Digital pressure gauge model CPG1200
Digitalmanometer Typ CPG1200
Digital pressure gauge model CPG1200
Operating instructions
Betriebsanleitung
EN
DE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPG1200 and is the answer not in the manual?

Questions and answers

Summary of Contents for WIKA CPG1200

  • Page 1 Operating instructions Betriebsanleitung Digital pressure gauge model CPG1200 Digitalmanometer Typ CPG1200 Digital pressure gauge model CPG1200...
  • Page 2 3 - 76 Betriebsanleitung Typ CPG1200 Seite 77 - 150 Further languages can be found at www.wika.com. © 05/2023 WIKA Alexander Wiegand SE & Co. KG All rights reserved. / Alle Rechte vorbehalten. ® WIKA is a registered trademark in various countries.
  • Page 3 6.2.1 Battery operation ......25 6.2.2 Mains operation via USB power supply unit ....26 WIKA operating instructions, model CPG1200...
  • Page 4 7.5.2 WIKA-Cal configuration (also possible with the demo version)..48 7.5.3 WIKA-Cal Log-Template ......50 App “myWIKA device”...
  • Page 5 11. Specifications 11.1 Specifications for CPG1200 ....60 11.2 Radio standard ....65 11.2.1 IC warnings RSS-Gen &...
  • Page 6 ■ Factory calibrations/DAkkS calibrations are carried out in accordance with ■ international standards. Further information: ■ WIKA Alexander Wiegand SE & Co. KG - Internet address: www.wika.de / www.wika.com - Relevant data sheet: CT 10.20 - Contact: Tel.: +49 9372 132-0 info@wika.de...
  • Page 7 ... identifies hazards caused by electrical power. Should the safety instructions not be observed, there is a risk of serious or fatal injury. Information ... points out useful tips, recommendations and information for efficient and trouble-free operation. WIKA operating instructions, model CPG1200...
  • Page 8 With an accuracy of ±0.5 % FS or ±0.25 % FS, the CPG1200 can be used as a calibration instrument as well as a reference instrument for a range of applications such as...
  • Page 9 No serial number needs to be entered. WIKA - intelligent serial number The WIKA intelligent serial number and the corresponding web application is the central tool in which all the required information on the specific instrument can be found.
  • Page 10 You can also download (calibration) certificates directly from this location. Under “Article details”, further article details are listed, as well as documentation such as the data sheet and current operating instructions WIKA operating instructions, model CPG1200...
  • Page 11 The use of unstable fluids, especially hydrogen, must be avoided. If the CPG1200 is used in applications with oil as a pressure medium, make sure it will not be used with combustibles or gases directly after that because it can lead to dangerous explosions and danger to personnel and machinery.
  • Page 12 11 “Specifications”. Improper handling or operation of the instrument outside of its technical specifications requires the instrument to be taken out of service immediately and inspected by an authorised WIKA service engineer. Handle electronic measuring instruments with the required care (protect from humidity, impacts, strong magnetic fields, static electricity and extreme temperatures, do not insert any objects into the instrument or its openings).
  • Page 13 Position of product label Position of labelling for the batteries Position of labelling for general information Product label (example) The product label is located on the rear of the CPG1200 on the cover of the battery compartment. CPG1200-1ID-B Pressure range: 0 ...
  • Page 14 3. Safety Labelling on the process connection The label is located on the upper half of the CPG1200 process connection. i#: 12345678901 QR code with link to product pass Radio approval Date of manufacture (YYYY-MM) Serial number Article number Voltage supply...
  • Page 15 4. Transport, packaging and storage 4. Transport, packaging and storage Transport Check the CPG1200 for any damage that may have been caused. Obvious damage must be reported to the manufacturer immediately. CAUTION! Damage through improper transport With improper transport, damage to property can occur.
  • Page 16 ■ It is locked, if the [ZERO/▲] or [MENU/◀▶] buttons have been locked via WIKA-Cal and must be pressed manually. The password protection is only implemented via the WIKA-Cal calibration software or the free-of-charge WIKA-DCS software. Battery symbol The battery symbol is displayed only during battery operation.
  • Page 17 Menu will be displayed Function buttons The CPG1200 is controlled via 4 function buttons, with each button having a main and a secondary function. In general, the information printed on the buttons corresponds to the main function: “ZERO”, “LIGHT” “MENU”, “ON/OFF”. Once the [MENU/◀▶] button is activated, the secondary function applies.
  • Page 18 By pressing the [MENU/◀▶] button, menu mode will be selected. If the CPG1200 is already in menu mode, the operation of “◀” or “▶” will depend on the display. If the button is pressed for longer, after 2 seconds the cursor switches (left ◀...
  • Page 19 The CPG1200 is available with all industry-standard process connections, as standard G ½ B is specified. When screwing the NPT thread of the CPG1200 to an adapter or a pressure connection, it is necessary to use additional sealant between the threads, e.g. PTFE tape. The hose, lines and fittings etc.
  • Page 20 The CPG1200 can, optionally, be configured with an integrated data logger. This data logger can be switched on and set via “MENU” / “Logger” (respectively). If the log rate time is longer than the measuring rate, the CPG1200 will take the average pressure value instead of the current pressure value.
  • Page 21 ® “Bluetooth” must be set to “On”. Once this has been done, the Bluetooth symbol blinks in the display. As soon as the CPG1200 is connected to a PC or mobile device via ® this Bluetooth interface, the symbol is displayed continuously.
  • Page 22 Mounting near to electromagnetic switches or cables carrying high currents ■ Direct contact with water, oil, chemicals or their vapours ■ Installation and plant conditions which can lead to the formation of atomic hydrogen ■ in the connection channel of the sensor. WIKA operating instructions, model CPG1200...
  • Page 23 Only mount the CPG1200 if it is in perfect condition with respect to safety. Prior to commissioning, the CPG1200 must be subjected to a visual inspection. To avoid possible damage to the CPG1200 or to test equipment, note the following with mechanical mounting: Requirements for mounting point: ▶...
  • Page 24 ▶ If the message “OL” or “-OL” is displayed, the measuring range has been exceeded and the pressure source must be removed immediately from the CPG1200 to prevent damage to the internal sensor. For information on tapped holes, see technical information IN 00.14 at www.wika.com.
  • Page 25 Due to different discharge curves, the battery level indicator may not match the actual battery level indicator. Damage to the instrument To avoid possible damage to CPG1200 or to test equipment, note the following: ▶ Always replace all three batteries together! ▶...
  • Page 26 Places where there is strong humidity or condensation ■ Outdoors ■ ▶ Disconnect the power supply unit from the mains supply when it won't be used for a longer period of time. WIKA operating instructions, model CPG1200...
  • Page 27 6. Commissioning, operation Plug the USB power supply unit's Micro-USB type B connector into the socket on the side panel of the CPG1200 and plug the adapter into a power outlet. Specifications for USB port USB input DC 5 V, 100 mA, 0.5 W...
  • Page 28 6.3.2 Zero point adjustment Zeroing the indication value to 0 ▶ Press the [ZERO/▲] button. For gauge pressure measuring ranges, the CPG1200 must be set to 0 with the [ZERO/▲] button before each use. [ZERO/▲] button [ON/OFF] button 6.3.3 MAX/MIN The CPG1200 stores the minimum and maximum pressure in the memory.
  • Page 29 1) 2) feet 1) 2) inch User-defined unit 1 User-defined unit 2 1) Only in combination with accuracy 0.25 % FS 2) Units are only displayed if the setting Level = is set to On. WIKA operating instructions, model CPG1200...
  • Page 30 Offset (value-dependent) Damping Off (presetting) Medium High Sample rate 2/s (presetting) 10/s Logger interval Alarm Off (presetting) Lower (value-dependent) Upper (value-dependent) Density unit kg/dm³ (presetting) lb/ft³ kg/m³ 1) Only in combination with accuracy 0.25 % FS WIKA operating instructions, model CPG1200...
  • Page 31 Delay (0000 h 00 min) [Limit: 23 h 59 min] Clear last Clear all Rename Entry 1 Entry 1 1) Only in combination with accuracy 0.25 % FS 3) Only available when Logger is enabled WIKA operating instructions, model CPG1200...
  • Page 32 15 min (presetting) Light off time Off (presetting) 30 s User unit Name1 Factor1 Name2 Factor2 Factory reset No (presetting) 1) Only in combination with accuracy 0.25 % FS 4) Available only when function was ordered. WIKA operating instructions, model CPG1200...
  • Page 33 Measuring mode 7.2.1 Pressure unit The CPG1200 is factory preset to the pressure unit of “bar” or “psi”, depending on the measuring range. Via the menu, the instrument can be changed to 5 pressure units and 1 user-defined unit, or (with the higher accuracy) an additional 15 predefined pressure and level units and a further user-defined unit.
  • Page 34 (matrix field). The previously active will automatically be deactivated. 7.2.3 Temperature The CPG1200 is temperature-compensated. This option displays the temperature measured by the internal sensor. The indication unit can be selected in the menu under “Measure Mode” / “Temperature” in degrees Fahrenheit, degrees Celsius or Kelvin.
  • Page 35 The Tare value input is limited to the measuring range. The limitation is calculated depending on the measuring range and unit. If a measured value due to a tare setting exceeds the value that can be indicated, “-----” is displayed. WIKA operating instructions, model CPG1200...
  • Page 36 The instrument moves back one menu level. Press the [HOME] button in order to exit the menu. 7.2.6 Sample rate The sample rate indicates the interval at which the CPG1200 requests pressure values from the sensor. The following values can be selected: ■...
  • Page 37 [MENU/◀▶] button to jump one digit to the right. To accept the set alarm value, press the [MENU/◀▶] button repeatedly until the instrument jumps back one menu level. Press the [HOME] button in order to exit the menu. WIKA operating instructions, model CPG1200...
  • Page 38 2. Confirm the selection with the [MENU/◀▶] button. ⇒ With ON or OFF, the instrument moves back one menu level. ⇒ If Density is selected, an input field for the calculation factor appears. (The input is made from left to right.) WIKA operating instructions, model CPG1200...
  • Page 39 0.0000 Limited to ±5 % Span factor 1.00000 Limited to ±10 % It is recommended to have the instrument calibrated if one or both of the two factors (offset or span factor) have been changed. WIKA operating instructions, model CPG1200...
  • Page 40 If the logger memory is full, the logger process is automatically stopped. The logger file contains the following values: Logger settings (once at the start) ■ Indicated pressure value if measuring interval = logger interval ■ WIKA operating instructions, model CPG1200...
  • Page 41 To accept the set logger interval value, press the [MENU/◀▶] button repeatedly until the instrument jumps back one menu level. Press the [HOME] button in order to exit the menu. WIKA operating instructions, model CPG1200...
  • Page 42 If Delay is selected, an input field appears with hour and minute values. (The input is made from left to right.) 3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the number and use the [MENU/◀▶] button to jump one digit to the right. WIKA operating instructions, model CPG1200...
  • Page 43 In order to accept the set name, press the [MENU/◀▶] button repeatedly until you return to the previous menu level. It is not possible to rename a logger process that has already been stored while the logger process is running/active. WIKA operating instructions, model CPG1200...
  • Page 44 This function is only displayed if the Bluetooth option has been ordered. 7.4.2 Language The Language function shows a selection of the languages available on the CPG1200. To change the instrument language, proceed as follows under “Menu” / “Measure mode” / “Language”: 1.
  • Page 45 In addition to the standard units, there are one or two configurable custom units to choose from. The user-defined units are defined in “Settings” / “User unit” by “Name 1”, “Factor 1” and “Name 2”, “Factor 2”. The default designation is “UsUnit1” or “UsUnit2” and the factor “1.000”. WIKA operating instructions, model CPG1200...
  • Page 46 An input field for the limit value appears. (The input is made from left to right.) 3. Use the [LIGHT/▼] button or [ZERO/▲] button to select the letter and use the [MENU/◀▶] button to jump one digit to the right. WIKA operating instructions, model CPG1200...
  • Page 47 The second configurable user-defined units is only available with 0.25 % FS accuracy. 7.4.6 Factory reset The Factory reset function resets the CPG1200 to default settings. Stored logger processes are retained. The entry of the password to enable the data logger remains stored after a factory reset of the instrument.
  • Page 48 For further information, see also chapter 5.6.4 “Bluetooth®”. 7.5.2 WIKA-Cal configuration (also possible with the demo version) 1. In the WIKA-Cal, define CPG1200 as standard in “Object manager” / “Standards (pressure)” and assign it to the workplace. 2. Open the menu item “Workstation” / “Object manager”.
  • Page 49 The communication is working properly if the pressure value displayed on the instrument is shown after pressing the [Test] button. If the “Bluetooth” in the CPG1200 is not activated, an error message “Activate Bluetooth in the CPG1200“ appears, see chapter 7.5.1 “Activating Bluetooth® in the CPG1200”...
  • Page 50 Select the CPG1200 used and confirm. By pressing the [Measuring results] graphic, the logger process is started. Relog Logger processes can be repeated. Download The logger sequences stored on the CPG1200 can be downloaded and archived using “Download”. WIKA operating instructions, model CPG1200...
  • Page 51 Logs that were stored on the mobile device can be transferred to a PC and be read by WIKA-Cal. This enables them to be processed further and the app forms the final part of a complete solution for handling data from the CPG1200.
  • Page 52 7. Operation via menu functions / 8. Faults Firmware update A firmware update can be made via the free software packages, WIKA-Cal or WIKA-DCS. Procedure 1. Install the WIKA-Cal software or alternative WIKA-DCS on a PC or notebook. 2. Connect the instrument to the PC or notebook via the USB interface.
  • Page 53 Ensure the correct polarity, see to button press chapter 9.2 “Battery replacement”. System error Switch off the CPG1200, wait for a short period of time, switch on again Defect in the CPG1200 Send in for repair WIKA operating instructions, model CPG1200...
  • Page 54 This does not apply to the replacement of alkaline batteries. Only use original parts (see chapter 12 “Accessories”). Battery replacement Damage to the instrument To avoid possible damage to CPG1200 or to test equipment, note the following: ▶ Always replace all three batteries together! ▶...
  • Page 55 Do not leave empty batteries in the instrument. Dispose of batteries and rechargeable batteries properly, see chapter 10.3.2 “Disposal of batteries”. Wear protective gloves! Use protective gloves when damaged or leaking/leaked batteries must be removed. WIKA operating instructions, model CPG1200...
  • Page 56 If there is any visible damage to the case or the wiring, do not use the power supply unit! ▶ Before cleaning, disconnect the power supply unit from the mains supply. ▶ Do not clean with chemical cleaning agents. Only clean with a dry cloth. WIKA operating instructions, model CPG1200...
  • Page 57 We recommend that the instrument is regularly calibrated by the manufacturer, with time intervals of approx. 12 months. The default settings will be corrected if necessary. The calibration label is attached at the side of CPG1200. For instruments with protective case cap, it is located at the top beneath the protective cap.
  • Page 58 4. Clean the digital pressure gauge as required, see chapter 9.3 “Cleaning”. 10.2 Return Strictly observe the following when shipping the instrument: All instruments delivered to WIKA must be free from any kind of hazardous substances (acids, bases, solutions, etc.) and must therefore be cleaned before being returned. WARNING!
  • Page 59 Ensure a proper disposal in accordance with national regulations. ▶ Hand in used batteries and rechargeable batteries for environmentally friendly disposal at retail outlets or appropriate collection points in accordance with national or local regulations. WIKA operating instructions, model CPG1200...
  • Page 60 2) FS = Full span = end of measuring range - start of measuring range 3) Weight determined with a G ½ process connection. With other process connections, the weight can differ from the values specified here. WIKA operating instructions, model CPG1200...
  • Page 61 1) FS = Full span = end of measuring range - start of measuring range Reference conditions per IEC 61298-1 Ambient temperature 15 ... 25 °C [59 ... 77 °F] 860 ... 1,060 mbar [12.5 ... 15.4 psi] Atmospheric pressure Air humidity 45 … 75 % r. h. (non-condensing) WIKA operating instructions, model CPG1200...
  • Page 62 -14.5 ... +15 -14.5 ... 300 -1 ... 1 -1 ... 20 -14.5 ... 160 -1 ... 5 -1 ... 24 -1 ... 9 -1 ... 40 -1 ... 10 Other measuring ranges on request. WIKA operating instructions, model CPG1200...
  • Page 63 1) Specifications in accordance with technical information IN 00.41 2) With 3.1 inspection certificate per DIN EN 10204 Input signal Micro-USB type B Input voltage DC 5 V Input current 100 mA Power 500 mW WIKA operating instructions, model CPG1200...
  • Page 64 -20 ... +70 °C [-4 ... +158 °F] Storage temperature range Relative humidity, < 84 % r. h. (non-condensing) condensation Permissible media All liquids and gases which are compatible with 316 stainless steel Permissible pollution degree 2 per EN 61010-1 WIKA operating instructions, model CPG1200...
  • Page 65 2. This device must accept any interference, including interference that may cause undesired operation of the device. Caution: Radio Frequency Radiation Exposure This equipment complies with IC radiation exposure limits set forth for an uncontrolled environment and meets the IC radio frequency (RF) Exposure Guidelines. WIKA operating instructions, model CPG1200...
  • Page 66 Increase the separation between the equipment and receiver. ■ Connect the equipment into an outlet on a circuit different from that to which the ■ receiver is connected. Consult the dealer or an experienced radio/TV technician for help. ■ WIKA operating instructions, model CPG1200...
  • Page 67 EN 300 328 harmonised frequency range 2,400 … 2,500 MHz is ® used; Bluetooth 5.2 Low Energy (BLE), max. transmission power 3.3 mW. The instrument may be used without restrictions in the EU and in the EFTA countries. RoHS directive WIKA operating instructions, model CPG1200...
  • Page 68 1 year (dependent on conditions of use) interval 1) Calibrated in vertical mounting position with process connection facing downwards For approvals and certificates, see website For further specifications, see WIKA data sheet CT 10.20 and the order documentation. WIKA operating instructions, model CPG1200...
  • Page 69 11. Specifications 11.5 Dimensions in mm [in] 11.5.1 Digital pressure gauge CPG1200 without protective case cap Ø 87,18 54,05 [3.43] [2.13] G 1/4 [1.22] 26,9 [1.06] [1.26] WIKA operating instructions, model CPG1200...
  • Page 70 11. Specifications CPG1200 with protective case cap 97,41 59,38 [3.84] [2.34] [0.2] 33,5 G 1/4 [1.32] 26,9 [1.06] [1.26] 11.5.2 Process connections Spanner width 27 mm, G ¼ B per EN 837 WIKA operating instructions, model CPG1200...
  • Page 71 11. Specifications EN 837 EN 837 G ¼ B 13 [0.51] G ⅛ B 15 [0.59] G ½ B 20 [0.79] ANSI/ASME B1.20.1 ¼ NPT 13 [0.51] WIKA operating instructions, model CPG1200...
  • Page 72 May not be used in Ex areas! Protective case cap - Ex-approved For CPG1200 case Plastic case For 1 x CPG1200 for storage and transport The plastic case is not permitted to be used in hazardous areas! Plastic case For 3 x CPG1200 for storage and transport...
  • Page 73 1. Order code: CPG-A-12 ⇓ 2. Option: 1) The figures are an example and may change depending on the state of the art in design, material composition and representation. WIKA accessories can be found online at www.wika.com. WIKA operating instructions, model CPG1200...
  • Page 74 Annex 1: EU declaration of conformity WIKA operating instructions, model CPG1200...
  • Page 75 Annex 2: UK declaration of conformity WIKA operating instructions, model CPG1200...
  • Page 76 WIKA operating instructions, model CPG1200...
