FORENO NORTH NRT73RBB Installation Instructions

NORTH Double Head Shower
Brushed Brass (PVD) NRT73RBB
9 421027 598973
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for Mains Pressure only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa*
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
TOP INLET PLUMBING CONNECTION.
CONFIGURATION
Mains Pressure systems
Unequal Low Systems
Equal Low systems
INSTALLATION
*FOR PRESSURES EXCEEDING 500KPA INSTALL A PRESSURE REDUCING VALVE. THOROUGHLY FLUSH ALL
PIPES TO ELIMINATE ANY REMAINING DIRT AND RESIDUE, AND INSTALL INLINE FILTERS. FAILURE TO DO
SO MAY VOID THE WARRANTY.
CAUTION: IF USING YOUR OWN SCREWS TO INSTALL THE WALL BRACKETS, DO NOT USE COUNTER SUNK TYPE
SCREWS, AS THIS WILL VOID THE WARRANTY.
• Refer installation diagram, overleaf.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Install as supplied.
Not suitable.
Not suitable.
