Becker P5/16PRF+ Assembly And Operating Instructions Manual

Roller shutter drives with integrated radio receiver

Advertisement

Quick Links

P5/16PRF+ - P9/16PRF+
Assembly and Operating Instructions
en
Roller Shutter Drives
with integrated radio receiver
Important information for:
• Fitters
• Electricians
• Users
Please forward accordingly!
These instructions must be kept for future reference.
Becker-Antriebe GmbH
35764 Sinn/Germany
www.becker-antriebe.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P5/16PRF+ and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Becker P5/16PRF+

  • Page 1 P5/16PRF+ - P9/16PRF+ Assembly and Operating Instructions Roller Shutter Drives with integrated radio receiver Important information for: • Fitters • Electricians • Users Please forward accordingly! These instructions must be kept for future reference. Becker-Antriebe GmbH 35764 Sinn/Germany www.becker-antriebe.com...
  • Page 2: Table Of Contents

    Assembly and Operating Instructions Table of Contents General ..................................2 Warranty ..................................3 Safety Information ................................3 Intended Use .................................. 5 Mounting and installation instructions ..........................5 Programming the switching times ........................... 13 Deleting the switching times ............................13 Technical Data ................................14 What should you do, if...? ...............................
  • Page 3: Warranty

    Warranty Structural modifications and incorrect installation which are not in accordance with these and our other instructions can result in serious injuries, e.g. crushing of limbs. Therefore, structural modifications should only be carried out with our prior approval and in accordance with our instructions, particularly the information contained in these Assembly and Operating Instructions. Any further processing of the products which does not comply with their intended use is not permitted.
  • Page 4 • The drive must not be carried by the mains connecting cable. • Drives with a H05VV-F connecting cable may only be used indoors. • To connect the drive to the driven part, solely mechanical accessory components from the current Becker product catalogue may be used.
  • Page 5: Intended Use

    Other applications, utilisation and modifications are not permitted in order to protect the safety of the users and others, since these actions can impair the system’s safety, resulting in personal injuries and property damage. Becker-Antriebe shall not accept liability for damages arising from such actions. Always observe the information in these instructions when operating or repairing the system.
  • Page 6 Assembly and Operating Instructions To install the drive, the following instructions must be followed carefully: Drive adapter safety catch • Mounting the drive adapter with safety catch: Self-locking hole The insert direction for the drive adapter is determined by the drive adapter type (shape).
  • Page 7 Action Response 1) Connecting the tubular drive 1) +2a) Connect the tubular drive to the power supply and open the battery compart- ment of the hand-held transmitter. 2) Activating tubular drive learn mode 2a) Activating the tubular drive learn mode by switching on the power sup- Switch on the power supply.
  • Page 8 Assembly and Operating Instructions 5) Setting the end limits Note The end limits can only be set via the master transmitter. The axle direction setting must be correct. When the end limits are being set, the tubular drive remains in lock-in mode. The lower end limit must always be programmed first.
  • Page 9 Action Response to 5d) Anti-lifting device at the lower limit to upper stopper Adjust the shutters until they are in the The tubular drive switches off automati- lower limit position. cally. Then adjust the shutters up towards the The tubular drive switches off automati- permanent upper stopper.
  • Page 10 Assembly and Operating Instructions Action Response 7) Deleting end limits Note The end limit settings can only be deleted via the master trans- mitter. 7a) Deleting the end limits individually Adjust the shutter into the end limit po- sition to be deleted. First press and hold the learn button.
  • Page 11 Action Response 9) Ventilation position Note This function is used to move your roller shutters from the lower end limit upwards in order to open the ventilation slats. The ven- tilation position can only be set after the two end limits have been set.
  • Page 12 Assembly and Operating Instructions Action Response 11) Deleting transmitters 11a) 11a) Deleting transmitters individually Note The master transmitter which was programmed in point 3) cannot be deleted. It can only be overwritten (see Point 12). Press the learn button on the master The tubular drive makes a “clack”...
  • Page 13: Programming The Switching Times

    Note This function is only available with the transmitters MemoControl MC441, MC411, MC441-II and MC411-II from the Becker Centronic range of control units. When both or individual limit positions are deleted, this set function is deleted as well. Every tubular drive can store switching times for one UP and one DOWN command.
  • Page 14: Technical Data

    Assembly and Operating Instructions Technical Data Type P5/16PRF+ P5/20PRF+ P9/16PRF+ Nominal torque (Nm) Output speed (min Limit switch range 64 revolutions Mains voltage 230 V AC / 50 Hz Power consumption (W) Nominal current consumption (A) 0,36 0,47 0,47 Operating mode S2 4 Min.
  • Page 15: What Should You Do, If

    What should you do, if...? Malfunction Cause Solution Tubular drive is not running. 1. No transmitter has been programmed. 1. Programme new transmitter. 2. Transmitter is outwith the range of the 2. Move transmitter into the range of the tubular drive. tubular drive.
  • Page 16: Brief Instructions Commissioning Prf

    Assembly and Operating Instructions Brief instructions commissioning PRF+ Caution Always adhere to the information contained in the assembly and operating instructions during commission- ing, operation and repair work. The manufacturer or supplier shall not accept liability for personal injuries, property damage or consequential damages resulting from non-adherence to the instructions. 1.
