V-440HD Ver.2.07 Additional Functions
The following functionality has been added in version 2.07 of the V-440HD.
V-LINK transmission is supported.
The audio input level of the M-400 RSS live mixing console can be controlled from the V-440HD.
Please go to MIDI Set up and turn 14-5. "V-Link switch" on or use below
V-440HD
* Up to eight channels can be controlled.
* Refer to the M-400 Owner's Manual for details on operation.
* The M-400 is controlled by transmitting V-LINK messages (system exclusive data set 1) from the V-440HD. The parameters received
by the M-400 in this case are listed below.
■ V-LINK (Model ID=00H 51H)
* Addresses marked with "#" are received as two bytes, with the data divided into upper byte (upper 3 bits) and lower byte (lower 7 bits).
Example: If the original data is 028AH, a value of 05H is transmitted as the first byte. A value of 0AH is transmitted as the second byte.
* Where "---" appears for the value, it means that the M-400 does not have a corresponding parameter.
+---------------+-------------------------------------------------------+
|Start Address
|Description
+---------------+-------------------------------------------------------+
|10H 00H 00H
|V-LINK System Common Preference Area
|20H 00H 00H
|V-LINK Video System Performance Area
|20H 20H 00H
|V-LINK Audio Mixer Parameter Area
+---------------+-------------------------------------------------------+
System Common Preference Area
+--------------+------------------------------------+-----------------------+--------------------------------+
|Address
|Parameter Name
+--------------+------------------------------------+-----------------------+--------------------------------+
|10H 00H 00H
|V-LINK Enabled
|10H 00H 01H
|V-LINK MIDI Rx Channel (Clip)
|10H 00H 02H
|V-LINK MIDI Rx Channel (Color)
|10H 00H 03H
|V-LINK Note Message Enabled
|10H 00H 04H
|V-LINK Fast Control Enabled
|10H 00H 05H
|V-LINK MMC Control Mode
|10H 00H 06H
|V-LINK MTC Control Mode
|10H 00H 07H
|V-LINK Auto Mix Mode
+--------------+------------------------------------+-----------------------+--------------------------------+
Video System Performance Area
+--------------+------------------------------------+-----------------------+--------------------------------+
|Address
|Description
+--------------+------------------------------------+-----------------------+--------------------------------+
|20H 00H 00H
|V-LINK Number of Video Mixer Inputs |---
+--------------+------------------------------------+-----------------------+--------------------------------+
Audio Mixer Parameter Area
+--------------+------------------------------------+-----------------------+--------------------------------+
|Address
| Description
+--------------+------------------------------------+-----------------------+--------------------------------+
|#20H 20H 00H
|V-LINK Audio Mixer Master Level
|#20H 21H 00H
|V-LINK Audio Mixer Channel1 Level
|#20H 21H 02H
|V-LINK Audio Mixer Channel2 Level
|#20H 21H 04H
|V-LINK Audio Mixer Channel3 Level
|#20H 21H 06H
|V-LINK Audio Mixer Channel4 Level
|#20H 21H 08H
|V-LINK Audio Mixer Channel5 Level
|#20H 21H 0AH
|V-LINK Audio Mixer Channel6 Level
|#20H 21H 0CH
|V-LINK Audio Mixer Channel7 Level
|#20H 21H 0EH
|V-LINK Audio Mixer Channel8 Level
+--------------+------------------------------------+-----------------------+--------------------------------+
The MIDI button can now be used to turn V-LINK mode on/off.
In the menu item "14-1. MIDI Sw Mode," the value of the setting has changed from "V-LINK Indicator" to "V-LINK Sw."
If you choose "V-LINK Sw," you'll be able to use the MIDI button to turn V-LINK mode on/off.
V-440HD version 2.0 Owner's Manual; p. 65
Parameters
14- 1.
MIDI Sw Mode
The RGB input supports 1080/59.94i, 1080/50i, 720/59.94p, and 720/50p.
* The above signals can be input if you choose "Auto" as the setting for "Format Auto Detect" in the "2. HD/RGB Input" menu.
Improvements in version 2.07
• We have fixed the problem that had caused the setting of the OUTPUT button to fail to be transmitted correctly via MIDI at startup.
• We have fixed the problem in which the Key Assign setting was not remembered in note mode.
Copyright © 2007 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND CORPORATION.
V-440HD
V-LINK
MIDI OUT
MIDI cable
|Sys.Ex.Value
|00H - 01H
|---
|---
|---
|---
|---
|---
|---
|Sys.Ex.Value
|Sys.Ex.Value
|---
|0000H-0768H
|0000H-0768H
|0000H-0768H
|0000H-0768H
|0000H-0768H
|0000H-0768H
|0000H-0768H
|0000H-0768H
Explanation
MIDI button function
function to turn V-Link on.
MIDI IN
|
|
|
|
|Meaning of Value
|OFF, ON
|---
|---
|---
|---
|---
|---
|---
| Meaning of Value
|---
| Meaning of Value
|---
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
| Level 0.0 - 100.0%
Values
Details
MIDI In/Out Sw
Turns MIDI message reception on/off.
V-LINK Sw
Turns V-LINK mode on/off.
*
4
0
7
8
M-400
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
40782934
2
9
3
4
-
0
1
*
1N
