 Rev A A600-H Wagering Terminal Mounting Instructions The A600-H Wagering Terminal is supplied with an installation kit; some parts in this kit may vary depending on the Jurisdiction the terminal is installed in. However, the hardware to bolt the terminal to a base/console will remain the same.
  • Page 30 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A The recommended holes to use for the mounting bolts are as follows: A. The front middle mounting hole as you are standing at the front of the terminal.

  • Page 31: Terminal Installation

    3. Power on the Wagering Terminal. 4. The Base and TM CF card will now be checked. 5. As the A560X-S32 Wagering Terminal boots up a blue Ainsworth screen will then appear with either of the following messages: NVRAM & E2PROM Cleared – Reset the Dip Switch 1 and 2 to continue.
  • Page 32 8. The Wagering Terminal IP Config screen will then be displayed. Wagering Terminal IP Config Screen 9. Connect a keyboard to the USB3.0 port on the A600-H Wagering Terminal Motherboard front panel. Enter the assigned Wagering Terminal Data and Save Settings. Remove the keyboard from the USB3.0 port on the A600-H Wagering Terminal Motherboard front panel.

  • Page 33: Chapter 3 Technician Maintenance And Troubleshooting

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Chapter 3 Technician Maintenance and Troubleshooting Page 33 of 108...

  • Page 34: System Maintenance / Audit

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A System Maintenance / Audit This section below describes how the System Maintenance / Audit Mode can be used to further assess various hardware components and peripherals to determine if they are faulty. This is primarily used by technicians to help them isolate any hardware problems with the Wagering Terminal.
  • Page 35 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A At the completion of testing; exit the System Test Menu as follows: 1. Select the INFO TAB at the top of the screen. 2. Select the Exit Maintenance icon to exit the Maintenance mode. This will take you back to the normal Game Display.

  • Page 36: Bill Acceptor Validator Test

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Bill Acceptor Validator Test Use the Bill Acceptor Validator Test to prove the operation of the Bill Acceptor. This test has the advantage that inserted notes are returned when the Reject button is selected and not guided to the stacker.
  • Page 37 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Bill Acceptor / Ticket Test Results Note: Select REJECT to return the Bank Note and not stack it. Select QUIT to exit the Bill Acceptor / Ticket Test Results screen...

  • Page 38: Printer Test

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Printer Test The Printer Test is used to determine if the Printer is acknowledged by the software. It is a basic test that initiates the Printer to print out a test page: Note: Upon entering this page if there is an outstanding fault with the Printer, such as a paper jam for example, it would be reported on screen.
  • Page 39 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Printer Test Results Screen Select OK to exit the Printer Test Results screen Page 39 of 108...

  • Page 40: Touchscreen Calibration

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Touchscreen Calibration The Touchscreen Calibrate on the Hardware Tab is used to calibrate the Touchscreen. It is a basic test that requires the user to touch squares on the LCD screen and the squares become highlighted indicating where the user has touched.
  • Page 41 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Select INFO TAB on the Maintenance display. Select EXIT MAINTENANCE, Game will resume. Page 41 of 108...

  • Page 42: Door Switch Test

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Door Switch Test Select the Switches Tab and use the door switch test to check the door interlocks. The display shows the condition of each of the door sensors (the various doors that can be tested are displayed in the screen shot displayed below).

  • Page 43: Terminal Sha1 Verification

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Terminal SHA1 Verification The Terminal SHA-1 Verification allows an operator or a technician to determine the SHA-1 of the installed Game Software, Base Software, and BIOS to compare these against the jurisdictional approval document(s).
  • Page 44 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A SHA1 Signature Test Results Screen Page 44 of 108...

  • Page 45: General Maintenance

    985 108 – 28 Rev A General Maintenance This section provides information for routine servicing of the A600-H Wagering Terminal. The instructions are limited to those that are deemed appropriate to be carried out on-site with minimum disruption to the terminal operation. More advanced information, and a listing of failure and status messages can be found at the end of this chapter.

  • Page 46: Note Validator Jam Clearing

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 3. The door opens towards the left, enabling the Note Stacker to be withdrawn. Removing Note Stacker Reverse the procedure to close and lock the Note Stacker Door.
  • Page 47 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 2. Open the Note Validator Note Path. This is done by pulling the yellow section forward and lifting the lid and bezel of the unit as displayed below.

  • Page 48: Note Validator Cleaning

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Note Validator Cleaning The Note Validator may reject notes with increased frequency as deposits on the Validator sensors accumulate. If the Note Validator requires cleaning the following procedures is to be used: Caution: Use a 90% solution of isopropyl alcohol to clean the Coin Validator.
  • Page 49 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Circuit Breaker reset Button A600-H Wagering Terminal PSU Side Panel Power Good LED on Backplane Board Page 49 of 108...

  • Page 50: Monitor Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Monitor Assembly The Monitor Controls are mounted on the rear of each LCD Panel. Open the Dual Monitor Door Assembly to adjust the Monitor. Monitor Mask Assembly Dual 24” LCD...

  • Page 51: Monitor Door Opening

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Monitor Door Opening Open the Main Door by rotating the Main Door Lock clockwise and raising the Main Door Release knurled lever. Once the main door is open there is a knurled knob (Monitor Door release) on the R/H side of the bill acceptor head;...

  • Page 52: Monitor Adjustment

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Monitor Adjustment Illustrated below is the monitors Key Control Board. The Key Control Board is used to fine tune and adjust the monitor. To access the control board the Monitor Door of the unit must be opened. The monitor control panel is located at the rear of the LCD assembly on the bottom left hand side and has an LED to show power is applied to the monitor.

  • Page 53: Osd Menu Screens

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A OSD Menu Screens Page 53 of 108...

  • Page 54: Osd Control Functions

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A OSD Control Functions Page 54 of 108...

  • Page 55: Lcd Monitor Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A LCD Monitor Replacement WARNING Check that you have disconnected electrical power from the terminal prior to carrying out removal/installation procedures. Even though the 2 x 24” LCD monitors operate at low voltages. Exercise extreme caution when handling the monitors or personal injury may result.
  • Page 56 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 5. Remove the 2 x 8mm Bolts fastening the LCD Monitor to the Monitor Door frame assembly. 2 x 8mm Bolts requiring removal 6. Pull the spring steel clip left and push it forward to separate the monitor frame assembly from the front monitor mask / door assembly as shown on the following page to facilitate removal of the LCD monitor.
  • Page 57 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A The Monitor Door and frame are separated as shown 7. The LCD Monitor can now be slid out of the L/H side of the monitor frame assembly using the handle as shown below.

  • Page 58: Speaker Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Installation: 1. Slide the LCD monitor into the Monitor door frame assembly. 2. Fasten into position with the 2 x 8mm Bolts removed previously. 3. Clip the Monitor Door/Mask and Monitor Frame assemblies together.

  • Page 59: Subwoofer Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Subwoofer Replacement The Subwoofer can be removed and installed by carrying out the following procedure: 1. Unlock and open the Main Door. 2. Power down the Wagering Terminal.

  • Page 60: Main Door Sub-Assemblies

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Main Door Sub-Assemblies The following instructions describe removal and installation of Main Door sub-assemblies. Main Door Opening The following procedure details how to open and close the Main Door.

  • Page 61: Belly Panel Door Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Belly Panel Door Assembly The Belly Panel Door is situated at the front of the Main Door and includes the Button Panel assembly, the Belly Panel Artwork and LED Belly Panel lighting. The Belly Panel assembly is also used to access the BACC Stacker Assembly during cash clearances by venue staff.
  • Page 62 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Belly Panel Door Assembly (Con’t) Button Access to Panel and Stacker Door Backlight through Connector Belly Panel Harness Door Belly Door Open Detection Switch Gas strut on Belly Panel Door Open.

  • Page 63: Lcd Touchscreen With Bash Button Panel Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A LCD Touchscreen with Bash Button Panel Replacement The Button Panel can be removed and installed by carrying out the following procedure: *Please Note* some items are not required to be performed if an LCD Touchscreen panel is installed.
  • Page 64 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A LCD Touchscreen with Bash Button Panel Replacement (Con’t) 2 x button panel fastening screws requiring removal. The Button Panel can now be removed Page 64 of 108...

  • Page 65: Lcd Touchscreen With Bash Button Panel Installation

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A LCD Touchscreen with Bash Button Panel Installation The LCD Touchscreen with Bash Button Panel can be installed by carrying out the following procedure: 1. Power OFF the Wagering Terminal 2.

  • Page 66: Changing The Artwork In The Belly Panel

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Changing the Artwork in the Belly Panel Changing the Artwork within the Belly Panel is easily done by following these steps. 1. Open the Main Door and power down the Wagering Terminal.

  • Page 67: Led Light Panel Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A LED Light Panel Replacement Changing the LED Light Panel within the Belly Door is easily done by following the steps: 1. Open the Main Door and power down the Wagering Terminal.

  • Page 68: Internal Components Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Internal Components Replacement The following instructions describe replacement of the Note Validator Assembly, the Printer and the Patron Tracking Module. Note Validator Replacement The Note Validator displayed below is a MEI SCNM8347 Note Validator. It is a general guide which is common to most Bill Validators.
  • Page 69 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Installation: 1. If the Note head was faulty just replace the head and reinsert it back into its housing. 2. Power up the Wagering Terminal. 3. Close the Main door.

  • Page 70: Note Validator Housing Replacement

    985 108 – 28 Rev A Note Validator Housing Replacement The following procedure explains the process for removing the Note Validator Housing including the MEI frame; however, this process is the same for all Note Validators used in the A600-H Wagering Terminal. Removal: 1.
  • Page 71 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 7. Next remove the Cashbox Coin Chute by undoing the 2 x M5 screws fastening it into place; one screw is accessed via a hole in the bottom of the note validator housing the other from outside the housing.
  • Page 72 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 9. Next remove the 3 x M5 screws fastening the note validator housing to the base of the terminal. 2 are located on the L/H side of the housing and 1 is located underneath and is accessed via a hole in the bottom of the housing.
  • Page 73 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 11. The Note Validator Housing can now be removed by sliding it forward out of the terminal on the base of the terminal so that the MEI harness can be removed before removing it completely from the terminal.

  • Page 74: Note Validator Frame Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Note Validator Frame Replacement The following procedure explains the process for removing the MEI frame; however, this process is same Note Validators used A600-H Wagering Terminal. If the MEI frame is only to be removed the following can be followed: 1.

  • Page 75: Printer Replacement (Optional)

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Printer Replacement (Optional) A ticket printer is an optional extra. The model of the ticket printer used will also vary according to the market requirements. Illustrated is the Ithaca 950 Ticket printer.
  • Page 76 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Removal: The Printer simply rests in its printer housing. It has one plug underneath at the back, which only needs to be detached to remove the complete printer unit (with housing).
  • Page 77 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Removal: To remove the printer and housing: 1. Unlock and open the Main Door. 2. Power down the Wagering Terminal. 3. Remove the printer as per the instructions outlined above.

  • Page 78: Patron Tracking Module Fitment

    1. The Patron Tracking Module is a draw design and it can be assembled on a bench prior to installation into the terminal. 2. Once the components are fastened to the draw insert the draw into the A600-H Wagering Terminal 3.

  • Page 79: Power Supply Replacement

    985 108 – 28 Rev A Power Supply Replacement The A600-H Wagering Terminal uses an integrated Universal Power Supply. The power supply is mounted below the Printer and Logic Cage assemblies and is at the rear of the Wagering Terminal.
  • Page 80 985 108 – 28 Rev A Interface Power Switch Interface Power Circuit Output Breaker Reset Button Mains Power in Connection A600-H Wagering Terminal PSU Side Panel Mains Switch Backplane Connection Board Power Harness A600-H Wagering Terminal PSU Top Panel Page 80 of 108...
  • Page 81 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Diagnostics To aid in diagnostics the Wagering Terminal Backplane Board has four blue status LED’s, each LED represents a pre-set voltage. The LED’s are (from left to right): +24V, +12V AUX, +12V and 5V.

  • Page 82: To Install A Power Supply, Follow These Instructions

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Installation: To install a power supply, follow these instructions: 1. Disconnect the Wagering Terminal from the Mains Supply. 2. Ensure that the Wagering Terminal Main Power Switch is OFF.

  • Page 83: Fiber Optic Interface, Optional

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Fiber Optic Interface, Optional The Fiber Optic Interface is attached to the left panel of the Wagering Terminal in front of the power supply and below the Ticket Printer shelf location.

  • Page 84: Logic Cage Assembly

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Logic Cage Assembly Mainboard Replacement Removal: 1. Unlock and open the Main Door to provide access to the Logic Cage. 2. Power down the Wagering Terminal. 3. Break and remove the security tag seal from the Logic Cage and unlock the door.

  • Page 85: Backplane Board Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Backplane Board Replacement Note: This procedure requires extreme care and is a relatively lengthy process. Be sure replacement is required prior to beginning. Removal: 1. Unlock and open the Main Door to provide access to the Logic Cage.
  • Page 86 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A A600-H Wagering Terminal Backplane Board. Page 86 of 108...

  • Page 87: Logic Cage And Backplane Board Replacement

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Logic Cage and Backplane Board Replacement This procedure is for when the Backplane Board is still part of the Logic Assembly Note: This procedure requires extreme care and is a relatively lengthy process. Be sure replacement is required prior to beginning.
  • Page 88 985 108 – 28 Rev A Remove this fastener at the rear of the Logic Cage A600-H Wagering Terminal Logic Cage top rear fastener location locating lugs at the top of the logic cage assembly A600-H Wagering Terminal Logic Cage locating lugs 4 x logic...

  • Page 89: Ram Clear

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A RAM Clear The RAM Clear process is only to be performed for a major fault or to change the base/game type. In the event of a major fault turn the Rest/Audit Key to the Audit position to enter the Maintenance Mode: 1.
  • Page 90 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 3. Select the Info Tab. 4. Open the Logic Cage Door. 5. Select the RAM Clear to restart the Wagering Terminal. Page 90 of 108...
  • Page 91 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 6. Select YES to clear a. Meter 1 & 2 Data, b. Bill / Ticket Acceptor History, c. XCredit History d. History File, and e. Restart the terminal.

  • Page 92: Base Change

    5. Power on the Wagering Terminal. 6. The Base and TM CF card will now be checked. 7. As the A560X-S32 Wagering Terminal boots up a blue Ainsworth screen will then appear with either of the following messages: a. NVRAM & E2PROM Cleared – Reset the Dip Switch 1 and 2 to continue.
  • Page 93 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 10. The IP Config screen will then be displayed; enter the assigned network data. 11. Continue with configuring the Wagering Terminal. Page 93 of 108...

  • Page 94: Error Messages

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Error Messages This table is the complete list of error and status messages. The most common causes and remedies are also listed. After clearing faults, use the CREDIT RESET / AUDIT MODE SWITCH to reset the terminal.
  • Page 95 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A not the same as the configured selection Hard Meter The Hard Meters have Check Security Switch. Adjust or Disconnected been disconnected or are replace loom connection, or swap the faulty.
  • Page 96 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Note Acceptor failure been Repair or replace the Note Validator. Fault detected Note Reset the terminal. Validator. Note Acceptor A Note is jammed in the Clear note path or replace the...
  • Page 97 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Self-Audit Error Self-Audit Check failed Clear NVRAM Reset the terminal. NVRAM EPROM System Error Clear NVRAM corrupted or there is a Game mismatch SYSTEM LOCKUP Program failure Clear NVRAM...

  • Page 98: Troubleshooting

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Troubleshooting This table lists problems with operating the terminal. Conditions that may be remedied by actioning on-screen prompts are not included. If the terminal fault remains after carrying out the suggested remedy, consider replacement of the circuit board assemblies within the Logic Cage.

  • Page 99: Note Validator Error Display

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A Note Validator Error Display This table lists the possible causes of errors associated with the Note Validator. Note The rows of LED’s on the illuminated bezel are numbered one through 4.

  • Page 100: Spare Parts List

    985 108 – 28 Rev A Spare Parts List Note: This parts list applies only to the A600-H Wagering Terminal and not all parts listed are available as a spare part. Please check with the Ainsworth Service Store for confirmation.
  • Page 101 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 017 723 A600 TOP DOOR CENTRE BADGE 017 724 A600 DUAL SCREEN CENTRE TOP TRIM A600 DUAL SCREEN TOP DOOR CTR 017 725 BOTTOM 017 726 A600 DUAL SCREEN SIDE TRIM RH...
  • Page 102 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 017 772 A600 COIN ENTRY GUIDE 017 773 A600 BOTTOM DOOR SIDE LOCK COVER 017 774 BELLY DOOR ROCKER SWITCH 017 776 A600 BELLY DOOR PUSH BUTTON 017 779...
  • Page 103 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 017 848 A600 DOOR ROLLER OPTIC BRACKET 017 849 A600 BOTTOM DOOR ROLLER OPTIC - 1 017 850 A600 BOTTOM DOOR ROLLER OPTIC - 2 017 851 A600 BELLY DOOR LOCK CAM...
  • Page 104 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 017 898 LARGE HOPPER PLATE 017 899 A600 BOTTOM TERMINAL GAS STRUT MOUNT 017 900 A600 19” TOPPER PLATFORM SPACER 017 901 A600 CHERRY SWITCH ACTUATOR 017 902...
  • Page 105 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 020 724 RUBBER BUMPER B0047-005 021 059 MICROSWITCH 021 113 GAS STRUT 021 114 GAS STRUT 021 115 GAS STRUT DAMPNER & CLEVIS PINS 023 027 13mm SMOOTH BALL CATCH 025 070 23.8”...
  • Page 106 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 210 950 LOGGING METER HARNESS 210 951 HARNESS – TICKET PRINTER 210 954 HARNESS NOTE ACCEPTOR – JCM 210 957 HARNESS HOPPER CYCLONE 210 961 A560 TERMINAL HARNESS...
  • Page 107 A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A 211 083 HARNESS 2.1 SOUND JUMPER 211 201 DVI HARNESS FOR 24” TOPPER 211 220 OLED ABUS HARNESS 211 244 OPTIC SENSOR 220 127 AMAOTO SPEAKER – 128mm...

  • Page 108: A600-H Wagering Terminal Wiring Diagram

    A600-H Service Manual Pari-Mutuel Wagering Terminal 985 108 – 28 Rev A A600-H Wagering Terminal Wiring Diagram Page 108 of 108...
