Summary of Contents for NuPrime STA-6
- Page 1 COMMERCIAL STA-6 Class A+D Stereo Amplifier Bridgeable into a 160 watt Mono Amplifier...
- Page 2 FCC Notice - Declaration of Conformity Information This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
- Page 3 The manufacturer of this product is NuPrime Audio, Inc., 1712 Pioneer Ave. Ste 1817, Cheyenne, Wyoming 82001, USA The Authorized Representative for EMC and product safety is NuPrime Audio, Inc., 1712 Pioneer Ave. Ste 1817, Cheyenne, Wyoming 82001, USA. For any service or guarantee matters please refer to the addresses given in separate service or guarantee documents.
-
Page 4: Safety Instructions
Safety Instructions There are two categories of Safety Instructions included in this manual: • Product Warnings, (i.e., what must never be done to assure avoiding those hazards that could cause bodily injury or property damage); and • User Directions (i.e., what must always be done to assure the safe use of your device). The Safety Instructions contained in this manual have been categorized in accordance with the seriousness of the potential hazards through the use of Signal Words. - Page 5 WARNING: Your device is not a toy. Never allow children to play with your device. Misuse, rough or improper handling of your device by children could result in serious bodily injury for any of the enumerated safety warnings in this manual. In addition, always keep all accessories and components out of the reach of small children as small parts might present a choking hazard.
- Page 6 The unit must be connected to a power supply only of the type and voltage specified on the rear panel. Connect the component to the power outlet only with the supplied power supply cable or an exact equivalent. Do not modify the supplied cable. Do not route the power cord where it will be crushed, pinched, bent, exposed to heat, or damaged in any way.
- Page 7 A comparison with traditional designs is mind-boggling. A NuPrime amp, small enough to sit on the palm of one’s hand, is, typically, 85% efficient – in practical terms, cool-running and easy on the utility bill.
- Page 8 20 to 50,000Hz. Only a very few, very expensive linear amplifiers are capable of achieving that. This bandwidth allows NuPrime to amplify complex music with faithfulness far beyond the capability of conventional amps, with particular regard to a vast soundstage –...
- Page 9 Introduction The NuPrime STA-6, a 2 X 90W Class A+D stereo amp, bridgeable into a 160W mono amp, is designed with enhanced even-order harmonic circuitry that produces sonic characteristic similar to NuPrime STA-9, but leaning toward neutral with a slight hint of warmth. The STA-6's spacious, transparent, dynamic and luxuriously textured soundstage has to be heard to believe.
-
Page 10: Specifications
The STA-6's frequency response to 50 kHz elevates vocals into emotional experiences; similarly, instrumental upper registers mimic a live performance’s shimmering heights. The STA-6 is designated for NuPrime Commercial product line and it is designed to be highly reliable under no-load condition and enhanced short circuit protection. - Page 11 Quick Start Guide Front Panel View: COMMERCIAL Back Panel View: Inputs: Outputs: RCA analog input x 1 Stereo Speaker Out x 1 Mono Speaker Out x 1...
-
Page 12: Stereo Connection
Stereo Connection: Preamp Stereo Speakers or CD/DVD/BD player Stereo Make sure the Stereo/Mono switch is switched properly to STEREO. 2. Make sure the RCA analog connection is properly connected. Connect stereo speakers to the output terminals. -
Page 13: Mono Connection
Mono Connection: Preamp Mono or CD/DVD/BD player Speakers Mono Make sure the Stereo/Mono switch is switched properly to MONO. 2. Make sure the RCA analog connection is properly connected. (Gray-out inputs do not work under MONO mode) Connect mono speaker to the output terminals. 4. -
Page 14: Limited Warranty
LIMITED WARRANTY For a period of ONE (1) YEAR from the date of retail purchase by the original end-user purchaser (“Warranty Period”), NuPrime warrants (in) this product against defects in materials and workmanship, and (ii) that each Product, unmodified and under normal use and conditions, will substantially comply with NuPrime’... -
Page 15: Obtaining Warranty Service
OBTAINING WARRANTY SERVICE If you purchased the product in the U.S., deliver the product, at your expense, to any NuPrime Service Center located in the U.S. If you purchased the product outside of the U.S., deliver the product to any NuPrime Authorized Importer in the country where you purchased the product. -
Page 16: Exclusions And Limitations
This Limited Warranty applies only to hardware products manufactured by or for NuPrime that can be identified by the "NuPrime" trademark, trade name, or logo affixed to them. The Limited Warranty does not apply to any non-NuPrime hardware products or any accessories, even if packaged or sold with NuPrime hardware. - Page 17 REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE REMEDY OF THE CONSUMER. NUPRIME SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS PRODUCT IS LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
