Red-D-Arc Welderentals LN25 PRO EXTREME DUAL POWER Operator's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IM10080-A
RED-D-ARC
August 2013
LN25™ PRO EXTREME DUAL POWER
For use with machines having Code Numbers: 11750, 12164
OPERATOR'S MANUAL
Red-D-Arc Spec-Built Welding Equipment
This RED-D-ARC welder is built to RED-D-ARC Extreme Duty
design specifications by Lincoln Electric.
Safety Depends on You
This welder is designed and built with safety in mind.
However, your overall safety can be increased by proper installation
... and thoughtful operation on your part.
DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT
WITHOUT READING THIS MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED THROUGHOUT.
And, most importantly, think before you act and be careful.
1-800-245-3660
North America's Largest Fleet of Welding Equipment
