User Manual
INFO:
To ensure that your cleaning
equipment can continue to
operate reliably and smoothly,
please change the O-rings
approx. every 6 months.
See: Service/Maintenance Section 3
1
US STEAM®
2440 Chambers Street, Ste A Venus, Texas 76084
1
(817) 297-7745 / ussteam.net

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BlueEvolution XL+ TS and is the answer not in the manual?

Questions and answers

Related Manuals for US Steam BlueEvolution XL+ TS

Summary of Contents for US Steam BlueEvolution XL+ TS

  • Page 1 INFO: To ensure that your cleaning equipment can continue to operate reliably and smoothly, please change the O-rings approx. every 6 months. See: Service/Maintenance Section 3 US STEAM® 2440 Chambers Street, Ste A Venus, Texas 76084 (817) 297-7745 / ussteam.net...

  • Page 2: Technical Data

    Technical data BlueEvolution XL+ TS POWER SUPPLY 480 V. 60Hz Electrical connection Nominal voltage 380-415 VAC 50-60 Hz READY TIME 5 MINUTES Total output 7200 W BOILER REFILL SYSTEM AUTOMATIC REFILL Boiler nominal consumption (2000 x 3) W (Boiler made from stainless...
  • Page 3 Assembly (Collection Tank, Handle, and Toolbox) ________________________________________ Quick Start Steam _______________________________________________________________________ Extraction ____________________________________________________________________ Vacuum ______________________________________________________________________ Extraction ______________________________________________________________________ Accessories ____________________________________________________________________ Troubleshooting / Error Codes _______________________________________________________ Maintenance - Descaling ___________________________________________________________ Maintenance – O-Rings _____________________________________________________________ Notices _________________________________________________________________________ Warranty & Repair ________________________________________________________________ Ø D0 NOT leave the steam cleaner unattended while plugged in Ø...
  • Page 4 The revolution in commercial cleaning The BlueEvolution is more flexible than any other professional steam cleaner. Both the steam and suction power have 3 settings. You can also regulate the hot water inflow continuously using a control valve, which allows you to set the soaking effect on the device individually.

  • Page 5: Important Advice For Users

    Important Advice for Users Congratulations on the purchase of this product. • Before cleaning ovens, fridges etc. always disconnect the power first to ensure these are switched off. You must follow the manufacturers' specific instruc- Your choice confirms your strong technical knowledge and your excellent taste. tions.

  • Page 6: Accessories Box

    Description of equipment ➊ ON/OFF button boiler Driving handle ➋ ON/OFF button suction Locking screw driving handle ➌ ON/OFF button hot water module Locking lever driving handle ➍ Display ➎ Socket steam suction hose ➏ Drain plug water tank ➐ Drain plug hot water module ➑...
  • Page 7 Assembly / preparation Assembly of the driving handle and Fill the reservoir accessories box Fill the hot water module Attach the handle using the two fixing knobs. Tighten them • Open the cap and fill the water tank with normal tap by turning clockwise.

  • Page 8: Assembly / Preparation

    Assembly / preparation Filling the filter bowl WARNING: Your appliance is fitted with a hygienic water filter. You must Insert the filter bowl correctly on the bottom rails to make fill the filter bowl with water before starting, in order to bind sure the fill level sensor is properly engaged.
  • Page 9 Start-up steam Insert the mains plug into the wall socket. Steam Function Turn the general switch to ON, Press and hold the steam button on the handle to de- liver steam. You can adjust the steam function by pressing buttons on the side of the handle. There are 3 steam modes to choose from: Mode 1 = Minimum steam flow, for use on sensitive sur- faces such as wood, parquet floors, upholstery, etc.
  • Page 10 Start-up steam with hot water module Start-up suction Status: Status: PAUSE HEATING STEAM VACUUM WATER STEAM VACUUM WATER MENU STANDBY MENU STANDBY The soaking effect and, thus, cleaning performance can be Suction increased for heavy soiling by switching the hot water mo- Press the “VACUUM”...
  • Page 11 Reports Lack of water in the tank A lack of water in the tank is indicated by the error E01 shown on the display and by an acoustic signal at the same Error: time. To resume work, follow the instructions on the display, by Empty waste tank clicking in the “Tap for other info”...

  • Page 12: Shutting Down

    Shutting down To ensure the functionality, cleanliness and hygiene of the INFO: appliance and accessories, follow this procedure to shut down the appliance: Repeat the rinsing process with clear water if there is a lot of foam. 1) Remove the filter bowl, empty out the water and re-insert. Alternatively, the steam suction hose can also be cleaned using a suitably sized sponge soaked in disinfectant.
  • Page 14 Entkalkungsanleitung B Entkalkungsanleitung B Extraction Cleaning, care and maintenance of accessories Cleaning, care and maintenance of accessories Your steam vacuum uses a separate reservoir tank to inject water into the steam as Care of accessories Care of accessories Care of accessories It is essential to clean accessory parts after use to maintain the performance and functio- it’s released from the extraction nozzle.
  • Page 15 Entkalkungsanleitung B Entkalkungsanleitung B Accessories (order at www.ussteam.net) Cleaning, care and maintenance of accessories Cleaning, care and maintenance of accessories Care of accessories Care of accessories Care of accessories It is essential to clean accessory parts after use to maintain the performance and functio- It is essential to clean accessory parts after use to maintain the performance and functionality of the It is essential to clean accessory parts after use to maintain the performance and functionality of the nality of the appliance.

  • Page 16: Troubleshooting

    Trouble Shooting PROBLEM SOLUTION The Blue Evolution powers ON This is normal: Ø Push the ON/OFF Button on the console to power ON the Blue after plugging into the electrical outlet and then turns OFF Evolution The Blue Evolution should be the ONLY appliance plugged into the electrical outlet: Does not turn power up when the Ø...
  • Page 17 Hot water module descaling...
  • Page 18 Warning! Descalers can be harmful. Read the information on the descaler packaging and follow the safety instructions. Descalers or vinegar may cause damage to surfaces. Wipe up drops immediately. Only use suitable and recommended descalers. The steam hose does not have to be descaled if you use decalcified water. 1.
  • Page 19 Hot water module discaling Rinse the Tank with Tap Water 3. Rinsing 3. Rinsing Pour 1 liter of tap water into the tank washing 2. Descaling extraction. Connect the appliance to the mains Pour 0.5 litres of clear tap water into the reservoir “Hot and press button (C) on the display.
  • Page 20 Boiler descaling...
  • Page 21 Descaling instructions boiler / introduction Entkalkungsanleitung B The boiler must be descaled, at the latest, when the error E05 appears on the display. Be- Descaling instructions boiler / introduction cause the hardness of the water varies signi cantly depending on the location, scheduled descaling may need to be brought forward if you notice a signi cant drop in steam emission, or particles of limescale coming out of the steam accessories.
  • Page 22 Entkalkungsanleitung B Descaling instructions boiler / introduction You must perform descaling at the latest when the “Probe cap with Clean” symbol appears on the display. As water quality varies hugely by region, descaling may also be required before this. Check the probe cap for limescale accordingly.
  • Page 23 3. Rinsing The rinsing stage involves three emptying cy- cles. Please proceed as follows. Close the boiler drain plug (tighten without forcing) and ll with clean water the re ll tank (O), then press the "OK" icon. After 20 minutes, the machine will stop and the display will notify that it is possible to drain the boiler and the re ll tank (O).
  • Page 24 4. Re-assembly Close the boiler drainage outlet (do not screw too tight), ll the reservoir with clean water and then press button A to start wor- Stat PAUSA king normally. NOTE: STEAM MOTORE If there is no water in the reservoir during the MENU descaling programme, the machine will au- tomatically pause.To restart, ll the reservoir...
  • Page 25 The H dram Proce • Loo from Service/Maintenance Part 3 • Loo HEPA-filter (optional); water filter and O-rings Then Repla...

  • Page 26: Maintenance & Cleaning

    Look foward to it. Look foward to it. Look foward to it. Maintenance / cleaning Maintenance / cleaning Maintenance / cleaning Maintenance / cleaning Look foward to it. Maintenance / cleaning Replacing the air fi lter (HEPA filter) Replacing the air fi lter (HEPA fi lter) Replacing the air fi...
  • Page 27 Entkalkungsanleitung B Entkalkungsanleitung B Entkalkungsanleitung B Cleaning, care and maintenance of accessories Cleaning, care and maintenance of accessories Cleaning, care and maintenance of accessories Care of accessories Care of accessories Care of accessories Care of accessories It is essential to clean accessory parts after use to maintain the performance and functio- It is essential to clean accessory parts after use to maintain the performance and functionality of the It is essential to clean accessory parts after use to maintain the performance and functionality of the It is essential to clean accessory parts after use to maintain the performance and functionality of the...

  • Page 28: Electrical Connections

    Read all instructions before using this steam cleaner. WARNING: STEAM GENERATED BY THE STEAM CLEANER IS EXTREMELY HOT AND WILL CAUSE INJURY IF IT COMES IN CONTACT WITH THE SKIN OR EYES. USE AS DIRECTED BY THE MANUAL AND ONLY AIM THE STEAM HANDLE AT THE CLEANING AREA. Ø...

  • Page 29: Service And Support

    5. DO NOT SEND IN A REPAIR WITHOUT AN RMA. WARRANTY Your steamer comes with a warranty which becomes effective on the date of purchase from US STEAM and is granted to the initial customer and is nontransferable. Any claims under this warranty must be made before the end of the applicable warranty period.
  • Page 30 Seats & Floors Auto Combine steam and extraction into one system for more efficient detailing. A Better Way to Clean US STEAM® 2440 Chamber Street, Ste A Venus, TX 76083 www.ussteam.net (817) 297-7745...
