Cooper Lighting Shaper 699 Specification Sheet

D E S C R I P T I O N
699 features a graceful Crescent Shape with indirect and front
illumination and is ADA compliant.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted aluminum or solid brass
for brass (only) with a 3/16"
matte white acrylic lens. 1/4"
matte white acrylic lens.
F i n i s h
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Satin
Copper (SCP), Satin Brass (SB),
Polished Brass (PB), Polished
Copper (PCP), Lacquered Satin
Aluminum (SAL), Oxidized Brass
(OBRS), Satin Nickel (SN),
Polished Nickel (PN), Natural
Aluminum (NA), Lacquered Satin
Chrome (SCL), Lacquered Satin
Nickel (SNL) or Custom Color
(CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF , multi-volt
120/277V (347V Canada),
thermally protected with end-of-
O R D E R I N G I N F O R M AT I O N
Sample Number: 699-CFL/1/39-277V-PCP
Series Lamp
699 Graceful = CFL/1/39
Cresent
INC/2/60
Notes:
1
Available with CFL only.
life circuitry to accommodate the
specified lamp wattage.
L a m p / S o cke t
One (1) 39W (2G11) high lumen
CFL lamp, or two (2) 60W frosted
T-10 lamps. CFL socket injection
molded plastic. INC socket fired
ceramic rated for 660W-250V.
Lamps furnished by others.
I n s t a l l a t i o n
Supplied with a universal
mounting plate for a standard 4"
J-box or plaster ring.
O p t i o n s
Hand Painted Faux Alabaster
Diffuser (FD), Perf Top Cover
(PTC), Perforated Diffuser (PDF),
MRI Applications (INC only) -
Contact factory, Modified Integral
Emergency Battery (MEM),
Damp Location (DL): All Painted
Finishes, Lacquered Satin
Chrome (SCL) and Lacquered
Satin Nickel (SNL) finishes only.
Energy Star Rating - Consult
factory.
Voltage Finish
120V NA Natural Aluminum =
1
277V
Standard
1
347V MW Matte White =
Premium
CC Custom Color =
OBRS Oxidized Brass =
PB Polished Brass =
PC Polished Chrome =
PCP Polished Copper =
PN Polished Nickel =
SAL Lacquered Satin Aluminum =
SB Satin Brass =
SC Satin Chrome =
SCL Lacquered Satin Chrome =
SCP Satin Copper =
SN Satin Nickel =
SNL Lacquered Satin Nickel =
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements. ADA
compliant.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location =
MEM Modified Integral Emergency Battery =
FD Hand Painted Faux Alabaster Diffuser =
PDF Perforated Diffuser =
PTC Perforated Top Cover =
shaperlighting.com
Type
Date
699 SERIES
I n t e r i o r W a l l L u m i n a i r e
G r a c e f u l C r e s c e n t
AMERICAN DISABILITIES
ACT (ADA)
Shaper offers a large selection of ADA
interior and exterior wall luminaires.
ADA requires all fixtures below 68" to
have a maximum projection of 4".
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
