- Page 1 ATX-M-CC462-T6 Industrial Micro-ATX Carrier for COM Express Type 6 Modules Product Manual WINSYSTEMS, Inc. | 2890 112th Street, Grand Prairie, Texas 75050 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 Copyright 2023, WINSYSTEMS, Inc. No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WINSYSTEMS, Inc. The information in the document is subject to change without notice. The information furnished by WINSYSTEMS, Inc.
-
Page 3: Table Of Contents
ATX-M-CC462-T6 Table of Contents Before You Begin........... 5 1.1 Warnings . - Page 4 ATX-M-CC462-T6 6.5.12 J17 - Audio I/O............18 6.5.13 J33 - eDP Interface .
-
Page 5: Before You Begin
ATX-M-CC462-T6. Functionality The ATX-M-CC462-T6 is an industrial Micro-ATX small form factor Type 6 reference carrier board designed to fully support WINSYSTEMS' COMeT6- 1100 COM Express Type 6 Compact modules as well as third-party Type 6 Compact and Basic form factor modules. -
Page 6: Features
ATX-M-CC462-T6/Features Features The ATX-M-CC462-T6 provides the following features. Carrier reference board Compatibility for: • COM Express Type 6 compact module • COM Express Type 6 basic module • 3x DisplayPort • 1x VGA (header) (COM option) • 1x eDP (population option on the COMET10-1100) •... -
Page 7: System Block Diagram
The board also includes expansion capabilities via one PCIe x16 and two PCIe x4 connectors. The ATX-M-CC462-T6 is a fully production ready platform and is a versatile and easily configured solution with customizable COM module, storage, and I/O options to suit the industrial use case. With design details available, the ATX-M-CC462-T6 is also an excellent reference design and evaluation carrier board for WINSYSTEMS Type 6 COM Express modules. -
Page 8: Specifications
ATX-M-CC462-T6/Specifications Specifications The ATX-M-CC462-T6 adheres to the following specifications and requirements. Feature Specification Electrical Power input 24 pin and 4 pin ATX 2.x power supply connections Models ATX-M-CC462-T6 Mechanical Dimensions 9.6 x 9.6 in. (243.84 x 243.84 mm) (Mini-ITX) Weight 14.4 oz. -
Page 9: Configuration
ATX-M-CC462-T6/Configuration Configuration This section describes the ATX-M-CC462-T6 components and configuration. Component Layout 6.1.1 Top View Expansion slots Ethernet Audio USB 3 USB 2 DisplayPort POST CODE display COMeT6 LVDS Battery External battery USB 2 SATA USB 3 System interface UART multi-protocol... - Page 10 ATX-M-CC462-T6/Configuration Item Description Reference Electrical Power button page 14 System reset button page 14 Sleep button page 15 Internal coin cell battery page 15 Case Fan-1 connector page 15 Case Fan-2 connector page 15 COMe module fan connector page 15...
-
Page 11: Configuration And Installation
ATX-M-CC462-T6/Configuration Configuration and Installation When installing a Type 6 COM module onto a compatible COM Express Type 6 carrier board, follow the instructions below to ensure that there is no damage to the COM module or the carrier board. Avoid electrostatic discharge (ESD) Only handle the circuit board and other bare electronics when electrostatic dis- charge (ESD) protection is in place. -
Page 12: Jumpers
ATX-M-CC462-T6/Configuration Jumpers 6.3.1 JP1 - Backlight Power Do NOT install jumpers 1 - 2 and 3 - 4 at the same time. Do NOT install jumpers 7 - 8 and 9 - 10 at the same time. NOTE Layout and Pin Reference... -
Page 13: Jp4 - Power Mode Jumper
ATX-M-CC462-T6/Configuration 6.3.3 JP4 - Power Mode Jumper Layout and Pin Reference Diagram Selection 1 - 2 AT mode 2 - 3 ATX mode (default) 6.3.4 JP5 - Carrier Configuration Layout and Pin Reference Diagram Selection 1 - 2 SPI_Enabled (default: open) -
Page 14: Led Indicators
6.5.1 SW1 - Power Button The ATX-M-CC462-T6 turns on automatically when power is applied to the computer and does not require the power button to be pressed. The power button can be used to wake the computer after shutdown, sleep, or system standby if power is not removed. -
Page 15: Sw3 - Sleep Button
6.5.4 B1 - Internal Coin Cell Battery The ATX-M-CC462-T6 accepts an external battery at J26 or an internal coin cell battery at B1. Battery input is configured using jumper JP3. See “JP3 - External/Internal Battery Connector” on page 12. -
Page 16: J25 - Come Module Power +12V Required
Molex Mini-Fit Jr. receptacle housing Part number: 39012040 6.5.7 J26 - External Battery Connector An external battery connected to the ATX-M-CC462-T6 provides standby power for the real-time clock. An extended temperature lithium battery is available from WINSYSTEMS, part number BAT-LPC-BR2330. -
Page 17: J27 - Atx Power Connector 24-Pin
Molex Mini-Fit Jr. receptacle housing Part number: 39012040 6.5.9 J10, J11, J12, J13 - SATA-0, 1, 2, 3 The ATX-M-CC462-T6 supports four SATA 3 (6 Gbps) interface. 6.5.10 J3, J4, J5 - Display Ports Standard full-size 20-pin DisplayPort (version 1.2). -
Page 18: J6 - Dual Channel Lvds Interface
LVDS data B0- Ground 6.5.12 J17 - Audio I/O Three 1/8th in. (3.5 mm) HD audio jacks are provided. The Type 6 module supports HD audio signals to the ATX-M-CC462-T6, which provides a Realtek ALC888S-VD HD audio codec. Audio Connectors Number... -
Page 19: J33 - Edp Interface
ATX-M-CC462-T6/Configuration 6.5.13 J33 - eDP Interface The ATX-M-CC462-T6 supports one embedded DisplayPort (eDP) interface. The eDP and LVDS interfaces cannot be used at the same time. The COMe module dictates which interface is being used. eDP configuration options are available via jumper JP1 on page 13. -
Page 20: J35 - Vga Connector
ATX-M-CC462-T6/Configuration 6.5.14 J35 - VGA Connector Layout and Pin Reference Diagram Selection Selection VGA_RED VGA_GRN VGA_BLUE HSYNC VSYNC DDC_DAT DDC_CLK Connector • Molex Milli-Grid header, shrouded with locking window Part number: 87832-1420 Matching Connector • Molex Milli-Grid receptacles (with locking ramp) -
Page 21: J1 - Com Express Ab Connectortype 6 Rev 3.0
ATX-M-CC462-T6/Configuration 6.5.16 J1 - COM Express AB ConnectorType 6 Rev 3.0 Layout and Pin Reference Row A Diagram Description Description Description USB_6_7_OC# LVDS_A2+/eDP_TX0+ GBE0_MDI3- USB4- LVDS_A2-/eDP_TX0- GBE0_MDI3+ USB4+ LVDS_VDD_EN GBE0_LINK100# LVDS_A3+ GBE0_LINK1000# USB2- LVDS_A3- GBE0_MDI2- USB2+ GBE0_MDI2+ USB_23_OC# LVDS_A_CK+/eDP_TX3+ GBE0_LINK#... - Page 22 ATX-M-CC462-T6/Configuration Layout and Pin Reference Row B Diagram Description Description Description USB_45_OC# LVDS_B2+ GBE0_ACT# USB5- LVDS_B2- ESPI_CS0#/LPC_FRAME# USB5+ LVDS_B3+ ESPI_IO_0/LPC_AD0 LVDS_B3- ESPI_IO_1/LPC_AD1 USB3- LVDS_BKLT_EN ESPI_IO_2/LPC_AD2 USB3+ ESPI_IO_3/LPC_AD3 USB_0_1_OC# LVDS_B_CK+ ESPI_ALERT0#/LPC_DRQ0# USB1- LVDS_B_CK- ESPI_ALERT1#/LPC_DRQ1# USB1+ LVDS_BKLT_CTRL ESPI_CK/LPC_CLK ESPI_EN# VCC_5V_SBY USB_HOST_PRSNT VCC_5V_SBY...
-
Page 23: J2 - Com Express Cd Connector
ATX-M-CC462-T6/Configuration 6.5.17 J2 - COM Express CD Connector Layout and Pin Reference Row C Diagram Description Description Description DDI3_DDC_AUX_SEL PEG_RX7- DDI3_PAIR0+ USB_SSRX0- DDI3_PAIR0- RSVD USB_SSRX0+ PEG_RX8+ DDI3_PAIR1+ PEG_RX8- USB_SSRX1- DDI3_PAIR1- USB_SSRX1+ DDI3_HPD PEG_RX9+ RSVD PEG_RX9- USB_SSRX2- DDI3_PAIR2+ RSVD USB_SSRX2+ DDI3_PAIR2-... - Page 24 ATX-M-CC462-T6/Configuration Layout and Pin Reference Row D Diagram Description Description Description RSVD PEG_TX7- DDI2_PAIR0+ USB_SSTX0- DDI2_PAIR0- RSVD USB_SSTX0+ PEG_TX8+ DDI2_PAIR1+ PEG_TX8- USB_SSTX1- DDI2_PAIR1- USB_SSTX1+ DDI2_HPD PEG_TX9+ RSVD PEG_TX9- USB_SSTX2- DDI2_PAIR2+ RSVD USB_SSTX2+ DDI2_PAIR2- RSVD PEG_TX10+ USB_SSTX3- DDI2_PAIR3+ PEG_TX10- USB_SSTX3+ DDI2_PAIR3-...
-
Page 25: J7 - Pcie Gen4 Connector 164Pos
ATX-M-CC462-T6/Configuration 6.5.18 J7 - PCIE GEN4 Connector 164POS Layout and Pin Reference Row A Diagram Description Description Description PRSNT1# HSIp(3) HSIn(9) +12V HSIn(3) +12V Reserved HSIp(10) Reserved HSIn(10) Ground HSIp(4) HSIn(4) HSIp(11) +3.3V HSIn(11) +3.3V PERST# HSIp(5) HSIn(5) HSIp(12) REFCLK+... - Page 26 ATX-M-CC462-T6/Configuration Layout and Pin Reference Row B Diagram Description Description Description +12V +12V PWRBRK# HSOp(10) +12V PRSNT2# HSOn(10) SMCLK HSOp(4) SMDAT HSOn(4) HSOp(11) HSOn(11) +3.3V TRST# HSOp(5) +3.3Vaux HSOn(5) HSOp(12) WAKE# HSOn(12) CLKREQ# HSOp(6) HSOp(0) HSOn(6) HSOp(13) HSOn(0) HSOn(13) PRSNT2#...
-
Page 27: J8, J9 - Pcie Gen4 Connector 64Pos
ATX-M-CC462-T6/Configuration 6.5.19 J8, J9 - PCIE GEN4 Connector 64POS Layout and Pin Reference Row A and B Mating Row A Description Row B Description PRSNT1# +12V +12V +12V +12V +12V SMCLK SMDAT 3.3V +3.3V TRST# +3.3V +3.3Vaux PERST# WAKE# CLKREQ#... -
Page 28: J15 - Usb4/Usb5 2.0 2X Front Panel
ATX-M-CC462-T6/Configuration 6.5.21 J15 - USB4/USB5 2.0 2x Front Panel The Type 6 module supports four USB 2.0 ports to the ATX-M-CC462-T6, which provides two USB 2.0 ports to J15 and two USB 2.0 ports to each Mini-Card #1-3. These ports supply 500 mA maximum continuous current and 480 Mbps transfer speed. -
Page 29: J23 - Multi-Protocol Carrier Serial Port
Molex Milli-Grid receptacles with center polarization key and locking ramps Part number: 51110-2051 6.5.25 J23 - Multi-Protocol Carrier Serial Port The Type 6 module supports an LPC bus to the ATX-M-CC462-T6, which provides two RS232/422/485 serial ports via on-board multi-protocol transceivers. Layout and Pin Reference... - Page 30 ATX-M-CC462-T6/Configuration • A momentary switch that shorts pins 7 and 8 together on J31 activates the system reset input. • A momentary switch that shorts pins 9 and 10 together on J31 acti- vates the sleep input. Layout and Pin Reference...
-
Page 31: J32 - Usb3 3.2 Gen1 2X Header
Molex Milli-Grid receptacles with center polarization key and locking ramps Part number: 51110-2051 Accessories and Cables WINSYSTEMS cables and batteries simplify connection to the ATX-M- CC462-T6. The following table lists available items. Go to www.winsystems.com for more information on WINSYSTEMS cables and batteries. - Page 32 ATX-M-CC462-T6/Accessories and Cables Item Part Number Connection Description Com module COMET6-1115GRE-8IL Type 6 COM interface Intel Core-I3, 32 GB DDR, LVDS, INDUSTRIAL TEMP Cable TCBL-DP-6A J3, J4, J5-DisplayPort DISPLAY PORT CABLE, 6 FT Cable CBL-234-G-1-1.375B J35-VGA ROHS CABLE 14 POS, 2.0 MM TO 15...
-
Page 33: Best Practices
CC462-T6. Measuring it at the power supply does not account for voltage drop through the wire and connectors. The ATX-M-CC462-T6 has two power connectors at J25 and J27. A standard ATX power supply is required to power the board. Power Harness Minimize the length of the power harness. - Page 34 Do not bend or flex the ATX-M-CC462-T6—Bending or flexing can cause irreparable damage. Embedded computer modules are especially sensitive to flexing or bending around ball grid array (BGA) devices. BGA devices are extremely rigid by design, and flexing or bending the v1.0...
- Page 35 Conformal Coating Applying conformal coating to a WINSYSTEMS product does not in itself void the product warranty, if it is properly removed prior to return. Coating can change thermal characteristics and impedes our ability to test, diagnose, and repair products.
- Page 36 Contact an applications engineer—If a diagram or chart in a manual does not seem to match your board, or if you have additional questions, contact a WINSYSTEMS applications engineer at +1-817-274-7553. v1.0 www.winsystems.com Page 36...
-
Page 37: Mechanical Drawings
ATX-M-CC462-T6/Mechanical Drawings Appendix B. Mechanical Drawings ATX-M-CC462-T6 Mechanical Drawings v1.0 www.winsystems.com Page 37... -
