Liquid Crystal Display Television
Service Manual
Chassis： MT5331
Product Type：LHD4007EU
Ver 1.0
Hisense Electric Co.，Ltd.
Aug. 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LHD4007EU and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hisense LHD4007EU

Summary of Contents for Hisense LHD4007EU

  • Page 1 Liquid Crystal Display Television Service Manual Chassis： MT5331 Product Type：LHD4007EU Ver 1.0 Hisense Electric Co.，Ltd. Aug. 2007...

  • Page 2: Table Of Contents

    7.5 Troubleshooting for TV/VGA/HDMI input...................- 38 - 7.6 Troubleshooting for YPbPr input....................- 39 - 7.7 Troubleshooting for Video/S-Video/Scart input ................- 40 - 8. Explode View and BOM..........................- 41 - 9. Schematic circuit diagram ........................- 42 - Hisense Confidential - 2 -...

  • Page 3: Service Manual

    WHEN REPLACEMENT PARTS ARE REQUIRED, BE SURE TO USE REPLACEMENT PARTS SPECIFIED BY THE MANUFACTURER. Proper service and repair is important to the safe, reliable operation of all Hisense Electric Co., Ltd Equipment. The service procedures recommended by Hisense and described in this Service Guide are effective methods of performing service operations.

  • Page 4: Warning

    LCD TV Service Manual not undertaken any such broad evaluation. Accordingly, a serviceman that uses a service procedure or tools, which are not recommended by Hisense, must first satisfy himself thoroughly that neither his safety nor the safe of the equipment will be jeopardized by the service method selected.
  • Page 5 Safety regulations require that after a repair the set must be returned in its original condition. In particular attention should be paid to the following points. -Note: The wire trees should be routed correctly and fixed with the mounted Hisense Confidential - 5 -...
  • Page 6 Confirm that the voltage has dropped to a safe level before disconnecting or connecting the connector. Hisense Confidential - 6 -...

  • Page 7: Notes

    • To prevent electric shock and breakage of PC board, start the servicing work at least 30 seconds after the main power has been turned off. Especially when installing and removing the power board, start servicing at least 2 minutes after the main power has Hisense Confidential - 7 -...
  • Page 8 • Do not stack the circuit boards. Failure to observe this precaution may result in problems resulting from scratches on the parts, the deformation of parts, and short-circuits due to residual electric charge. • Routing of the wires and fixing them in position must be done in accordance with Hisense Confidential - 8 -...
  • Page 9 The exclamation point within an equilateral triangle is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the set. Hisense Confidential - 9 -...

  • Page 10: Product Function Specifications

    LCD TV Service Manual 2. Product Function Specifications 2.1 Product Function Hisense Confidential - 10 -...
  • Page 11 LCD TV Service Manual Hisense Confidential - 11 -...

  • Page 12: Specifications

    Weight (gross) 30kg Allowable temperature of operation environment 0℃ to 40℃ ACCESSORIES Operating Instructions Remote Control Unit Power Lead Dry Cell Battery NOTE: Specifications and design are subject to possible modifications without notice due to improvements。 Hisense Confidential - 12 -...

  • Page 13: Lcd Panel Spec

    SPVA (Super Patterned Vertical Align ) mode Wide viewing angle(±178°) High speed response WXGA(1366×768 pixels) resolution (16:9) Low power consumption Direct Type 16 CCFTs (Clod Cathode Fluorescent Tube) DE(Data Enable) mode LVDS (Low Voltage Differential Signaling) interface (1 pixel/clock) Hisense Confidential - 13 -...
  • Page 14 LCD TV Service Manual Hisense Confidential - 14 -...

  • Page 15: Chassis Layout And Overall Wiring Diagrams

    4. Chassis Layout and Overall Wiring Diagrams 4.1 Chassis Layout Description Part No Type/Model Main BD 113578 RSAG2.908.1098-1\ROH Power BD 113197 RSAG2.908.982-3\ROH Scart BD 113544 RSAG2.908.1107\ROH Keypad PCA 112615 RSAG2.908.1030\ROH LED / IR Board 112829 RSAG2.908.1048\ROH Hisense Confidential - 15 -...

  • Page 16: Main Bd

    Buttons (connect key BD and main IR, LED TJC10-5A\ROH TJC10-14A\ROH 5V,12V power TJC10-4A\ROH Power 14V from power BD XP212 TJC3-4A\ROH Audio output TJC10-8A\ROH Video, S-video, Headphone out A2600WSO-2X9P\ROH Scart 2 A2600WSO-2X11P\ROH Scart 1 FF-HX19-10\ROH LVDS Hisense Confidential - 16 -...

  • Page 17: Wires And Cables Overall Wiring Diagrams

    TJC3H-4Y-800-600\ROH Main BD XP212<-->Speaker L/R Video input connection (Scart 1) HX-2022C500\ROH Main BD J38<-->XP0102 Video input connection (Scart 2) HX-2018C500\ROH Main BD J22<-->XP0101 Video input connection (video, TJC10T-8Y-500\ROH Main BD J19<-->XP2 s-video) and headphone output Hisense Confidential - 17 -...

  • Page 18: Factory/Service Osd Menu And Adjustment

    0-255 Brightness Red. Component1 0-255 Component2 0-255 HDMI1 0-255 HDMI2 0-255 G Gain CVBS 0-255 To adjust White Composite 0-255 Balance, High S-Video 0-255 Brightness Green. SCART1 0-255 SCART2 0-255 0-255 Component1 0-255 Component2 0-255 Hisense Confidential - 18 -...
  • Page 19 Brightness Green. Component1 0-255 Component2 0-255 HDMI1 0-255 HDMI2 0-255 B Offset CVBS 0-255 To adjust White Composite 0-255 Balance, Low S-Video 0-255 Brightness Blue. SCART1 0-255 SCART2 0-255 0-255 Component1 0-255 Component2 0-255 HDMI1 0-255 Hisense Confidential - 19 -...
  • Page 20 Item 备注 Jiangxi Road factory Zhong Shi Huangdao Industrial Park Huang Dao Gui Yang Industrial Park Gui Yang Liao Ning Industrial Park Liao Ning Hisense Hungary Hungary Hisense Australia Australia Hisense France France 5.2.3. Factory Option Item Default Options Note M-Can enter factory mode with factory RC or user RC.

  • Page 21: Designer Menu

    Default Value Default Item Range Note Warm Cool Cool CVBS 0-255 Composite 0-255 S-Video 0-255 SCART1 0-255 SCART2 0-255 R Gain 0-255 Component1 0-255 Component2 0-255 HDMI1 0-255 HDMI2 0-255 G Gain CVBS 0-255 Composite 0-255 Hisense Confidential - 21 -...
  • Page 22 0-1000 Brightness SCART2 0-1000 Min Brightness 0-1000 Component1 0-1000 Component2 0-1000 HDMI1 0-1000 HDMI2 0-1000 Brightness CVBS 0-1000 Mid Brightness Composite 0-1000 S-Video 0-1000 SCART1 0-1000 SCART2 0-1000 0-1000 Component1 0-1000 Component2 0-1000 HDMI1 0-1000 Hisense Confidential - 22 -...
  • Page 23 SCART2 0-1000 Mid Contrast 0-1000 Component1 0-1000 Component2 0-1000 HDMI1 0-1000 HDMI2 0-1000 CVBS 0-1000 Composite 0-1000 S-Video 0-1000 SCART1 0-1000 Contrast SCART2 0-1000 Max Contrast 0-1000 Component1 0-1000 Component2 0-1000 HDMI1 0-1000 HDMI2 0-1000 Hisense Confidential - 23 -...
  • Page 24 HDMI1 0-1000 1000 HDMI2 0-1000 Pictur CVBS Composite Composite Mode S-Video S-Video SCART1 SCART1 Display the current SCART2 SCART2 SOURCE source Component1 Component1 Component2 Component2 HDMI1 HDMI1 HDMI2 HDMI2 VIVID CVBS 0-100 Brightness of Vivid Hisense Confidential - 24 -...
  • Page 25 HDMI2 0-100 CVBS 0-100 Composite 0-100 S-Video 0-100 SCART1 0-100 SCART2 0-100 Brightness of STD Brightness mode 0-100 Component1 0-100 Component2 0-100 HDMI1 0-100 HDMI2 0-100 CVBS 0-100 Contrast of STD Contrast mode Composite 0-100 Hisense Confidential - 25 -...
  • Page 26 Composite 0-100 S-Video 0-100 SCART1 0-100 MOVIE SCART2 0-100 Contrast of Movie Contrast mode 0-100 Component1 0-100 Component2 0-100 HDMI1 0-100 HDMI2 0-100 MOVIE CVBS 0-100 Saturation of Movie Saturation mode Composite 0-100 S-Video 0-100 Hisense Confidential - 26 -...
  • Page 27 Think about the Volume Max 0-90 Audio out power before adjusting Standard, Music Audio Mode Speech, Music Different 120HZ -10-10 frequencies for Audio Mode 500HZ -10-10 different Audio 1.5kHZ -10-10 Mode 5kHZ -10-10 10kHZ -10-10 Hisense Confidential - 27 -...

  • Page 28: Software Upgrading

    TV’s RS232 port. For the first connecting, the pc will recognize and automatically install the USB device. The process is just like the installation of a mini disk, see the following picture. Hisense Confidential - 28 -...
  • Page 29 LCD TV Service Manual Hisense Confidential - 29 -...

  • Page 30: Upgrading With The Mtktool

    If following error appears, it means the related port is not be set properly. Ignore these errors, click “Confirm” and enter the MtkTool main interface, see the following picture. 1—Flash chip model (for LHD3233EU, it will be MT5331). 2—The port through which the PC communicate with the chip. Hisense Confidential - 30 -...
  • Page 31 LCD TV Service Manual 3—The communicating baud rate 4—The new program file (*.bin) for upgrading. 5—Click this button can select the *.bin file to be used for upgrading. 6—Click to start upgrading. Hisense Confidential - 31 -...
  • Page 32 If the flash chip does not support high speed transport, do not select this option; otherwise, reserve the selected mood. Click “Browse” button (5), find the upgrading program file, select it. Press “Upgrade” button and start upgrading. The following interface appears on the screen, indicating upgrading successfully. Hisense Confidential - 32 -...
  • Page 33 LCD TV Service Manual Hisense Confidential - 33 -...

  • Page 34: Troubleshooting

    Replace battery batteries Replace remote Replace RC control Check IR receiver Change Led Replace Led & IR BD & IR board Change Led Replace Led & IR cable & IR cable Replace main board Hisense Confidential - 34 -...

  • Page 35: Troubleshooting For Function Key

    LCD TV Service Manual 7.2 Troubleshooting for Function Key Buttons does not work Replace tact switch Check switches Replace Key BD Check key board Check Key BD cable Change Key BD Replace main board Hisense Confidential - 35 -...

  • Page 36: Tv Won't Power On

    Check/replace IR Only BD or Keypad one works Try Power on by Check signal RC and Button OSD? Source Neither Both works Work Replace Main Replace Main BD Power on Replace Panel Replace Power BD Hisense Confidential - 36 -...

  • Page 37: Troubleshooting For Audio

    LCD TV Service Manual 7.4 Troubleshooting for Audio No sound Reconnect Check connecter Replace speaker wire Check speaker wire Replace speaker set Check speaker set Replace main board Hisense Confidential - 37 -...

  • Page 38: Troubleshooting For Tv/Vga/Hdmi Input

    LCD TV Service Manual 7.5 Troubleshooting for TV/VGA/HDMI input No picture on the screen Check Signal Source Make sure signal source is available Reconnect Check connect Replace cable Check cable Replace main board Hisense Confidential - 38 -...

  • Page 39: Troubleshooting For Ypbpr Input

    LCD TV Service Manual 7.6 Troubleshooting for YPbPr input No picture on the screen Check Source Check Source Device work or not Reconnect Check connect Check Wires (Green Replace wires Blue, Red) Replace main board Hisense Confidential - 39 -...

  • Page 40: Troubleshooting For Video/S-Video/Scart Input

    LCD TV Service Manual 7.7 Troubleshooting for Video/S-Video/Scart input No picture on the screen Check Source Check Signal Source work or not Reconnect Check connect Check Cable/ Replace Cable/Wires Wires Check Scart Replace Scart BD Replace main board Hisense Confidential - 40 -...

  • Page 41: Explode View And Bom

    LCD TV Service Manual 8. Explode View and BOM Hisense Confidential - 41 -...

  • Page 43: Schematic Circuit Diagram

    LCD TV Service Manual 9. Schematic circuit diagram Hisense Confidential - 42 -...
  • Page 44 +14V MT5331RAV1.6 MT5331 (PBGA) REFERENCE DESIGN - 4 LAYERS +12V +14V 0R_NC 0R_NC R-RESC1608N-HX R-RESC1608N-HX 4PIN 2.0mm 4PIN 2.0mm 01. INDEX 0R_NC 0R_NC +12V R-RESC1608N-HX R-RESC1608N-HX 2,15,16,17 +12V 02. POWER 2,3,9,10,12,13,14,15,16,17 +5VSB 2,7,13 +5VSB DV33SB 03. TUNER 2,5,6,7,16,17 DV33SB DV33 2,5,6,7,9,15 DV33 +5V_P...
  • Page 45 150/2W 150/2W +12V +5V_TUNER or +12V AP1513/SOP-8 AP1513/SOP-8 3R3/2W 3R3/2W R-SOIC08N-1.270-6.00-HX R-SOIC08N-1.270-6.00-HX DV12 L1 FB L1 FB CB112 CB112 CB225 CB225 CE73 CE73 CB211 CB211 R-INDC2012N-HX R-INDC2012N-HX VOUT 0.1uF 0.1uF 0.1uF 0.1uF 220uF/16V 220uF/16V 0.1uF 0.1uF +5V_TUNER 27uH/POWER CHOKE 27uH/POWER CHOKE R-CAPC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX...
  • Page 46 +5V_TUNER +5V_TUNER +3V3_TUNER +3V3_TUNER 1,2,9,10,12,13,14,15,16,17 GPIO_4 GPIO_4 1,2,4,5,6,7,8,9,10,11,12,13,14,15,16,17 +5V_TUNER THOMSON COMBO-TUNER +5V_TUNER RF_AGC_IN RF_AGC_IN NS/FB NS/FB IF_AGC IF_AGC CE39 CE39 R-INDC2012N-HX R-INDC2012N-HX 0.1uF 0.1uF 4.7K 4.7K 4.7K 4.7K FAT_IN+ 10uF/16V 10uF/16V FAT_IN+ R-CAPC1608N-HX R-CAPC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX FAT_IN- R-CAPAE-D6.3X5.4-HX R-CAPAE-D6.3X5.4-HX FAT_IN- +5V_TUNER...
  • Page 47 FAT_IN- R-CAPC1608N-HX R-CAPC1608N-HX FAT_IN+ R-CAPC1608N-HX R-CAPC1608N-HX NS/220nH NS/220nH +5V_TUNER +5V_TUNER R-INDC2012N-HX R-INDC2012N-HX DV33_DM DV33_DM DV18_DM DV18_DM 1,2,3,5,6,7,8,9,10,11,12,13,14,15,16,17 NS/47pF NS/47pF R-CAPC1608N-HX R-CAPC1608N-HX 0.1uF 0.1uF 0.1uF 0.1uF GLOBAL SIGNAL R-CAPC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX MT5131_IF_AGC IF_AGC R-RESC1608N-HX R-RESC1608N-HX 10uF 10uF 47nF 47nF R-CAPC2012N-HX R-CAPC2012N-HX R-CAPC1608N-HX R-CAPC1608N-HX...
  • Page 48 R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX OPWRSB OPWRSB R207 75_NS R207 75_NS FB2_IN GPIO_79 ORESET# ORESET# GPIO_3 GPIO_80 OPCTRL0 OPCTRL0 GPIO_10 GPIO_10 OPCTRL1 OPCTRL1 RESERVE HEAT-SINK SPACE OPCTRL4 AV33 OPCTRL4 OPCTRL5 GPIO_4 OPCTRL5 DV26_DDR DV33 DV33 GPIO_4 1,2,6,7,9,15 DV33 AV33 OPCTRL7 2,6,10,11,12,14,17 AV33...
  • Page 49 DV33SB AV12 AV12 AV33 AV33 DV33 1,2,5,7,9,15 DV33 AVCC_SRV AVCC_HDMIPLL AVCC_ADCPLL AVCC_VAD0 AVCC_AADC AV33 2,10,11,12,14,17 AV33 FB/80OHM FB/80OHM 121PT 121PT DV26_DDR 2,5,8 DV26_DDR CB51 CB51 CB52 CB52 CB53 CB53 R-INDC1608N-HX R-INDC1608N-HX CB54 CB54 CB55 CB55 R-INDC3216N-HX R-INDC3216N-HX CB56 CB56 AV15 AV15 0.1uF 0.1uF...
  • Page 50 ORESET# DV33SB DV33 CB38 CB38 DV33 0.1uF 0.1uF R-CAPC1608N-HX R-CAPC1608N-HX R968 R968 820K 820K R-RESC1608N-HX R-RESC1608N-HX CE49 CE49 NS/4.7K NS/4.7K 220uF/16V 220uF/16V R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-CAPAE-D6.3X5.4-HX R-CAPAE-D6.3X5.4-HX ORESET# 10Kx4 10Kx4 OXTALI OXTALO GPIO_0 R-RESC1608N-HX R-RESC1608N-HX R-RESCA3216-8N-HX R-RESCA3216-8N-HX R-RESC1608N-HX R-RESC1608N-HX 2N3904 2N3904 27MHz...
  • Page 51 DV13_DDR DV13_DDR DV26_DDR DV26_DDR DV26_DDR DV26_DDR RWE# MEM_WE# MEM_RAS# RDQ0 47x4 47x4 MEM_DQ0 75x4 75x4 R-RESCA2010-8N-HX R-RESCA2010-8N-HX R-RESCA2010-8N-HX R-RESCA2010-8N-HX RCAS# MEM_CAS# MEM_CAS# RDQ1 MEM_DQ1 RRAS# MEM_RAS# MEM_WE# RDQ2 MEM_DQ2 RCS# MEM_CS# MEM_ADDR13 RDQ3 R-RESCA2010-8N-HX R-RESCA2010-8N-HX MEM_DQ3 R-RESCA2010-8N-HX R-RESCA2010-8N-HX MEM_DQ0 MEM_DQ15 MEM_DQ16 MEM_DQ31 DQ15...
  • Page 52 DV33 DV33 PDD3 PDCD1# PDA14 PDA18 CD1# PDD4 PODOUTDATA3 PDA15 PDA14POD PDA19 PODINDATA0 PDD5 PODOUTDATA4 PDA16 PODINCLK PDA20 PODINDATA1 PDD6 PODOUTDATA5 PDA17 PODINVALID PDA21 PODINDATA2 PDD7 PODOUTDATA6 PODINSYNC PDA22 PODINDATA3 PDCE1# PODOUTDATA7 PDA23 PODINDATA4 CE1# PDA10 PDCE2# PDA24 PODINDATA5 CE2# PDOE# PDVS1# PDA25...
  • Page 53 AV33 2,6,11,12,14,17 AV33 1,2,3,9,12,13,14,15,16,17 AGND_AFE 1,2,3,4,5,6,7,8,9,11,12,13,14,15,16,17 AGND_AFE S_Video input AV input NEARLY MT5331 AV_IN AV_IN S_R_IN CVBS2 CVBS2 R175 R175 NEARLY AV CONNECTOR NEARLY MT5331 AV_SY0_IN C686 C686 47nF 47nF C706 C706 R172 R172 47pF 47pF R-RESC1608N-HX R-RESC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX ECVAL160805E20100 ECVAL160805E20100 R969...
  • Page 54 SCT1_G_IN SCT1_G_IN SCT1_R_IN SCT1_R_IN AV5_scart_avout AV5_scart_avout R209 R209 1,2,3,4,5,6,7,8,9,10,12,13,14,15,16,17 R206 R206 SCT1_AVI_GND LOPIVA16G05A LOPIVA16G05A 15pF 15pF LOPIVA16G05A LOPIVA16G05A R-RESC1608N-HX R-RESC1608N-HX 15pF 15pF R-RESC1608N-HX R-RESC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX R-INDC1608N-HX R-INDC1608N-HX R-INDC1608N-HX R-INDC1608N-HX AGND_AFE 1,2,3,4,5,6,7,8,9,10,12,13,14,15,16,17 AGND_AFE SCT1_AV_IN SCT1_G_GND SCT1_R_GND SCT1_FB_IN AV_IN SCT1_G_IN AV33 SCT1_B_IN...
  • Page 55 AV5_scart_avout AV33 AV5_scart_avout AV33 2,6,10,11,14,17 AV33 1,2,3,9,10,13,14,15,16,17 R533 R533 4.7K 4.7K AGND_AFE 1,2,3,4,5,6,7,8,9,10,11,13,14,15,16,17 AGND_AFE SCT2_FB_IN SCT2_FS_IN R247 R247 ADIN1 R-RESC1608N-HX R-RESC1608N-HX R294 R294 FB2_IN R-RESC1608N-HX R-RESC1608N-HX NS/0 NS/0 R-RESC1608N-HX R-RESC1608N-HX R242 R242 R250 R250 R295 R295 SCT2_FB_IN ECVAL160805E20100 ECVAL160805E20100 ECVAL160805E20100 ECVAL160805E20100 4.7K 4.7K...
  • Page 56 1,2,3,9,10,12,14,15,16,17 +5VSB NEARLY VGA CONNECTOR NEARLY MT5331 1,2,7 +5VSB DV33SB 1,2,5,6,7,16,17 DV33SB AV33 2,6,10,11,12,14,17 AV33 R298 R298 C106 C106 +5VSB AGND_AFE 1,2,3,4,5,6,7,8,9,10,11,12,14,15,16,17 AGND_AFE R-RESC1608N-HX R-RESC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX R299 R299 C107 C107 RED_GND FB/80OHM FB/80OHM 10nF 10nF R-INDC1608N-HX R-INDC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-CAPC1608N-HX R-CAPC1608N-HX GRN_GND...
  • Page 57 CONTROL PINS I/O SELECTED HOT PLUG DETECT STATUS SCL_SINK HPD1 HPD2 HPD3 SDA_SINK LOPIVA16G05A LOPIVA16G05A RX0_2 R-INDC1608N-HX R-INDC1608N-HX SCL1 HPD_SINK LOPIVA16G05A LOPIVA16G05A RX0_2B A1/B1 R-INDC1608N-HX R-INDC1608N-HX RX0_2 SDA1 LOPIVA16G05A LOPIVA16G05A RX0_1 R-INDC1608N-HX R-INDC1608N-HX RX0_2B SCL2 HPD_SINK LOPIVA16G05A LOPIVA16G05A RX0_1B RX0_1 A2/B2 R-INDC1608N-HX R-INDC1608N-HX...
  • Page 58 GPIO_19 GPIO_19 +12V 1,2,16,17 +12V 1,2,3,9,10,12,13,14,16,17 DV33 1,2,5,6,7,9 DV33 R458 R458 VGAR_IN C148 C148 10uF 10uF R368 R368 OPCTRL7 GPIO_19 1,2,3,4,5,6,7,8,9,10,11,12,13,14,16,17 R-RESC1608N-HX R-RESC1608N-HX NS/1K NS/1K R316 R316 VMIDDAC VGAL_IN C149 C149 10uF 10uF R369 R369 R370 R370 R-RESC1608N-HX R-RESC1608N-HX R313 R313 R-RESC1608N-HX R-RESC1608N-HX...
  • Page 59 +12V DV33SB 1,2,5,6,7,17 DV33SB R402 R402 R418 R418 47K/NC 47K/NC R-RESC1608N-HX R-RESC1608N-HX OPAVREF 1,2,3,9,10,12,13,14,15,17 R-RESC1608N-HX R-RESC1608N-HX OPAVREF +12V 1,2,15,17 +12V FB/80OHM FB/80OHM DV33 1,2,5,6,7,9,15 DV33 R-INDC1608N-HX R-INDC1608N-HX R407 R407 CE106 CE106 C130 C130 CE107 CE107 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,17 470uF/25V 470uF/25V NS/ZENER/6.2V NS/ZENER/6.2V 10uF/25V 10uF/25V R-RESC1608N-HX...
  • Page 60 DV33_DM DV33_DM AV33 2,6,10,11,12,14 AV33 +12V 1,2,15,16 +12V 1,2,3,9,10,12,13,14,15,16 +5VSB 1,2,7,13 +5VSB AGND_AFE 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 AGND_LVDS 1,2,3,4,5,6,7,8,9,10,11,12,13,14,15,16 +12V R453 R453 R440 R440 R441 R441 R452 R452 0/NS 0/NS 0/NS 0/NS R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX R-RESC1608N-HX CK1P CK1P CK1N CK1N GPIO_10 GPIO_10...
