FORENO ESPREE FLO EF04 Installation Instructions

T A P W A R E M A D E F O R N E W Z E A L A N D s i n c e 1 9 6 9
ESPREE FLO
Slide Shower
Chrome EF04
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.
TECHNICAL SPECIFICATIONS
Suitable for All Pressures
Minimum Pressure = 35kPa
Maximum operating Pressure = 500kPa* (As per NZ Building Code AS/NZ 3500.1)
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.
CONFIGURATION
Mains Pressure systems Install the flow restrictor as shown in the diagram below.
Unequal Low Systems Install as supplied.
Equal Low systems Install as supplied.
CONTENTS
• Wall brackets
• Fixing kit
• Glide bar with adjuster/holder
• 1.5m supply hose
• Supply elbow
• Shower handpiece
• Flow restrictor for Mains Pressure installation
INSTALLATION
*FOR PRESSURES EXCEEDING 500kPa INSTALL A PRESSURE REDUCING VALVE. THOROUGHLY FLUSH ALL
PIPES TO ELIMINATE ANY REMAINING DIRT AND RESIDUE, AND INSTALL INLINE FILTERS. FAILURE TO DO SO
MAY VOID THE WARRANTY.
CAUTION: If using your own screws to install the wall brackets, DO NOT use counter sunk type screws as
this will void the warranty.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Water Flow
Black O-ring
8L/min Flow Regulator
Mains Pressure installation only:
Insert the flow regulator with the O ring
facing away from the hose (as shown).
This will comply with the WELS rating.
Shower Elbow
(O-ring side)
Flow Regulator
Washer
Flexi Hose
