FORENO LE TAP LTS3 Installation Instructions

LE TAP 3 Function Slide Shower
Chrome LTS3
9 421027 598102
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for Mains Pressure Only
Minimum Pressure = 150kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure Systems Install as supplied.
Unequal Low Systems Not Suitable.
Equal Low systems
CONTENTS
• Wall brackets and covers
• Fixing kit (wall anchors & screws)
• Glide bar with adjuster/holder
• 1.5m supply hose
• Supply elbow
• Shower handpiece
• Soap dish
• Flow regulator
INSTALLATION
*FOR PRESSURES EXCEEDING 500kPa INSTALL A PRESSURE REDUCING VALVE. THOROUGHLY FLUSH ALL
PIPES TO ELIMINATE ANY REMAINING DIRT AND RESIDUE, AND INSTALL INLINE FILTERS. FAILURE TO DO SO
MAY VOID THE WARRANTY.
CAUTION: If using your own screws to install the wall brackets, DO NOT use counter sunk type screws as
this will void the warranty.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Not Suitable.
Black O-ring
7.5L/min Flow Regulator
Mains Pressure installation:
Insert the flow regulator with the O ring
facing away from the hose (as shown).
This will comply with the WELS rating.
Water Flow
Shower Elbow
(O-ring side)
Flow Regulator
Washer
Flexi Hose
