Quiet Portable
Air Conditioner
7,200/8,600 BTU
SKU: HME020379N
SKU: HME020235N
Thank you for purchasing our appliance.
Please be sure to read the entirety of this user
manual carefully prior to using this appliance.
If you have any questions regarding the use of
this product, please contact Customer Service
at homelabs.com/help or help@homelabs.com.
Advertisement
Table of Contents
Related Manuals for homelabs HME020379N
Summary of Contents for homelabs HME020379N
- Page 1 Thank you for purchasing our appliance. Please be sure to read the entirety of this user manual carefully prior to using this appliance. If you have any questions regarding the use of this product, please contact Customer Service at homelabs.com/help or help@homelabs.com.
-
Page 2: Table Of Contents
Failure to keep the product Manufacturing Info................in its original quality from the time of receipt may impede Warning....................hOmeLabs’s ability to correct any legitimate problem and may Contact Us................... limit the extent to which hOmeLabs may provide recourse. Specifications.................. - Page 3 Congratulations on bringing home your new appliance! Don’t forget to register your product at homelabs.com/reg for updates, coupons, and other relevant information. Although greatly appreciated, product registration is not required to activate any warranty.
-
Page 4: Important Safety Instructions
important safety instructions important safety instructions Read all instructions thoroughly before use and save them for future reference. CAUTION To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. This symbol indicates the possibility of property damage or serious consequences. - Page 5 Important Safety Instructions Important Safety Instructions Transport of Equipment Containing Flammable Refrigerants WARNING FOR USING R32 REFRIGERANT See transport regulations • Do not use any means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer.
- Page 6 Important Safety Instructions Important Safety Instructions The following checks shall be applied to installations using flammable refrigerants: The following procedure shall be adhered to: Remove refrigerant; Purge the circuit with inert gas; Evacuate; Purge again with inert gas; The charge size is in accordance with the room size within which the refrigerant containing parts are installed; Open the circuit by cutting or brazing.
-
Page 7: Parts Overview
Parts Overview Installation Instructions PREPARATION CHOOSING THE RIGHT LOCATION All the illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The actual shape will Your installation location should meet the following requirements: prevail. The unit can be controlled by the unit Control Panel alone or with the Remote Controller. This manual does not include •... - Page 8 Installation Instructions Installation Instructions TOOLS NEEDED HOW TO STAY COOL WITH A NEW PORTABLE AIR CONDITIONER (FOR MODELS COMPLYING WITH THE REQUIREMENTS OF U.S. DEPARTMENT OF ENERGY) • Medium Philips screwdriver; • Tape measure or ruler; Because of a new federal test procedure for Portable Air Conditioners, you may notice that the cooling capacity claims on Portable Air •...
-
Page 9: Operation
Operation Operation INSTALLATION INSTALLATION Your installation location should meet the following requirements: Preparing the Adjustable Window Slider • Make sure that you install your unit on an even surface for minimal noise and vibration. • Based on the size of your window, adjust the size of the Window Slider. •... - Page 10 Operation Operation CONTROL PANEL INSTALLATION TYPE 2: Sliding Window Installation 1. Cut Foam Seal A and B strips to the proper lengths and remove the adhesive backing. Attach them to the window sash and frame as shown. 2. Insert the Window Slider assembly into the window opening. 3.
- Page 11 Operation Operation OPERATION INSTRUCTIONS OTHER FEATURES “Auto-Restart” NOTE: If the unit shuts off unexpectedly due to a power outage, it will restart with the previous function settings automatically The unit can be operated by use of the Control Panel or the Remote Controller (See Page >...
-
Page 12: Remote Controller
Inserting and Replacing Batteries Applied Model: HME020379N, HME020235N Your Remote Controller comes with two AAA batteries. Put the batteries in the Remote Controller before use: 1. Slide the back cover from the Remote Controller downward to open the battery compartment. - Page 13 Remote Controller Remote Controller HOW TO USE THE BASIC FUNCTIONS HOW TO USE THE ADVANCED FUNCTIONS • “Cool” Operation • Operation (Dehumidifying) “Sleep” Function “Shortcut” Function 1. Press the “Mode” button. Select “Cool” mode. 1. Press the “Mode” button to select “Dry” mode. Used to decrease energy Used to restore the current settings use while you sleep.
- Page 14 Remote Controller Remote Controller SETTING THE “ TIMER ” FUNCTION SETTING THE “ TIMER ” FUNCTION When setting the “Timer On” or “Timer Off” functions for up to 10 Setting Both “Timer On” and “Timer Off” at the Same Time hours, the time will increase in 30-minute increments with each Keep in mind that the time periods you set for both functions refer to hours after the current time.
-
Page 15: Maintenance
Maintenance Troubleshooting PROBLEM POSSIBLE CAUSES SOLUTION WARNING: • Always unplug the unit before cleaning or any repairs. Water Collection Tray is full. • Do not use flammable liquids or chemicals to clean the unit. P1 Error Code Turn off the unit, drain the water from the •... -
Page 16: Warranty
(a) normal wear and tear; (b) abuse, mishandling, accident, or failure to follow operating instructions; (c) exposure to liquid or infiltration of foreign particles; (d) servicing or modifications of the product other than by hOmeLabs; (e) commercial or non-household use. The hOmeLabs warranty covers all costs related to restoring the proven defective product through repair or replacement of any defective part and necessary labor so that it conforms to its original specifications. A replacement product may be provided instead of repairing a defective product. hOmeLabs’s exclusive obligation under this warranty is limited to such repair or replacement. - Page 17 For Household Use Only Distributed by hOmeLabs™, LLC 350 Springfield Avenue, Suite #200, Summit, NJ 07901 help@homelabs.com homelabs.com/help All rights reserved, hOmeLabs™ Made in China.
