Cooper Lighting Portfolio CLW7142 Specification Sheet

CLW7218/7726 Dimensions Length Width
Standard Housing 13-3/4" 13-5/16"
Emergency 16-1/8" 20"
Chicago Plenum 13-3/4" 13-5/16"
CLW7142 Dimensions Length Width
Standard Housing 13-3/4" 13-5/16"
Emergency 17-5/8" 20"
Chicago Plenum 13-3/4" 13-5/16"
HOUSING BALLAST
CLW7218=(2) 18W DTT Lamp E=120V - 277V 50/60 Hz Electronic
CLW7226=(2) 26W DTT Lamp 3E=347V 50/60 Hz Electronic
CLW7142=(1) 26W TTT Lamp 1D=120V Dimming, Lutron
(1) 32W TTT Lamp 2D=277V Dimming, Lutron
(1) 42W TTT Lamp 1D26=26W 120V Dimming, Lutron
1D32=32W 120V Dimming, Lutron
1D42=42W 120V Dimming, Lutron
2D26=26W 277V Dimming, Lutron
*For CLW7218, CLW7226
2D32=32W 277V Dimming, Lutron
**For CLW7142 only
2D42=42W 277V Dimming, Lutron
TRIM
7491=Self Flanged
7493=Metal Trim Ring,
White
7-1/8"
8-3/4"
7-1/8"
8-3/4"
Height Cutout
7-1/2"
7-1/2" 8-1/8"
7-1/2"
Lens wall wash utilizes compact
fluorescent lamps and concave spread
Height Cutout
lens for uniform light distribution on
6-1/2"
6-1/2" 8-1/8"
6-1/2"
® Compact SE
*
® Compact SE
*
Compact SE
®
® Compact SE
® Compact SE
® Compact SE
® Compact SE
Compact SE
®
Ordering Example
Housing, Trim, Accessories and Lamps ordered as separate line items.
7" Lens Wall Wash
2-18, 2-26 DTT
1-26, 1-32, 1-42 TTT
vertical sufaces.
EDR26=DeRated
Wattage Label, 26W
**
EDR32=DeRated
Wattage Label, 32W
**
**
**
**
**
**
**
FINISH
LI=Low Iridescent Clear
H=Haze
WMH=Warm Haze
G=Gold
WH=Wheat
W=Gloss White
GP=Graphite
GPH=Graphite Haze
K=Cognac
KH=Cognac Haze
Housing
CLW7142EDR26
PORTFOLIO
HOUSING
OPTIONS ACCESSORIES
CP=Chicago Plenum HB26=C Channel Bar
EM=Emergency module Hanger, 26" Long, Pair
with remote test switch HB50=C Channel Bar
Hanger, 50" Long, Pair
RMB22=Wood Joist Bar
Hanger, 22" Long, Pair
FK5=Field Installed Fuse
Kit, 5 Amp
Lens Wall Wash
OPTIONS
WF=White
Painted
Flange (Self
Flanged
only)
Trim Accessories
7493LI HB26
