FAS2800 Systems
Installation and Setup Instructions
Prepare for installation | Stage 1
Pre-setup
Contents
in the box
Cables in your shipment
are order-dependent. Not all
cables shown may be
in your shipment.
Note: For more cable
information and part numbers,
see the
Hardware
Universe.
You provide
Prepare for installation
1. Unpack all boxes and inventory contents.
Attention: Customers with specific power requirements must check
2. Watch the
Setup
Videos.
3. Review the
NetApp ONTAP Configuration
10Gb Ethernet, SFP28
25Gb Ethernet, SFP28
Network cable
Network cable
Part numbers:
Part numbers:
X6566B-05-R6, .5m
X66240A-05, .5m
X6566B-2-R6, 2m
X66240-2, 2m
X66240A-5, 5m
32Gb Fiber Channel,
MiniSAS HD cable
SFP+ (target/initiator)
Storage connections
Network cable
Part numbers:
X66030A, 0.5m
Part numbers:
X66031A, 1m
X66250-2, 2m
X66032A, 2m
X66250-5, 5m
X66250-15, 15m
Rack space
Screwdriver
2U per chassis
Phillips #2
Install hardware
1
2
Hardware Universe
Guide.
10GBASE-T, RJ45
Network cable
Part numbers:
X6561-R6
X6562-R6
Additional cables
Ethernet cables
Power cables
Additional network cables
For connecting your storage system
to your network switch and laptop
or console
Cable storage
Complete system setup
3
and configuration
for their configuration options.
Cable management arms
Slide rail kit
Laptop or console
With a USB/serial connection and
access to a Web browser to configure
your storage system
4
June_2023_Rev1_FAS2800_ISI
