OPERATOR'S
MANUAL
BIG VAC
Models 72-000-A
Starting Serial # 72001
May, 2001
SMITHCO PRODUCT SUPPORT
1-800-891-9435
Hwy SS and Poplar Avenue, Cameron WI 54822
E-mail: productsupport@smithco.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 72-000-A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Smithco 72-000-A

  • Page 1 OPERATOR’S MANUAL BIG VAC Models 72-000-A Starting Serial # 72001 May, 2001 SMITHCO PRODUCT SUPPORT 1-800-891-9435 Hwy SS and Poplar Avenue, Cameron WI 54822 E-mail: productsupport@smithco.com...
  • Page 2: Table Of Contents

    CONTENTS Introduction ... 1-10 Introduction ... 1-8 Introduction ... 1 Symbols ... 2-3 Safe Practices ... 4 PTO Safety Warnings ... 5 Specifications ... 6 OPtional Equipment ... 6 Setup ... 7 Overloading Debris Hopper and Vacuum Housing Wear ... 7 Controls &...
  • Page 3: Introduction

    Thank you for purchasing a Read this manual and all other manuals pertaining to the Big Vac carefully as they contain safety, operating, assembly and maintenance instructions. Failure to do so could result in personal injury or equipment damage. Keep manuals in a safe place after operator and maintenance personnel have read them. Right and left sides are from the operator’s seat, facing forward.
  • Page 4: Symbols

    SYMBOLS Read Operator’s Manual Engine - Stop Engine Oil Glow Plug - On Hour Meter Hand Throttle Park Brake Off / Stop Electrical Power Engine - Start Temperature Light Gasoline Glow Plug - Off Hour Meter Choke - Closed Park Brake Release On / Start No Electrical...
  • Page 5: Symbols

    Up/Down Arrow No Smoking Pinch Point Hydraulic Fluid Penetration Engage Ground Speed High Reverse Down/Lower Moving Parts Step Lift Arm Disengage Fast Neutral SYMBOLS Up/Raise Manual Operation Hot Surface Tractor Slow Forward Warning Danger Caution...
  • Page 6: Safe Practices

    14. Never carry passengers. 15. Use parts and materials supplied by SMITHCO only. Do not modify any function or part. 16. Avoid sharp turns. Watch the tires of the tractor while turning to make sure they do not contact the tongue of the Big Vac.
  • Page 7: Pto Safety Warnings

    10. Regularly test driveline guards by spinning or rotating them to ensure the have not become stuck to the shaft. 11. Always use the driveline recommended for your machine. Never switch drivelines among different ma- chines. 12. Reduce PTO shaft abuse by observing the following: a.
  • Page 8: Specifications

    SPECIFICATIONS FOR BIG VAC WEIGHTS AND DIMENSIONS Length 180" (458 cm) Width 84" (214 cm) Height 87" (221 cm) Weight 3500 lb (1588 kg) SOUND LEVEL At Ear Level 92 dB (Use ear protection while operating) PTO SHAFT Maximum RPM TIRES &...
  • Page 9: Setup

    4. Collection of aerifier cores causes extreme wear on the liner (and if unchecked, on the housing). 5. Caution users that, while Smithco Sweeper-Vacs do an excellent job collecting cores, the lining (and the housing) will wear quickly in such use.
  • Page 10: Controls & Instruments

    CONTROLS & INSTRUMENTS Hopper Lever - The hopper lever is used to lift and lower the hopper which also opens and closes the tailgate. Refer to decal for direction. B. Finger Reel Off-On Valve - Turns the reel on or off. Refer to decal for direction.
  • Page 11: Service

    Before operating this machine, become familiar with all controls and functions of this unit and the tow vehicle. Also complete all maintenance requirements and read all safety warnings. By knowing both machines thor- oughly, how it operates and by doing the prescribed maintenance steps, you can expect relatively trouble-free operation for years to come.
  • Page 12: Diagrams

    HYDRAULIC DRAWING...
  • Page 13: Hydraulic Parts List

    REF# PART# 72-079 18-276 60-215 60-334 72-096 34-058 72-065 72-040 72-040-01 72-040-02 72-064 72-070 72-071 10-187 14-273 72-022 78-219-01 78-219-02 72-073 72-044 72-045 72-072 18-170 78-219 78-219-01 78-219-02 72-075 72-074 72-043 72-046 HRR-150 72-068 72-074 72-067 72-063 33-066 72-069 78-416 72-062 72-021 72-021-01...
  • Page 14: Other

    (Full address of the manufacture - authorized representative established in the Community must also give the business name and address of the manufacture) declare under our sole responsibility, that the product Big Vac / 72-000-A (Make, Model) to which this declaration relates corresponds to the relevant basic safety and health requirements of the Direc-...
  • Page 15: Limited Warranty

    Batteries. Wheels and tires. A copy of the warranty for the above items is furnished if necessary with each SMITHCO product. Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitations of incidental or consequential damages, so the above limitations or exclusions may not apply to you.
