Summary of Contents for US Steam Blue Evolution
- Page 1 User Manual 2440 Chambers Street, Ste A Venus, Texas 76084 (817) 297-7745...
-
Page 3: Table Of Contents
Table of Contents Assembly (Collection Tank, Handle, and Toolbox) ____________________________________ Quick Start Steam ____________________________________________________________________ Extraction _________________________________________________________________ Vacuum __________________________________________________________________ Tools & Accessories ___________________________________________________________ Indicators ___________________________________________________________________ Trouble Shooting / Error Codes. __________________________________________________ Descaling ___________________________________________________________________ Maintenance _________________________________________________________________ Specifications ________________________________________________________________ Warranty & Repair ____________________________________________________________ Ø... - Page 4 Blue Evolution Boiler Cap Cleaning Accessories Water Reservoir Tanks Console Collection Tank Hose Connection Exhaust Cover Look foward to it. Drain Plugs er module Start-up suction Iron (not included) Low Water Steam Pressure Descaling Boiler Temperature Extraction Steam Boiler Heating...
-
Page 5: Assembly (Collection Tank, Handle, And Toolbox)
Ø Secure the lid to the tank before re-installing. Ø To install the tank, pull out the latches and slide tank onto the back of the Blue Evolution. Ø Use the latches to lock tank in place. It should slide smoothly and fit tightly. -
Page 6: Quick Start
6) Steam Control INFO: If you only wish to suction liquid, such as accidental water Ø The Blue Evolution should be the Ø Unlock the trigger by pressing spills, it is not necessary to fi ll the appliance's fi lter bowl with water. -
Page 7: Vacuum
Quick Start-Up Vacuum Hot Water Injection / Extraction Vacuum ON/OFF Activate the VACUUM by Your Blue Evolution has the ability Ø Pushing the button on the to add water to the steam. console OR Ø Pushing the button on the... -
Page 9: Tools & Accessories
Cleaning Tools Extension Wands Floor Brush (Set of 2) Part # SV5672 Hose Part # SV1594 Part # SV4896 Small Extraction Nozzle Large Extraction Nozzle Part # SV7314 Part # SV8011 1-Hole Nozzle 3-Hole Nozzle Part # SV4890 Part # SV4891 Part # SV5624 Part # SV5645 Brushes... -
Page 10: Indicators
Indicators Boiler Symbol Ø Will flash during warm-up and during use Ø Will stop flashing when the Blue Evolution is ready for use Steam Symbol Increase (+) or decrease (-) steam pressure by pressing and holding button on the console... -
Page 11: Trouble Shooting / Error Codes
The Blue Evolution powers ON after This is normal: plugging into the electrical outlet and Ø Push the ON/OFF Button on the console to power ON the Blue Evolution then turns OFF: The Blue Evolution should be the ONLY appliance plugged into the electrical... -
Page 12: Descaling
①The Blue Evolution must be cool and at room module on and off. temperature before descaling. ②Place the Blue Evolution on a flat surface and lock all 4 Briefl y press button + or on the side to vary suct power. - Page 13 ①Pour 1/3 of the descaling solution into the steam tank. ②Pour 1/3 of the descaling solution directly into the boiler tank. ③ Turn ON the Blue Evolution to pump the descaling solution into the boiler. It will take 40 seconds before you hear the alarm.
-
Page 14: Maintenance
Ø Clean by using air hose to blow out dirt and dust. Make sure both sides of the filter are clean Do not tilt or lay the Blue Evolution on its back or side. Doing so could cause damage and void the warranty. Accessory Cleaning... -
Page 15: Specifications
Specifications POWER SUPPLY 120 V. 60Hz READY TIME 10 MINUTES BOILER REFILL SYSTEM AUTOMATIC REFILL STEAM FLOW ADJUSTMENT 3 LEVELS / ADJUSTED ON CONSOLE PRESSURE 8 BAR / 117 PSI MAX TEMPERATURE 338 °F BOILER VOLUME 1/2 GALLON BOILER MATERIAL AISI 304 WATER TANK CAPACITY 1/2 GALLON –... - Page 16 Notices Read all instructions before using this steam cleaner. WARNING: STEAM GENERATED BY THE BLUE EVOLUTION IS EXTREMLY HOT AND MAY CAUSE INJURY IF THE STEAM COMES IN DIRECT CONTACT WITH THE SKIN OR EYES. USE AS ONLY AS DIRECTED BY THIS MANUAL AND ONLY AIM THE STEAM HANDLE AT THE CLEANING AREA.
-
Page 17: Warranty & Repair
All disputes arising out of or related to the warranty shall be governed by the laws of the State of Texas. In the event the customer and US Steam LLC are unable to resolve any customer dispute, and any collection action, suit, or other judicial proceeding is commenced, the prevailing party in any such action, suit, or proceeding shall be entitled to recover any cost and attorney fees incurred. - Page 18 Floors, Kitchen, Grills, & Bathrooms Restaurants The Blue Evolution will clean every area of your restaurant without chemicals. Patient Beds, Wheelchairs, & Curtains Hospitals Steam is a proven killer of virus and infection causing organisms. UV-C reduces airborne bacteria. Deli’s, Freezers & Butcher Grocery Chemical free cleaning in areas of food storage and preparation.
