Summary of Contents for EIJKELKAMP Scuba Blue Green Algae Buoy
- Page 1 Scuba Blue Green Algae Buoy Water quality meter for blue and green algae User manual Meet the difference Royal Eijkelkamp +31 313 880 200 Nijverheidsstraat 9, 6987 EN info@eijkelkamp.com M-181150E royaleijkelkamp.com © 2023-05 Giesbeek, the Netherlands...
-
Page 2: Table Of Contents
Royal Eijkelkamp. Technical data can be amended without prior notification. Royal Eijkelkamp is not responsible for (personal) damage due to (improper) use of the product. Royal Eijkelkamp is interested in your reactions and remarks about its products and operating instructions. -
Page 3: On These Operating Instructions
Royal Eijkelkamp, inadequate maintenance, other abuse and damage due to transport are not covered by the warranty. Royal Eijkelkamp can never be held liable for direct and/or indirect consequential damage resulting from defects or faults in the equipment supplied by Royal Eijkelkamp. -
Page 4: Limitations Of Use
The Scuba BGA buoy measures the following parameters: Green algae via chlorophyll-a (RFU or µg/l) „ Blue algae (cyanobacteria) via phycocyanin (RFU or µg/l) „ Turbidity (NTU) „ Ambient light (PAR = Photosynthetically Active Radiation) „ Water temperature (Celsius or Fahrenheit) „... -
Page 5: Product Overview
2.3 Product overview The drawing shows the dimensions of the buoy in inches. Parts of the buoy: 1. Attachement ring 2. Wiper 3. Ring for protection of wiper 4. Solar cell 5. Power button 6. Sticker with serial number and bar code 7. -
Page 6: Technical Specifications
Push button and green LED lamp * Photosynthetically Active Radiation ** The buoy can work for 2 to 3 weeks without sunlight from 100% battery capacity 2.5 Accessories For the buoy, the accessories below are available at Royal Eijkelkamp. Article number Accessory 181170 Accessory set for BGA Buoy, set to protect and anchor Scuba BGA buoy. -
Page 7: Installation
Scuba BGA buoy. The Scuba BGA buoy must be attached via a secondary ‘counterweight’ or via a ring buoy (‘Life Ring’). These can be supplied by Royal Eijkelkamp as the 181170 Accessory set BGA. 3.2.2. Installation accessory set-BGA Choose this option when waves from boats or wind may be higher than 12 inches or 30 cm, or if you do not know the wave status. -
Page 8: Enabling Buoy
LED with your finger so that you can see that the dot turns on or off. 3.4 Access to data The webportal can be reached at algae.royaleijkelkamp.com „ Enter the login information provided by Royal Eijkelkamp for your account „ To reset your account information, contact Royal Eijkelkamp „... -
Page 9: Web Portal For Data Presentation
Web portal for data presentation The webportal shows a dashboard that contains the following items: Device data (device name, online status, signal strength, battery status) „ Map with location (map, satellite, location pointer, streetview) „ Weather forecast (current, 5 day forecast) „... -
Page 10: Maintenance
The lithium ion battery pack in the Scuba BGA buoy is charged by the solar panel and has a life time of 3 years. If the battery is not chargeable anymore, you have to send the buoy for service to Royal Eijkelkamp to change the battery. -
Page 11: Calibration By Field Measurement
Note: the dashboard in our webportal allows you to use any measurement unit you have from another source. In this way, the sensors has been corrected for the local conditions and species of chlorophyll-a and phycocyanin. Royal Eijkelkamp’s Youtube channel has an instructional video on how to calibrate the sensor with a field measurement. -
Page 12: Performing The Calibration
Prepare the Calibration Standard Solution: „ Pour accurately 2 ml of the Rhodamine WT 2.5% solution into the 400 ml beaker ƒ Fill the beaker with DI water till 400 ml ƒ Mix it thoroughly to obtain a solution which is 125 mg/l. ƒ... -
Page 13: Customer Service Contact Information
6.3 Customer service contact information If after reading this manual you still have questions about buoy maintenance or calibration, please feel free to contact us at: Royal Eijkelkamp, Service Department T: +31 313 800 200 E: service@eijkelkamp.com I: royaleijkelkamp.com/nl/service-verhuur/ 7. Storage and transportation 7.1 Storage... -
Page 14: Appendix 1: Certificate
Appendix 1: Certificate To be defined. -
Page 15: Appendix 2: Technical Specifications Rhodamine Wt Dye
Appendix 2: Technical specifications Rhodamine WT dye WATER TRACING DYE FWT RED PRODUCTS Division of Kingscote Chemicals ® TECHNICAL DATA BULLETIN Bright Dyes FWT Red products are proprietary formulations of Rhodamine dyes. Our Bright Dyes FWT Red liquid products are specially formulated versions of Rhodamine WT dye for convenient use in water tracing and leak detection studies. -
Page 16: Appendix 3: Msds Rhodamine Wt Dye
Appendix 3: MSDS Rhodamine WT dye Safety Data Sheet Issue Date: 30-May-2013 Revision Date: 18-Jan-2019 Version Number: 2.2 1. Identification Product Identifiers Product Name: Bright Dyes® FWT Red 25 Liquid Product Number: 106023 Recommended Use & Restrictions on Use Water tracing & leak detection dye Manufacturer/Supplier Kingscote Chemicals, Inc. - Page 17 Bright Dyes® FWT Red 25 Liquid Revision Date: 18-Jan-2019 Ingestion Rinse mouth. DO NOT induce vomiting. Drink plenty of water. Never give anything by mouth to an unconscious person. Get medical attention if large quantities were ingested or if nausea occurs. Most Important Symptoms and Effects Symptoms Will cause staining of the skin on contact.
- Page 18 Bright Dyes® FWT Red 25 Liquid Revision Date: 18-Jan-2019 Conditions for Safe Storage, Including Incompatibilities Storage Conditions Keep container tightly closed and store in a cool, dry, and well- ventilated area. Keep from freezing. Incompatible Materials No materials to be especially mentioned 8.
- Page 19 Bright Dyes® FWT Red 25 Liquid Revision Date: 18-Jan-2019 10. Stability and Reactivity Reactivity Not reactive under normal conditions. Chemical Stability Stable under recommended storage conditions. Possibility of Hazardous Reactions None under normal processing. Conditions to Avoid Keep separated from incompatible substances. Keep out of reach of children. Incompatible Materials No materials to be especially mentioned Hazardous Decomposition Products...
- Page 20 Bright Dyes® FWT Red 25 Liquid Revision Date: 18-Jan-2019 12. Ecological Information Ecotoxicity This product is not classified as environmentally hazardous. However, this does not exclude the possibility that large or frequent spills can have a harmful or damaging effect on the environment. Component Information Not available Persistence/Degradability...
- Page 21 Bright Dyes® FWT Red 25 Liquid Revision Date: 18-Jan-2019 SARA 313 Section 313 of Title III of the Superfund Amendments and Reauthorization Act of 1986 (SARA). This product does not contain any chemicals which are subject to the reporting requirements of the Act and Title 40 of the Code of Federal Regulations, Part 372.
