D E S C R I P T I O N
691 features a Floating Silhouette Dome.
S P E C I F I C AT I O N F E AT U R E S
M a te ri a l
Painted or plated cold-rolled
steel base metal.
F i n i s h
Standard: Matte White (MW).
Premium: Satin Chrome (SC),
Polished Chrome (PC), Polished
Copper (PCP), Satin Copper
(SCP), Satin Brass (SB), Polished
Brass (PB), Satin Nickel (SN),
Polished Nickel (PN), Lacquered
Satin Chrome (SCL), Lacquered
Satin Nickel (SNL) or Custom
Color (CC).
O p t i c s
Refer to
www.shaperlighting.com for
complete photometrics.
B a l l a s t
Integral electronic HPF multi-volt
120/277V (347V Canada),
thermally protected with end-of-
life circuitry to accommodate
13W, 26W, or 32W lamps.
O R D E R I N G I N F O R M AT I O N
Sample Number: 691-CFL/2-277V-PCP
Series
Lamp
691 Floating
=
CFL/2 (26/32W-Triple)
Silhouette Dome
CFL/2/13
INC/2/75
Notes:
1
Available with CFL only.
2
Supplied by others.
L a m p / S o cke t
Two (2) 13W (2GX7) 4-pin low
wattage CFL, two (2) 26W or 32W
(GX24q-3) 4-pin triple CFL lamps
or two (2) 75W A-19 lamps. CFL
socket injection molded plastic.
INC socket fired ceramic rated for
660W-250V. Lamps furnished by
others.
I n s t a l l a t i o n
Supplied with a universal
circular strap for a standard 4"
J-box or plaster ring.
O p t i o n s
Perforated Dome with Accent
Disc (PFD), Remote Emergency
Battery - Supplied by others
(REM), Damp Location (DL): All
Painted Finishes, Lacquered
Satin Chrome (SCL) and
Lacquered Satin Nickel (SNL)
finishes only. Energy Star Rating
- Contact factory. MRI
Applications (INC only) - Contact
Factory.
Voltage
Finish
120V
Standard
1
MW Matte White
=
277V
1
347V
Premium
CC Custom Color
=
PB Polished Brass
=
PC Polished Chrome
=
PCP Polished Copper
=
PN Polished Nickel
=
SB Satin Brass
=
SC Satin Chrome
=
SCL Lacquered Satin Chrome
=
SCP Satin Copper
=
SN Satin Nickel
=
SNL Lacquered Satin Nickel
=
Specifications and dimensions subject to change without notice.
Consult your representative for additional options and finishes.
Catalog #
Project
Comments
Prepared by
L a b e l s
U.L. and C.U.L approved for
indoor and damp location. See
options for damp location
finishing requirements.
M o d i f i c a t i o n s
Shaper's skilled craftspeople
with their depth of experience
offer the designer the flexibility
to modify standard wall
luminaires for project specific
solutions. Contact the factory
regarding scale options, unique
finishes, mounting, additional
materials/colors, or decorative
detailing.
Options
DL Damp Location
=
PFD Perforated Dome w/ Accent Disc
=
2
REM Remote Emergency Battery
=
shaperlighting.com
Type
Date
691 SERIES
I n t e r i o r W a l l L u m i n a i r e
F l o a t i n g S i l h o u e t t e D o m e
SUSTAINABLE
DESIGN
Shaper has a long-standing history
of offering environmentally-friendly
fixtures. The copper and bronze alloys
used in our exterior luminaires feature
up to 98% recycled content, contribute
less undesirable air emissions compared
to painted aluminum and are easy to
recycle.
MAGNETIC
RESONANCE
IMAGING (MRI)
Lighting fixtures for MRI facilities are
specialized and unique, requiring non-
ferrous construction. Fluorescent fixtures
cannot be used due to the ferrous parts in
ballasts and lampholders. Modified incan-
descent fixtures meet the requirements.
ENERGY
STAR
Shaper now offers a wide variety of
fixtures that can be provided with an
Energy Star Rating.
Refer to the Icon Legend
Link on shaperlighting.com.
