1- PRESENTATION, SAFETY RECOMMENDATIONS AND GENERAL PRECAUTIONS ........................................................ 2
2- DESCRIPTION OF THE MACHINE ........................................................................................................................... 3-4
3- INSTALLATION OF THE MACHINE ......................................................................................................................... 5-6
4- PRODUCT OPERATION ......................................................................................................................................... 7
Key definition ................................................................................................................................................ 7
Recommendations on the use of welding modes ............................................................................................. 8
Using pneumatic clamps C ............................................................................................................................. 9-12
Use a gun ..................................................................................................................................................... 12
Error management ........................................................................................................................................ 13
Welding spot counter .................................................................................................................................... 14
Recording features (report - user identification mode - user programs) ........................................................... 14-17
SD memory card ........................................................................................................................................... 17
Software ....................................................................................................................................................... 18-21
5- USE AND MAINTENANCE PRECAUTIONS ................................................................................................................ 22
User training ................................................................................................................................................. 22
Preparation of the work-piece ........................................................................................................................ 22
Single sided gun welding ............................................................................................................................... 22
Cooling liquid level and efficiency ................................................................................................................... 22
Cleaning the pneumatic filter ......................................................................................................................... 22
Generator maintenance ................................................................................................................................. 22
Cleaning / replacement of welding tools and other items ................................................................................. 22
Installation and use of the gun....................................................................................................................... 23
Replacement of C arms ................................................................................................................................. 24
Adjustment of C arms .................................................................................................................................... 25-27
6 - SYMPTOMS / REASONS / SOLUTIONS .................................................................................................................. 28
7 - DECLARATION OF CONFORMITY ......................................................................................................................... 29
8 - WARRANTY ........................................................................................................................................................ 29
9 - CIRCUIT DIAGRAM ............................................................................................................................................. 30
10 - COOLING LIQUID CIRCUIT ................................................................................................................................ 31
11 - CLAMP CABLE BEAM CONNECTORS ................................................................................................................... 31
12 - TECHNICAL SPECIFICATIONS ............................................................................................................................ 32
13 - ICONS .............................................................................................................................................................. 32
73502-26.02.2016-V1
MI200T SPOTWELDER - 220 V
USER MANUAL
Table of Contents
Other languages are available on the SD card.
CO9703.1
IN20773
Rev. - 3/15/2016
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CHIEF MI200T
Summary of Contents for CHIEF MI200T
-
Page 1: Table Of Contents
MI200T SPOTWELDER – 220 V USER MANUAL Table of Contents 1- PRESENTATION, SAFETY RECOMMENDATIONS AND GENERAL PRECAUTIONS ............2 2- DESCRIPTION OF THE MACHINE ........................... 3-4 3- INSTALLATION OF THE MACHINE ......................... 5-6 4- PRODUCT OPERATION ............................7 Key definition ..............................7 Recommendations on the use of welding modes ..................... -
Page 2: 1- Presentation, Safety Recommendations And General Precautions
Chief Automotive Technologies cannot be held responsible for damage to persons or items, as a result of using the machine in the following... -
Page 3: 2- Description Of The Machine
2. DESCRIPTION DE LA MACHINE Front panel SD card reader Display panel Rear panel 40A D-Curve Switch Pneumatic filter, 30 mA differential Pneumatic network air connector C clamp Button (B) : remote Button (A) : Open / Close control of welding the clamp. - Page 4 X4 MI200T Stand assembly b X4 d x4 a X2 b X2 60mm 1 mm M8 x 12 70mm 2 mm 80mm M5 x 10 M8 x 16...
-
Page 5: 3- Installation Of The Machine
Connect a 3 phase plug with earth (minimum 40 A) to the power cable. Chief MI200T 3 phases 220 V / 50 Hz In case of bad connection or bad voltage on the electrical line, the following screen will appear : On the right hand side of the screen appears the voltage on each phase. - Page 6 Filling the cooling tank Chief Automotive Technologies recommends that you specific welding machine coolant with antifreeze and corrosion inhibitors in this cooling tank. The use of other cooling liquids, and in particular standard cooling liquids, can lead to the accumulation of solid substances inside the cooling system (due to electrolysis), this will negatively impact the cooling efficiency, and possibly cause total obstruction of the system.
-
Page 7: 4- Product Operation
4- PRODUCT OPERATION Key definition allow modification of each parameter. sich die Werte ① key ändern oder auswählen; die + und – Tasten erhöhen bzw. _ This key is used to select the tool required: Clamp, verringern den ausgewählten Wert. -
Page 8: Recommendations On The Use Of Welding Modes
The AUTO, ENERGY, and CAR MANUFACTURER modes are available on MI200T models only. The AUTO mode allows welding without entering any parameter inside the machine. This mode may be used on all welding spots identified as non-critical by the car manufacturers. -
Page 9: Using Pneumatic Clamps C
Using the C pneumatic clamp - Tighten the C-clamp using the locking lever and check that the screw between the arm and the clamp is correctly tightened. - The clamping force is calculated by the machine, considering the force setting or the thickness of the sheets selected. CLAMP SETTING MODE key is used to enter the clamp adjustment mode. - Page 10 MULTI-sheet Mode This mode allows the user specify the thickness and type of each sheet in an assembly of 2 or 3 sheets. Using The up and down button (key definition diagram, (5) ) allows selection of the parameters for each sheet. When the parameters for a sheet are highlighted, the sheet thickness and type of steel can be adjusted using the + and –...
- Page 11 User programmed welding spots can be recalled by selecting USER in the list of car manufacturers. The welding spots can be programmed using the welding spot programming module in the software. AUTO Mode : The AUTO mode is optional and is configurable in the setup menu that is activated by pressing the mode key for 2 seconds (AUTO MODE : ON / OFF).
-
Page 12: Use A Gun
SETTINGS MODE : The SETTINGS mode can be accessed by pressing the MODE key during more than 2 seconds. The language of the menus can be selected on line 1. The date and time can be entered on line 2. The CAR MANUFACTURER, AUTO and ENERGY modes can be also be disabled in this menu. -
Page 13: Error Management
When highlighted, a parameter can be adjusted using the + and – keys. The and keys allow movement from one parameter to the next. Error Management Different events might cause the appearance of error messages. They can be classified in three categories: - General Warnings: i.e overheating, lack of electrode force or welding current, etc…... -
Page 14: Welding Spot Counter
Saving a report allows spot welding data to be stored on a memory card, in order to retrieve it at a later date e.g. on a computer. Chief Automative Technologies supplies software called SPOT to read the SD card and the user manual. - Page 15 To erase the content of a report , it has to be To erase the report shown, press and the on screen by pressing "view" following message will be on the screen: When the warning image is displayed, press again and the report content will be erased. The warning image will disappear after 3 seconds.
- Page 16 The Mode button changes the field to modify playback. : « Registration number » (optional) Screen: « Vehicle make » (optional) Screen Screen: « Vehicle model » (optional) Screen: Chassis number (optional) Catalogue The View button , allows you to view all repair orders on the screen - "CATALOGUE": The number of pages is displayed (max 13) at the top The left and right arrow keys scroll through the pages.
-
Page 17: Sd Memory Card
SD memory card (ref CEL050914) This card is a link between the MI200T and a PC to enable the user to: - Retrieve and print reports for a record of work, and documentation for insurance companies if required. -
Page 18: Software
3.1/ Import the spot reports made from an SD card To import the spot reports made with your MI200T to your PC, insert the SD card into the PC card drive, or use a card reader, and start up the SPOT software. - Page 19 Insert the SD card delivered with your MI200T spot welding machine in the SD card reader of your PC, then select the corresponding reader identifier in the « Unit Choice» menu.
- Page 20 The other files are restricted to Car Manufacturer defined welding spots. It is possible to import downloaded Car manufacturer files from the website. It is not possible to add, edit or delete a welding spot saved in a Car Manufacturer file. 4.1/ Import a Car Manufacturer welding spot file Double click in the first column and highlight a car manufacturer name.
- Page 21 4.3/ Edit a welding spot programmed in the USER file In order to edit the parameters of a programmed welding spot, select a welding spot in the list and then edit the welding parameters. To validated the modifications, click on the button To cancel the modifications, click on the button 4.4/ Delete a welding spot programmed in the USER file Select a welding spot programmed in the list, then click on the button...
-
Page 22: 5- Use And Maintenance Precautions
Ensure the dehumidifier filter located at the back of the machine is cleaned regularly. Generator maintenance The maintenance and repair of the generator should only be carried out by a Chief Automotive Technologies technician. Any repair/maintenance made to the generator by unauthorized personnel will invalidate the machine's warranty - Chief Automotive Technologies will not take responsibility for any incident or accident under these circumstances. -
Page 23: Installation And Use Of The Gun
Installation and use of the gun The gun and the earth clamp are optional. Ref: CEL051010 - Select the clamp adjustment mode in the menus, in order to stop the pump and the flow of cooling liquid. - Fix the earth cable on the removable electrode; put the clamp and tighten the lever. - Remove the arm from the top and put the gun cable instead of that one. -
Page 24: Replacement Of C Arms
Replacement of C arms Please read the following instructions carefully. Incorrectly tightening or setting the C clamp arms can lead to the arm and clamp overheating and causing damage. Damage caused by incorrect assembly are not covered under the warranty ... -
Page 25: Adjustment Of C Arms
Adjustment of C arms Ⓓ - Position screw to fix the arm on the clamp. Tighten it in manually - do not overtighten. - Tighten ring manually, then the tighten using the Allen key. Ⓔ - Tighten the lever manually and check it is not end up against the joint stop (see diagram below). Ⓓ. - Page 26 A bad tightening leads to a loss of current, and worst can damage your arm or clamp irreversibly. Connexion MI200T / C clamp : B : Black G : Green W : White Y : Yellow...
- Page 27 Arm types for the C clamp: Spot control HLE / HTS 1,0mm (x150) Ref. CEL050181 Ref. CEL050433 THLE / VHTS 2,5mm (x150) Ref. CEL050167...
-
Page 28: Symptoms / Reasons / Solutions
6. SYMPTOMS / REASONS / SOLUTIONS SYMPTOMS REASONS SOLUTIONS The caps used are worn Replace the caps out/faulty Insufficient grinding / Sand and clean the metal The Spot weld doesn’t hold / preparation of the workpiece sheet again is not good The arm selected doesn’t Check the arm with the match the one installed... -
Page 30: Circuit Diagram
9 - CIRCUIT DIAGRAM... -
Page 31: Cooling Liquid Circuit
10 – COOLING LIQUID CIRCUIT 11 – CLAMP CABLE BEAM CONNECTIONS... -
Page 32: Technical Specifications
12 – Technical specifications ELECTRICAL CHARACTERISTICS Nominal input voltage : U1N 3~200V 3~208V 3~230V 3~240V Frequency 50/60 Hz Permanent input current : I1N 40 A Power at 50 % duty cycle : S50 20 kVA Permanent input power : Sp 14 kVA Maximum welding input power : Smax 80 kVA...
