Rotel RCC-1055 Command List

Table: RCC 1055 Waveform format expected:
•
For units BEFORE serial # 077-7121001 (Black) or 977-7121001 (Silver):
Baud Rate Parity
2400
•
For units AFTER serial # 077-7121001 (Black) or 977-7121001 (Silver):
Baud Rate Parity
9600
Table: RCC 1055 expected format of a request by RS 232 controller:
Start Count Device ID
0xFE 0x03 0xB0
Table 1: Type 10 Primary Command List
NOTE: The values in the table below show the exact byte sequence of all requests. The device
will expect the bytes only - no spaces, no delimiter, etc. The controlling device may implement its
own method to download each command sequence. The numerical values in the first column are
Hexadecimal.
RCC 1055 HEX
FE 03 B0 10 00 C3
FE 03 B0 10 01 C4
FE 03 B0 10 02 C5
FE 03 B0 10 03 C6
FE 03 B0 10 04 C7
FE 03 B0 10 07 CA
FE 03 B0 10 09 CC
FE 03 B0 10 1D E0
FE 03 B0 10 1F E2
FE 03 B0 10 0D D0
FE 03 B0 10 19 DC
FE 03 B0 10 1B DE
FE 03 B0 10 11 D4
FE 03 B0 10 15 D8
FE 03 B0 10 17 DA
FE 03 B0 10 12 D5
FE 03 B0 10 16 D9
FE 03 B0 10 0A CD
FE 03 B0 10 0B CE
FE 03 B0 10 0E D1
FE 03 B0 10 0F D2
FE 03 B0 10 10 D3
FE 03 B0 10 13 D6
FE 03 B0 10 1A DD
FE 03 B0 10 1E E1
RCC 1055
RS232 Controller Command List
Valid Data Bits
N 8
Valid Data Bits
N 8
Type Key
0x10 0xXX
Command
Random
Repeat
Time
Program
Scan
Review
1
2
3
4
5
6
7
8
9
10
+10
Search <<
Pause
Track |<<
Stop
Open / Close
Play
Track >>|
Search >>
Stop Bit Value Handshaking
1
Stop Bit Value Handshaking
1
Checksum
0xXX
Command Description
Random
Repeat
Time
Program
Scan
Review
1
2
3
4
5
6
7
8
9
10
+10
Search <<
Pause
Track |<<
Stop
Open / Close
Play
Track >>|
Search >>
Data Type
None String
Data Type
None String
