EIJKELKAMP Aquameter Series Instruction Manual

Multiparameter water quality meters, probes, utilities & accessories
Table of Contents

Advertisement

P.O. Box 4, 6987 ZG Giesbeek
Nijverheidsstraat 30,
6987 EM Giesbeek,
The Netherlands
T +31 313 880 200
E info@eijkelkamp.com
I
www.eijkelkamp.com
Instruction Manual
for the
TM
Aquameter
Series
Multiparameter Water Quality
Meters, Probes, Utilities & Accessories
(Software Version 3.00 and above including Optical DO & Depth Measurement)
Document No. 10401-00188
Revision: M
Date: February 16, 2011
M185701E

Advertisement

Table of Contents

Troubleshooting

loading
Need help?

Need help?

Do you have a question about the Aquameter Series and is the answer not in the manual?

Questions and answers

Summary of Contents for EIJKELKAMP Aquameter Series

  • Page 1 P.O. Box 4, 6987 ZG Giesbeek Nijverheidsstraat 30, 6987 EM Giesbeek, The Netherlands T +31 313 880 200 E info@eijkelkamp.com www.eijkelkamp.com Instruction Manual for the Aquameter Series Multiparameter Water Quality Meters, Probes, Utilities & Accessories (Software Version 3.00 and above including Optical DO & Depth Measurement) Document No.
  • Page 2 Aquameter™ Series Instruction Manual 10401-00188 Rev M PROPRIETARY NOTICE The information disclosed within this document or separately supplied in furtherance of this document includes proprietary rights of Aquaread Ltd. Neither this document nor the information disclosed herein or of a supplementary nature shall be reproduced or transferred to other documents or used for any other purposes, except as specifically authorised in writing by Aquaread Ltd.
  • Page 3: Table Of Contents

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Table of Contents 1. INTRODUCTION................................6 2. WHAT’S IN THE BOX?..............................6 2.1. T AQUAMETER ........................6 AND THE NVIRONMENT 2.2. T ..........................7 QUAPROBE AND THE NVIRONMENT 2.3. A ..............................7 BOUT THE ROBE LEEVE 2.4. P ............................7 ROTECTIVE LEEVE...
  • Page 4 Aquameter™ Series Instruction Manual 10401-00188 Rev M 13.5. E .............................28 RRORS URING ALIBRATION 13.6............................28 LECTRODE FFICIENCY 13.7. C ORP..............................29 ALIBRATING 13.8. C ORP R ....................31 ONVERTING EADINGS TO THE YDROGEN CALE 14. DO/EC ELECTRODE CALIBRATION AND MAINTENANCE................32 14.1. R DO/EC E .........................32 ECOGNISING THE...
  • Page 5 Aquameter™ Series Instruction Manual 10401-00188 Rev M 19. LIMITED WARRANTY.............................56 19.1. C ............................57 LEANING RIOR ETURN 19.2. D ..........................57 ECONTAMINATION ERTIFICATE 20. TROUBLESHOOTING...............................58 21. DECLARATION OF CONFORMITY........................59 22. APPENDIX 1. THE TECH BEHIND AQUAREAD’S OPTICAL DO MEASUREMENT SYSTEM....60 22.1. P .............................60 RINCIPLE OF PERATION...
  • Page 6: Introduction

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 1. Introduction This manual covers the setup, operation, calibration and maintenance of the full Aquameter series of Meters, Aquaprobes and the associated AquaLink PC software. Depending upon the model of Meter and Probe you are using, some of the functions described may not be available.
  • Page 7: The Aquaprobe And The Environment

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 2.2. The Aquaprobe and the Environment The Aquaprobe is designed to be fully submerged in water and is rated to IP68, that is to say, it is rated for continual immersion to a depth of 10 meters. 2.3.
  • Page 8: Battery Installation And Care

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 3. Battery Installation and Care The Aquameter requires five AA size batteries. To install the batteries, loosen the two screws on the centreline of the rear of the meter and remove the battery compartment lid. Following the battery polarity markings inside the battery compartment, insert five AA cells then replace the compartment lid and tighten the screws.
  • Page 9: Overview Of The Operating System

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 4. Overview of the Operating System The operating software in the Aquameter has been designed for simple, intuitive use. Similarly, a great deal of development work has been put into simplifying and automating the calibration procedures in the Aquameter in order to allow normal field operatives (as opposed to trained lab technicians) to achieve quick and accurate results.
  • Page 10: Connecting An Aquaprobe

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 5. Connecting an Aquaprobe The Aquameter is designed to operate in conjunction with any one of eight different Aquaprobes (each variant is considered in later sections). To connect an Aquaprobe, align the key slot of the Aquaprobe plug with the Aquameter socket, then press the plug into the socket and tighten the retaining collar.
  • Page 11: What Does It All Mean

    Aquameter™ Series Instruction Manual 10401-00188 Rev M SAL:03.57 PSU   SSG:01.3σt  TURB:12.3 NTU GPS:3D Pos    BARO:1013mb DEPTH:15.75m Hit [OK] to zero GPS:3D Pos    Lat:N51°21.498 Long:E001°24.323 Alt:00050M 1013mb Sats in use:09   6.1.
  • Page 12: Trend Indication

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Items in the Units column marked with an asterisk (*) can be selected as alternative units of measurement in the Settings Menu (see section 9: Setting Units of Measurement). Items in the Units column marked with a dagger ( ) are auto-ranging, i.e.
  • Page 13: Gps Reception

    Aquameter™ Series Instruction Manual 10401-00188 Rev M During calibration of the DO electrode, variations due to temperature and air pressure are automatically compensated for. During the measurement of DO, temperature, air pressure and salinity are automatically compensated for. During calibration of the ORP electrode, the variation in the calibration buffer solution due to temperature is automatically corrected for.
  • Page 14: Depth Measurement (Ap-1000 Only)

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 7. Depth Measurement (AP-1000 only) Depth is measured in the Aquaprobe AP-1000 by a pressure sensor mounted inside the body of the probe. The exact position of the sensor is 150mm (6”) up from the bottom edge of the sleeve.
  • Page 15: Memory Mode

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 8. Memory Mode 8.1. Manually Saving Readings When you are happy that the readings are stable, press the M+ key to snapshot the readings along with the time, date, GLP (calibration) data and position (GPS models only). As each reading is saved, a numeric memory location ‘Tag’...
  • Page 16: Clearing The Memory

    Aquameter™ Series Instruction Manual 10401-00188 Rev M GLP DATA pH7.00 [31/Jan/09] pH4.01 [07/Feb/09] [09/Feb/09] This tells you that the last successful calibration, prior to the recorded reading being taken, was January 31 for the pH 7.00 point, February 7 for the pH 4.01 point and February 9 for ORP.
  • Page 17: Important Information About Memory Mode

    Aquameter™ Series Instruction Manual 10401-00188 Rev M You can cancel Auto Data Logging at any time by going back into the screen above and setting the Status to OFF. Auto Data Logging will also be cancelled if you switch the Meter off.
  • Page 18: Setting Units Of Measurement

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 9. Setting Units of Measurement To alter the way the Aquameter displays readings, press the MENU key to get to the Main Menu, then choose Settings. The Settings Menu will be displayed. Settings Menu Units ...
  • Page 19 Aquameter™ Series Instruction Manual 10401-00188 Rev M Finally, this screen allows you to set the factor that the Meter uses to calculate Total Dissolved Solids from Specific EC. This is the TDS Fact: (TDS = EC x TDS Fact) and can be set anywhere between 0.00 and 1.00.
  • Page 20: Rapidcal Calibration Method

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 10. RapidCal Calibration Method 10.1. About Calibration Calibration is a very important part of successful water quality measurement and should be carried out regularly as detailed in each separate section of this manual. A great deal of development work has been put into simplifying and automating the calibration procedures in the Aquameter in order to allow normal field operatives (as opposed to trained lab technicians) to achieve quick and accurate results.
  • Page 21 Aquameter™ Series Instruction Manual 10401-00188 Rev M Calibration RapidCal  DO 100% Full Cal 6. Select RapidCal. The screen will change to: PLEASE WAIT Stabilising 000% The Meter will wait until all readings are stable, then it will send the RapidCal command to the Probe, where the calibration takes place.
  • Page 22: Calibration Error Codes

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 10.3. Calibration Error Codes If the Aquameter detects a problem with either the Aquaprobe or the calibration solution during the calibration procedure, an error will be indicated accompanied by an error code number. The chart below shows the possible errors and how to correct them. Error Code Problem Action...
  • Page 23: Calibration Data Storage

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Move the cursor arrow to the electrode you want to reset, then press the MR key. A confirmation screen will be displayed. Are you sure you want to restore the factory calibration values? [ESC]=NO If you are sure, press the OK key.
  • Page 24: After Use

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 11. After Use The Sleeve on the Aquaprobe is made in two parts, which separate by unscrewing to allow cleaning of the individual electrodes. After every use, remove the protective Sleeve End Cap (if fitted) then unscrew the lower half of the sleeve as shown.
  • Page 25: General Probe Maintenance

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 12. General Probe Maintenance Each Aquaprobe is constructed with a two-part protective aluminium sleeve surrounding the more delicate sensing electrodes. To gain full access to the individual electrodes for periodic maintenance and thorough cleaning, first unscrew the lower half of the sleeve. Next, remove the four small black countersunk screws from around the top of the upper sleeve, then gently slide the upper sleeve off the Probe body being careful not to damage the individual electrodes.
  • Page 26: Ph/Orp Electrode Calibration And Maintenance

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 13. pH/ORP Electrode Calibration and Maintenance 13.1. Recognising the pH/ORP Electrode The pH, ORP and combined pH/ORP electrodes are easy to recognise because they are the only electrodes that are not black. These electrodes have a clear, gel filled body. 13.2.
  • Page 27: Calibrating Ph

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 13.4. Calibrating pH pH electrodes should be calibrated fully at least once a week to ensure optimum accuracy. Full calibration involves calibrating at pH 7.00 first, then at pH 4.01. Although the Aquaprobe allows only two point pH calibration, the pH electrodes are extremely linear and once calibrated, will read accurately over the full range of 0 –...
  • Page 28: Errors During Calibration

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Select pH7.00. The screen will change to: PLEASE WAIT Stabilising 000% The Meter will wait until the readings are stable, then it will send the calibration command to the Probe, where the calibration takes place. During calibration, the Calibrating screen is displayed and the progress counter counts up.
  • Page 29: Calibrating Orp

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Never place the entire Aquaprobe in methyl alcohol, as this will cause irreparable damage to the DO/EC electrode. Damaged caused in this way is not covered by the warranty. If the methyl alcohol rinse does not restore the electrode, perform the following actions: Remove the electrode from the body again.
  • Page 30 Aquameter™ Series Instruction Manual 10401-00188 Rev M Ensure the temperature of the solution is between 5ºC and 40ºC (41ºF - 104ºF). Press the MENU key then select Calibration. The following screen will be displayed. Calibration RapidCal  DO 100% Full Cal Select Full Cal.
  • Page 31: Converting Orp Readings To The Hydrogen Scale

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 13.8. Converting ORP Readings to the Hydrogen Scale Electrochemical measurements are ultimately referred to the so-called hydrogen scale, the convention for which is that the electrochemical potential of a hydrogen electrode in contact with hydrogen gas at one atmosphere partial pressure and a solution containing hydrogen ions at unit activity is zero at all temperatures.
  • Page 32: Do/Ec Electrode Calibration And Maintenance

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 14. DO/EC Electrode Calibration and Maintenance 14.1. Recognising the DO/EC Electrode The DO/EC electrode is easy to recognise because it has a screw-on cap and four stainless-steel EC sensor contacts on the side (see photograph). Dissolved Oxygen (DO) is measured at the end of the electrode by the components behind the removable cap.
  • Page 33: Calibrating The Do Zero Point

    Aquameter™ Series Instruction Manual 10401-00188 Rev M If you are going to calibrate both the Zero and 100% points at the same time, ALWAYS calibrate the Zero point first, then the 100% point. To calibrate the DO/EC electrode follow these steps: 14.5.
  • Page 34: Calibrating The Do 100% Saturation Point In Moist Air

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Calibrating 100% Press [OK] When calibration is complete, press the OK key then the ESC key repeatedly to return to normal operating mode. If a problem occurs during calibration, an error message will be displayed. Refer to Calibration Error Codes in section 10 for error message handling.
  • Page 35: Replacing The Optical Do Cap

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 2. Unscrew the DO Membrane cap from the end of the DO/EC electrode by rotating it anti-clockwise. 3. Gently brush away any scaly grey deposits from the coiled wire section of the electrode with a soft toothbrush, taking care not to damage the coil in the process. After removing the deposits, rinse the electrode with DO Electrode Filling Solution.
  • Page 36 Aquameter™ Series Instruction Manual 10401-00188 Rev M 14.9. Calibrating EC EC calibration is always carried out at a single point. There is a choice of three single points. These are: 1413µS/cm, 2570µS/cm (using Aquaread RapidCal solution) and 12,880µS/cm. These values have been chosen to allow accurate readings to be taken in a variety of water types.
  • Page 37: Verifying Ec Calibration

    Aquameter™ Series Instruction Manual 10401-00188 Rev M The dates shown to the right of the screen are the dates of the last successful calibration. The value shown on the bottom line next to ‘EC’ is the value the EC electrode was last calibrated to.
  • Page 38: Errors During Calibration

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Remove the probe from the calibration bottle, shake it off, then reinsert. Press the ESC key repeatedly to get back to the Main Menu. Go into settings and make sure EC is set to read with reference to 25ºC. If it’s not, set it that way.
  • Page 39: Turbidity Electrodes Calibration And Maintenance

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 15. Turbidity Electrodes Calibration and Maintenance Turbidity is measured by the Aquaprobe using a dual electrode, optical, Nephelometric technique in accordance with ISO 7027, which uses Formazin as a reference standard. The Aquameter displays turbidity in Nephelometric Turbidity Units (NTU) which are nominally equivalent to Formazin Turbidity Units (FTU).
  • Page 40: Calibrating The Turbidity Electrodes

    Aquameter™ Series Instruction Manual 10401-00188 Rev M The lens system in the Turbidity Electrodes is designed to focus correctly in water. When the Probe is not submerged, the system will be out of focus and random readings will occur. This is normal. The Probe sleeve forms an integral part of the turbidity measurement system.
  • Page 41: Verifying Turbidity Zero Point Calibration

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Select Turb. The screen will change to: Calibration Zero? [01/Jan/09]  1000? [01/Jan/09] The dates shown to the right of the screen are the dates of the last successful calibration. Select Zero. The screen will change to: PLEASE WAIT Stabilising 000%...
  • Page 42: Alibrating The Urbidity 1000 Ntu Point

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 15.6. Calibrating the Turbidity 1000 NTU Point Remove the Probe from the calibration bottle, rinse thoroughly in fresh water (if using RapidCal solution), shake off any excess and dry the outer sleeve with a soft cloth. Gently invert, do not shake, a bottle of StablCal...
  • Page 43: Lens Maintenance

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 15.10. Lens Maintenance On a monthly basis, the lenses on the Turbidity Transmitter and Receiver electrodes should be wiped over with a soft damp cloth and non-abrasive detergent. Always re-calibrate after cleaning the electrodes. 15.11.
  • Page 44: Aqualink Pc Software

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16. AquaLink PC Software AquaLink is a utility program designed to run under Microsoft ® Windows ® ® , Vista ® or 7 on a stand-alone PC with a minimum screen resolution of 800 x 600, a CD drive and an available USB 2.0 socket.
  • Page 45: Uploading Data From Your Aquameter

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.4. Uploading Data From Your Aquameter Ensure your Aquameter has batteries installed but is switched off. Connect the Aquameter to your PC using the USB cable supplied. The Aquameter should switch itself on automatically and display ‘USB CONNECTED’...
  • Page 46: Ph/Orp Electrode Data Logged Using An Ap-700 - Ap-1000

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.6. pH/ORP Electrode Data Logged Using an AP-700 - AP-1000 If your data was logged using an AP-700, AP-800, AP-900 or AP-1000, all the boxes within the pH/ORP group will be populated as shown in the example above. 16.7.
  • Page 47: Exporting Text Reports

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.12. Exporting Text Reports To export a text report, first fill in the boxes in the group marked Report Header on the left of the screen. This information will be used at the beginning of your report. Next, click on the ‘Export as Text Report’...
  • Page 48: Typical Text Report Cover Page

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.13. Typical Text Report Cover Page AquaLink REPORT ---------------------------- File name: C:\Test\3 day test 024690136.txt Operator name: G.E.M. Company name: Aquaread Ltd Site name: Test Site 4 Start date and time: 24-Jul-2009 10:09:33 Start position: Lat: N 51°21.4989' Lon: E 001°24.3232' OSGB: TR 370 677 End date and time:...
  • Page 49: Exporting Excel Files

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.14. Exporting Excel ® Files ® To export an Excel file, click on the ‘Export as Excel File’ button. You will be asked to ® specify a file name. A .xls extension will automatically be added. Excel files are exported in a Tab delimited text format.
  • Page 50 Aquameter™ Series Instruction Manual 10401-00188 Rev M 1. Click on ‘File’. 2. Select ‘Open’ from the list. 3. Browse for the file you exported from AquaLink, and select it. You will now be able to view your data overlaid on Google™ Earth Satellite images. Each data point is represented by a yellow pushpin, and all the data points are listed in a column on the left of the screen.
  • Page 51: Google™ Examples

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 16.18. Google™ Examples The following two images show the same logged data displayed first in Google™ Maps, then in Google™ Earth. The data displayed on Google™ Maps is useful, but for real detail, Google™ Earth is the answer. Zooming in on the satellite photos in Google™...
  • Page 52: Specification

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 17. Specification 17.1. METERS (V3.XX software) Meter Model AQUAMETER-200™ AQUAMETER-100™ Dimensions (W x H x D) 90mm x 180mm x 39mm (3.5” x 7” x 1.5”) 90mm x 180mm x 39mm (3.5” x 7” x 1.5”) Weight (including 450g (15.9oz) 440g (15.5oz)
  • Page 53: Probes Specific

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Probe Model 17.4. PROBES SPECIFIC Range 0 – 1000 NTU 2 Auto-range scales: 0.0 - 99.9 NTU, ● ● ● ─ ● ─ ● ─ ● ─ Turbidity Resolution 100 - 1000 NTU Repeatability ±...
  • Page 54: Part Numbers

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 18. Part Numbers 18.1. Aquameters & Aquaprobes Item No. Name Description GPS Aquameter shipped complete with 5AA Alkaline Cells, Lanyard, USB cable, AM-200 GPS AQUAMETER 'Getting Started' cards and CD containing AquaLink software, USB drivers and full Manual.
  • Page 55: Accessories

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 18.2. Accessories Flow Cell Flow-through Cell Heavy duty Flow-Through Cell (can be used with any model Aquaprobe) EX- 5 Extension Cable 5 Meter Aquaprobe extension cable (connectors submersible to 10m). EX-10 Extension Cable 10 Meter Aquaprobe extension cable (connectors submersible to 10m).
  • Page 56: Limited Warranty

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 19. Limited Warranty All Aquaread Meters are guaranteed for three years, Probes, Flow-Through Cells and individual electrodes are guaranteed for one year from date of purchase against defects in workmanship and materials when used for their intended purpose and maintained according to instructions.
  • Page 57: Cleaning Prior To Return

    Aquameter™ Series Instruction Manual 10401-00188 Rev M If the repair is not covered by the warranty, you will be given an estimate for the costs of repair and return carriage. Upon receipt of payment, your equipment will be repaired and returned.
  • Page 58: Troubleshooting

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 20. TROUBLESHOOTING This section details some of the common difficulties you may encounter when using the Aquameter, Aquaprobes and AquaLink software. Try all the suggested remedies. If your problem is still unresolved, contact our Service Department (service@aquaread.co.uk). Problem Cause / Remedy The Aquameter will not...
  • Page 59: Declaration Of Conformity

    Aquameter™ Series Instruction Manual 10401-00188 Rev M Troubleshooting Continued … Problem Cause / Remedy pH and/or ORP readings  The electrodes may need re-calibrating. Recalibrate. are slow, inaccurate or  The electrodes may need cleaning. Clean as described in the unstable or calibration is relevant section of this manual.
  • Page 60: Appendix 1. The Tech Behind Aquaread's Optical Do Measurement System

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 22. Appendix 1. The Tech Behind Aquaread’s Optical DO Measurement System 22.1. Principle of Operation The Aquaread™ AquaPlus™ Optical DO measurement system works on the principle of Dynamic Luminescence Quenching. A gas-permeable chemical known as a luminophore is excited with short bursts of blue light, which causes molecules in the luminophore to emit red photons.
  • Page 61: Sensor Cap Life

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 22.2. Sensor Cap Life All optical dissolved oxygen sensors work on the same principle, and all must have the sensor cap containing the luminophore replaced periodically due to a phenomenon known as photo bleaching. When a sensor cap is new, the luminophore will return a large number of red photons when excited.
  • Page 62: Appendix 2. Flow Through Cell

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 23. Appendix 2. Flow Through Cell 23.1. Introduction The Aquaread Flow Through Cell (Flowcell) is designed for use with any model of Aquaread Aquaprobe and most third party pumping device. The Flowcell allows sample water to flow up through the Aquaprobe, passing over all the individual electrodes simultaneously.
  • Page 63: Operation

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 23.5. Operation Connect the Flowcell to a pumping device so that sample water enters at the bottom and exits at the top. Adjust the flow rate so that there is no visible turbulence or cavitation within the Flowcell.
  • Page 64: Appendix 3. Probe Hanger

    Aquameter™ Series Instruction Manual 10401-00188 Rev M 24. Appendix 3. Probe Hanger Aquaprobes can be used with up to 100m of cable. When using long cable lengths, especially down boreholes, it is advisable to support the Probe on a separate steel cable using a Probe Hanger.
