FORENO Muro MUR030 Instructions

Muro Shower Mixer
MUR030
9 421027 594296
Congratulations on your purchase of this high quality product from Foreno Tapware.
Please read the following before installation and retain (along with your receipt) for future reference.

TECHNICAL SPECIFICATIONS

Suitable for All Pressures.
Minimum Pressure = 35kPa
Maximum operating Pressure = 500kPa
Maximum operating Temperature = 65 deg. Celsius
For domestic use only.

CONFIGURATION

Mains Pressure systems Install as supplied (NB: with no Green or Yellow valve inserts in the shower mixer body).
Equal Low systems
Unequal Low systems
there is an arrow on the insert, this must be pointed towards the mixer, with the rubber ring to the outside (the
arrow show the water flow direction). Install the yellow valve insert into the water inlet on the cold side (marked
with a 'C'). NB: there is an arrow on the insert, this must be pointed towards the mixer, with the O-ring to the outside
(the arrow indicates the water flow direction).

INSTALLATION

Installation must comply with Section 5.4 of AS/NZS 3500 Standard with regard to Isolating stop cock use. Shower
mixers must be water tested with the outlet open, to prevent damage to cartridge seals; due to back pressure.
All pipe work must be flushed prior to the installation of this mixer, accessible inline filters must be installed in the
pipework for both the hot and cold inlet supply to prevent particles from damaging the ceramic cartridge.
FORENO TAPWARE (NZ) LTD | Freephone: 0508 FORENO | info@foreno.co.nz | 5 Hewlett Street, Port Whangarei 0110 | FORENO.CO.NZ
Install as supplied (NB: with no Green or Yellow valve inserts in the shower mixer body).
Install the green valve insert into the water inlet on the hot side (marked with an 'H'). NB:
