- Page 1 SYS-ITX-P-3800 Pico-ITX Intel ® Atom™ E3800 Embedded Computer in Aluminum Enclosure with Dual 10/100/1000 Ethernet, USB, COM Product Manual WinSystems, Inc. | 715 Stadium Drive, Arlington, Texas 76011 | 817-274-7553 | info@winsystems.com | www.winsystems.com...
- Page 2 No part of this document may be copied or reproduced in any form or by any means without the prior written consent of WinSystems, Inc. The information in the document is subject to change without notice. The information furnished by WinSystems, Inc. in this publication is believed to be accurate and reliable.
-
Page 3: Table Of Contents
SYS-ITX-P-3800 Table of Contents Before You Begin ......... 5 Warnings . - Page 4 SYS-ITX-P-3800 BIOS Functionality ........20 General Information .
-
Page 5: Before You Begin
Before You Begin Review the warnings in this section and the best practice recommendations (see “Best Practices” on page 35) when using and handling the WinSystems SYS-ITX-P-3800. Following these recommendations provides an optimal user experience and prevents damage. Read through this document and become familiar with the SYS-ITX-P-3800 before proceeding. -
Page 6: Features
Intel’s 7th generation (Gen 7) graphics and media encode/decode engine supports DirectX*11, OpenGL 3.0 (OGL 3.0), OpenCL 1.2 (OCL 1.2), and OpenGLES 2.0. Considering the small size of the SYS-ITX-P-3800, it is packed with I/O features often lacking from larger single board computers. It includes dual 10/100/1000 Ethernet controllers based on the Intel i211 family with wake on LAN and PXE capabilities, connectivity and controlling network devices. - Page 7 SYS-ITX-P-3800/Features • Full-HD and 3D graphics acceleration BIOS • Insyde UEFI BIOS Video Interfaces • VGA output Ethernet • Two Intel 10/100/1000 Mbps controllers using Intel i211-AT Storage • One full-size PCIe Mini Card slot for mSATA (shared with internal SATA connector) •...
-
Page 8: General Operation
The following figure is a simplified system block diagram of the SYS-ITX-P-3800. The SYS-ITX-P-3800 features the Intel Atom (Bay Trail) dual core or quad core system on chip (SOC). Its robust design, small size, and extended operational temperature make it ideal for use in industrial IoT applications and embedded systems for industrial controls, transportation, Mil/COTS, and energy markets. -
Page 9: Specifications
The SBC is software-compatible with Windows 10, Windows 10 IoT Enterprise, and Windows 10 IoT Core, as well as Linux, and some real-time operating systems. Drivers are available from the WinSystems website. Specifications The SYS-ITX-P-3800 adheres to the following specifications and requirements. Table 1: SYS-ITX-P-3800 specifications Electrical +12V DC... -
Page 10: Configuration
SYS-ITX-P-3800/Configuration Configuration This section describes the SYS-ITX-P-3800 connectors and configuration. Component Layout 7.1.1 Rear Connectors LAN2 LAN1 10/100/1000 10/100/1000 Analog VGA COM1 COM port +12V DC Ethernet 2 Ethernet 1 USB2 USB 2.0 USB1 USB 2.0 v1.0 www.winsystems.com Page 10... -
Page 11: Internal Connectors
SYS-ITX-P-3800/Configuration 7.1.2 Internal Connectors USB3 USB4 +12V DC USB 2.0 USB 2.0 JCMOS Clear CMOS Mini Card mSATA (selectable) USB/I BATT CMOS battery connector SATA1 Serial ATA (on back side) C bus PWROUT Mini Card COM4 COM3 COM2 AUDIO Line-in/... -
Page 12: Watchdog Timer (Wdt)
WinSystems supports the SYS-ITX-P-3800 WDT in the System Management tools for the SYS-ITX-P-3800. Ask your sales representative for details of this software package. -
Page 13: Pwrout - Dc+12V/+5 Voltage Power Output (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.3 PWROUT - DC+12V/+5 Voltage Power Output (Internal Connector) PWROUT: +12V/+5V DC voltage output 4 pin (2.0 mm) connector Layout and Pin Reference pin 1 Description +12V Matching Connectors • JST B4B-PH-KL Cable Housing • JST PHR-4 7.4.4 FPH - Front Panel Pin Header (Internal Connector) FPH: Front panel header 2x5 pin (2.0 mm) connector... -
Page 14: Audio - Audio Interface (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.5 AUDIO - Audio Interface (Internal Connector) AUDIO: Line-out/line-in/mic-in/SPDIF-out 2x5 pin (2.0 mm) connector Layout and Pin Reference pin 1 Description Description Line-out-R MIC-IN Line-in-R SPDIF-OUT Line-in-L Line-out-L MIC-IN Matching Connectors • JST B10B-PHDSS Cable Housing • JST PHDR-10VS 7.4.6 COM1 - COM Interface... -
Page 15: Com2, 3, 4 - Com Interface (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.7 COM2, 3, 4 - COM Interface (Internal Connector) COM2-COM4: 2x5 pin (2.0 mm) connector (RS232 mode) Layout and Pin Reference pin 1 Description Description Matching Connectors • JST B10B-PHDSS Cable Housing • JST PHDR-10VS 7.4.8 VGA - Analog VGA Display... -
Page 16: I2C - I2C Interface (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.9 I2C - I2C Interface (Internal Connector) I2C: I C 4-pin (1.25 mm) connector Layout and Pin Reference pin 1 Description +3.3V C clock C DATA Matching Connectors • Molex 53047-0410 Cable Housing • Molex 51021-0400 7.4.10 LAN1/LAN2 - LAN 10/100/1000 Ethernet Interface... -
Page 17: Usb1, 2 - Usb Interface
SYS-ITX-P-3800/Configuration LED1/LED2 - 10/100/1000 Ethernet LED Speed 10 Mbps 100 Mbps 1000 Mbps Indicate Side Back Front Back Front Back Front Link Link Link LAN light Orange Orange Orange Green Orange Orange Orange Orange 7.4.11 USB1, 2 - USB Interface USB1: USB 2.0 type-A external connector... -
Page 18: Sata1 - Serial Ata Interface (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.13 SATA1 - Serial ATA Interface (Internal Connector) SATA1: SATA port 1x7 pin connector Layout and Pin Reference Description Notes: 1. SATA1 supports SATA 2.0 (3 Gb/sec.). 2. PWROUT provides SATA HDD power +12V, GND, +5V. 3. SATA1 and MC1 share the same SATA channel. Only one can be used at a time. -
Page 19: Mc1/Mc2 - Pci Express Mini Card (Internal Connector)
SYS-ITX-P-3800/Configuration 7.4.14 MC1/MC2 - PCI Express Mini Card (Internal Connector) • MC1: Full-size Mini Card port 1 (PCIe/mSATA, USB) • MC2: Half-size Mini Card port 2 (mSATA, USB) Layout and Pin Reference Description Description +3.3V +1.5V pin 52 PCIe-CLK- PCIe-CLK+... -
Page 20: Jumpers
BIOS Functionality General Information The SYS-ITX-P-3800 includes a UEFI BIOS from Insyde stored in Flash ROM. Access setup information through the BIOS setup utility to modify basic system configuration. The configuration is stored in CMOS RAM (it is retained during power off). When power... -
Page 21: Entering Setup
SYS-ITX-P-3800/BIOS Functionality Entering Setup To enter setup, apply power to the computer and then press Del. You must press the Del key when either the splash screen is displayed (during the system power-on self test, POST) or when the Press Del for Setup message is displayed. It may take a few seconds before the main setup menu screen is displayed. - Page 22 SYS-ITX-P-3800/BIOS Functionality The Main BIOS page also contains information related to the amount and configuration of the system RAM (the type of RAM used in the design). • System Information. System Information parameters provide information and vary with BIOS version and the specific modules used. The typical format of the informa- tion is provided instead of the actual default setting or value.
-
Page 23: Advanced Menu
SYS-ITX-P-3800/BIOS Functionality square block. Use the +/- keys to change the highlighted value, or enter the time using the number keys 8.4.2 Advanced Menu Boot Configuration • Select power-on state for Numlock. Options are On (default), Off. PCI Express Configuration •... - Page 24 SYS-ITX-P-3800/BIOS Functionality • IGD - DVMT Total Gfx Mem. Use this item to select DVMT 5.0 pre-allocated (fixed) graphics memory size used by the internal graphics device. Options are 128M, 256M (default), MAX. Thermal Configuration This value controls the temperature of the ACPI critical trip point, the point where the OS shuts down the system.
-
Page 25: Security Menu
SYS-ITX-P-3800/BIOS Functionality 8.4.3 Security Menu Supervisor Password To set up a supervisor password: 1. Select Set Supervisor Password. A Create New Password dialog opens. 2. Type your desired password using no fewer than 3 characters and no more than 10 characters. -
Page 26: Power Menu
SYS-ITX-P-3800/BIOS Functionality 8.4.4 Power Menu • Wake on LAN. Determines the action taken when the system power is off and the PCI power management Enable wake up event occurs. Options are Enabled, Dis- abled (default). • Power Button. Options are: –... -
Page 27: Boot Menu
SYS-ITX-P-3800/BIOS Functionality 8.4.5 Boot Menu • Boot Type. Options are Dual type (default), Legacy boot type, UEFI boot type. • Quiet Boot. Options are Enabled (default), Disabled. • EFI/Legacy Device order. Determine whether the EFI device boots first or the leg- acy device. -
Page 28: Exit Menu
SYS-ITX-P-3800/BIOS Functionality 8.4.6 Exit Menu • Exit Saving Changes. This item allows the user to reset the system after saving the changes. • Save Change Without Exit. This item allows the user to save the changes, but doesn’t restart. •... -
Page 29: Super I/O Settings
SYS-ITX-P-3800/BIOS Functionality Super I/O Settings Press the F10 key during boot up to enter the Super I/O Settings menu. Serial Port 1/2 Configuration (SIO FINTEK81801U) • Serial Port 1/2 Configuration. Use this item to enable or disable the serial port (COM1 or COM2). - Page 30 SYS-ITX-P-3800/BIOS Functionality – RS485 driver: When hardware set to RS485 mode, select the RS485 driver. It is the auto flow function for RS485. • Power Failure. This item specifies whether your system reboots after a power fail- ure or interrupt occurs. Options are: –...
-
Page 31: Glossary
Software Description This section provides details on the Insyde BIOS components to be used in the implementation of the SYS-ITX-P-3800 BIOS firmware. 8.7.1 Software Design Specification: UEFI Operating System Support The BIOS supports the booting of the following UEFI compliant OSes: •... -
Page 32: Software Design Specification: Boot Device Configuration
SYS-ITX-P-3800/BIOS Functionality The BIOS supports the booting of the following legacy OS: • MS-DOS 6 8.7.3 Software Design Specification: Boot Device Configuration The BIOS supports booting an OS from the following devices: • USB mass storage device • Serial ATA (SATA) device •... -
Page 33: Bios Update With Uefi Shell
1. Insert a USB flash drive containing the BIOS update program into a USB socket on the SYS-ITX-P-3800 platform. 2. Turn on the SYS-ITX-P-3800 and press the ESC or DEL key during the boot process, which starts the BIOS setup utility. -
Page 34: Accessories And Cables
The following items are included in the package: • One SYS-ITX-P-3800 Embedded System • One power cable adapter Accessory List WinSystems cables simplify connection to the SYS-ITX-P-3800. The following table lists available items. Table 3: Cable specifications Part Number Connection Description CBL-AUDIO2-J02-06A See “AUDIO - Audio Interface (Internal... -
Page 35: Best Practices
The SYS-ITX-P-3800 requires +9V to +36V (+- 5%) to operate. Verify the power connections. Incorrect voltages can cause catastrophic damage. The SYS-ITX-P-3800 has a single power connector at J17. A single 9V-36V DC input and ground is required to power the board. - Page 36 —Always turn off the power supply before connecting to the I/O Module. ower Supply OFF Do not hot-plug the SYS-ITX-P-3800 on a host platform that is already powered. I/O Connections OFF—Turn off all I/O connections before connecting them to the embedded computer modules or any I/O cards.
- Page 37 Conformal Coating Applying conformal coating to a WinSystems product does not in itself void the product warranty, if it is properly removed prior to return. Coating can change thermal characteristics and impedes our ability to test, diagnose, and repair products. Any coated product sent to WinSystems for repair will be returned at customer expense and no service will be performed.
-
Page 38: Mechanical Drawings
SYS-ITX-P-3800/Mechanical Drawings Appendix B. Mechanical Drawings SYS-ITX-P-3800 Mechanical Drawings v1.0 www.winsystems.com Page 38... -
Page 39: Warranty Information
WinSystems, provided that the warranty, if any, may be assigned. The sole obligation of WinSystems for any breach of warranty contained herein shall be, at its option, either (i) to repair or replace at its expense any materially defective Products or Software, or (ii) to take back such Products and Software and refund the Customer the purchase price and any license fees paid for the same.
