- Page 1 INSTALLATION MANUAL Simrad TP90 kongsberg.com/simrad...
- Page 3 Unit Installation Manual The purpose of this manual is to provide the descriptions and procedures required to install the TP90 Catch Monitoring Positioning Transceiver Unit and set it up to interface the TV80. 484238/A March 2023 © Kongsberg Maritime AS...
- Page 4 Kongsberg Maritime disclaims any responsibility for damage or injury caused by improper installation, use or maintenance of the equipment. Disclaimer Kongsberg Maritime AS endeavours to ensure that all information in this document is correct and fairly stated, but does not accept liability for any errors or omissions. Support information If you require maintenance or repair, contact your local dealer.
-
Page 5: Table Of Contents
Installation Manual Table of contents ABOUT THIS MANUAL ..............5 SIMRAD TP90 ................7 TP90 Catch Monitoring Positioning Transceiver ..............7 Order information ........................8 System diagram........................9 Support information .......................11 INSTALLING THE TP90 USING ITS MOUNTING BRACKETS ..14 CABLE LAYOUT AND INTERCONNECTIONS......... - Page 6 Simrad TP90 484238/A...
-
Page 7: About This Manual
The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval. Kongsberg Maritime AS will accept no responsibility for any damage or injury to the product, vessel or personnel caused by equipment that has been incorrectly installed or maintained, or by drawings, instructions or procedures that have not been prepared by us. - Page 8 Microsoft Corporation in the United States and other countries. ® ® ® Simrad , SIMRAD and the Simrad logo are either registered trademarks, or trademarks of Kongsberg Maritime AS in Norway and other countries. 484238/A...
-
Page 9: Simrad Tp90
Simrad TP90 TP90 Catch Monitoring Positioning Transceiver The Simrad TP90 Catch Monitoring Positioning Transceiver is an optional part of the Simrad TV80 catch monitoring system. By means of this transceiver, the TV80 can provide information about the relative position of the ITI and PxPos sensors placed on the trawl. -
Page 10: Order Information
Simrad TP90 Installation Manual The transceiver supports these catch monitoring sensors: • PxPos sensor: measurement combinations – Depth – Height 1 – Height 2 – Remote 1 – Remote 2 – Spread COM 1 – Spread COM 2 – Temperature / Depth (Lid dependant) –... -
Page 11: System Diagram
Simrad TP90 System diagram The system diagram presents a TV80 system with a TP90 transceiver. A basic system consists of a TV80 system, the transceiver, one single-split beam transducer, and a computer. The TV80 software controls the operation of the system. - Page 12 Simrad TP90 Installation Manual Unless otherwise specified in a contract, the display, the computer, and the transducers are not included in the standard delivery from Kongsberg Maritime. Related topics TP90 Catch Monitoring Positioning Transceiver, page 7 484238/A...
-
Page 13: Support Information
Telefax • www.kongsberg.com/simrad Website • simrad.france@simrad.com Email address • : Kongsberg Underwater Technology LLC (KUTL) / Simrad Fisheries Company name • : 19210 33rd Ave W, Suite A, Lynnwood, WA 98036, USA Address • : +1 425 712 1136 Telephone... - Page 14 Website • simrad.canada@simrad.com Email address Malaysia • : Kongsberg Maritime Malaysia Sdn. Bhd Company name • : Unit 27-5 Signature Offices, The Boulevard, Mid Valley City, Address Lingkaran Syed Putra, 59200 Kuala Lumpur, Malaysia • : +65 6411 7488 Telephone •...
- Page 15 Simrad TP90 • www.kongsberg.com/simrad Website • simrad.china@simrad.com Email address 484238/A...
-
Page 16: Installing The Tp90 Using Its Mounting Brackets
Simrad TP90 Installation Manual Installing the TP90 using its mounting brackets The transceiver can be installed vertically or horizontally using the integrated mounting brackets. Prerequisites A suitable location for the TP90 must be defined prior to installation. The unit can in principle be mounted anywhere on board the ship provided that the location is dry and ventilated. - Page 17 Installing the TP90 using its mounting brackets Secure the unit using four bolts or screws. Connect the cables. Note When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. 484238/A...
-
Page 18: Cable Layout And Interconnections
Simrad TP90 Installation Manual Cable layout and interconnections Topics Cable plan, page 17 List of cables, page 18 Connecting the transducer, page 19 Installing the Power Supply Unit, page 22 484238/A... -
Page 19: Cable Plan
Cable layout and interconnections Cable plan The cables are used to connect the TP90 transceiver to the computer, the Power Supply Unit and the transducer(s). Display Processor Unit TP90 Transceiver Unit Transducer Power Supply Unit Cables identified with an asterisk (*) are system or commercial cables. These cables are provided in the delivery or with the relevant item. -
Page 20: List Of Cables
Simrad TP90 Installation Manual List of cables A set of cables is required to connect the system units to each other, and to the relevant power source(s). Additional cables are required to connect the TP90 system to peripheral devices. Cable numbers not shown are not relevant for the purpose of this manual. -
Page 21: Connecting The Transducer
Cable layout and interconnections Connecting the transducer Connecting the transducer(s) to the correct inputs is critical for the correct functioning of the sensor positioning. Prerequisites You must be equipped with a standard set of tools. This tool set must comprise the normal tools for electronic and electromechanical tasks. - Page 22 Simrad TP90 Installation Manual Note If you connect just one transducer for Trawl Positioning (TP), you must mount one cable gland on the left cable entry and three blind plugs on the other cable entries on the transceiver connector panel. The TP90 delivery includes 2 cable glands and 3 blind plugs.
- Page 23 Cable layout and interconnections Single transducer for Trawl Positioning (TP) / Port transducer Colour Terminal Signal Brown Left element + Yellow / Green Left element - Blue Right element + Black Right element - Insert the plug into the Port / Single transducer socket. Place the connector panel back to its original position.
-
Page 24: Installing The Power Supply Unit
Simrad TP90 Installation Manual Installing the Power Supply Unit The transceiver requires an external power supply offering 12 to 15 Vdc, minimum 5 A. A suitable power supply is provided with the delivery. Prerequisites A suitable location for the power supply must be defined prior to installation. If you place the unit on the bridge, observe the compass safe distance. - Page 25 Cable layout and interconnections Make sure that adequate ventilation is available to avoid overheating. Make sure that the installation method allows for the physical vibration, movements and forces normally experienced on a vessel. Note To allow future maintenance, you must mount the unit with its cables and connectors available for easy access.
- Page 26 Simrad TP90 Installation Manual Note When you connect the cables, make sure that they are all properly secured, and able to withstand the vibration and movements of the vessel. These cables are included in the delivery. 484238/A...
-
Page 27: Setting Up The Transceiver
The software installation file is provided in a USB flash drive. You can also download the software installation file from Simrad website. For more information, contact one of our dealers or agents, or Kongsberg Maritime. Install the TpTransceiver software. The software installation file is provided in a USB flash drive. You can also download the software installation file from Simrad website. - Page 28 Simrad TP90 Installation Manual Install the software license. dialog box can be opened from the menu. Software License Setup Set up the transceiver. On the menu, select Setup Installation Select to open the dialog box. Add LAN Port Select Input (LAN) Select TP90.
- Page 29 Setting up the transceiver Result The transceiver receives trawl positioning information from the PxPos sensors and sends information in ITI NMEA format. You can check the entering measurements by clicking on the TP90 icon information circle in the TP90 block diagram under group.
-
Page 30: Technical Specifications
These technical specifications summarize the main functional and operational characteristics of the TP90 Catch Monitoring Positioning Transceiver Unit. Note At Kongsberg Maritime, we are continuously working to improve the quality and performance of our products. The technical specifications may be changed without prior notice. - Page 31 Technical specifications Environmental requirements • : 0 to +50 °C Operating temperature • : -40 to 70 °C Storage temperature • : 5 to 95% relative, non-condensing Relative humidity • : IP52 Ingress protection (IP) code Compass safe distance • : Not applicable.
-
Page 32: Drawing File
Simrad TP90 Installation Manual Drawing file Topics About the drawings in the drawing file, page 30 TP90 outline dimensions, page 32 About the drawings in the drawing file Relevant drawings related to the installation and/or maintenance of the TP90 system are provided for information purposes only. - Page 33 Drawing file installation can begin. The shipowner and shipyard doing the installation are responsible for obtaining and paying for such approval. 484238/A...
-
Page 34: Tp90 Outline Dimensions
Simrad TP90 Installation Manual TP90 outline dimensions Download the source drawing from our website: https://www.kongsberg.com/tp90 484238/A... -
Page 35: Overview Of Frequency Selection
