- Page 1 HIGHlite 4000Dsx HIGHlite 6000Dsx Super High Brightness Digital Video Projector User Manual...
- Page 2 Precautions: Please read this manual carefully before using your Digital CAUTION: To turn off main power, be sure to remove the plug from Projection HIGHlite 6000Dsx/4000Dsx Projector and keep the manual power outlet. The power outlet socket should be installed as near to handy for future reference.
- Page 3 Fire and Shock Precautions Important Safeguards 1. Ensure that there is sufficient ventilation and that vents are unob- These safety instructions are to ensure the long life of your projector structed to prevent potentially dangerous concentrations of ozone and to prevent fire and shock. Please read them carefully and heed all and the build-up of heat inside your projector.
- Page 4 Précautions contre l'incendie ou la décharge Recommandations importantes 1. S'assurer qu'il y ait une ventilation suffisante et que les ouvertures Ces instructions de sécurité ont pour but d'assurer une longue vie à ne soient pas obstruées afin d'éviter des concentrations votre projecteur et d'éviter un incendie ou une décharge électrique.
- Page 5 89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC & 93/68/EEC. 73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC. Products covered by this Directive Large Screen Projector type HIGHlite 4000Dsx Chassis HIGHlite 6000Dsx Chassis Basis on which Conformity is being declared The products identified above comply with the protection requirements of the above EU...
-
Page 6: Table Of Contents
TABLE OF CONTENTS Motion Level ............E-34 INTRODUCTION YTR Adjustment ............E-34 Introduction to the HIGHlite 6000Dsx/4000Dsx Projector ..E-1 CTR Adjustment ............E-34 Getting Started ............... E-1 Option Adj ..............E-34 What's in the Box? ..............E-1 Clamp Timing ............E-34 Sync Protection ............ -
Page 7: Introduction
• User Manual lumens (High Bright mode: HIGHlite 6000Dsx) / 3,500 ANSI lumens • CompactFlash Memory Card (8MB) with Adapter (Variable mode at max: HIGHlite 4000Dsx) with a lamp life of 1500 hours. • Digital Projection’s unique DLP based light engine offers true color reproduction. -
Page 8: Part Names And Functions
1. PART NAMES AND FUNCTIONS Projector Stacking Pad (4 pcs) Digital Input Terminal Panel Remote Sensor PC Card Access Indicator PC Card Slot Insert a PC memory card here to upgrade the projector system software or copy data Lens (Optional) Carrying Handle Input Terminal Panel Ventilation (out) - Page 9 Controls Remote sensor 1. Power Button 6. Cancel Button Press to turn the projector on when the projector is in the standby con- Press this button to exit the menu. Press this button to return the adjust- dition (Main Power switch must be on and the POWER indicator lit am- ments to the last condition while you are in the adjustment or setting ber).
-
Page 10: Terminal Panel
1. INPUT 3 RGB Connector (Mini D-Sub 15 pin) Terminal Panel Connect your PC or other analog RGB equipment such as a high-defi- nition document camera. 2. Option Connector (Mini D-Sub 9 pin) For system expansion such as PC-control. IN ....connect to the external equipment such as PC. INPUT3 INPUT2 INPUT1... - Page 11 Push the left side of the panel to open the compartment for the RGB Digital connectors and the optional SDI board. OUTPUT INPUT9 OUTPUT INPUT 0 DIGITAL Space to install the optional SDI or SX HDSDI board. Note SDI Loop through only available on SDSDI 11.
-
Page 12: Remote Control
4 ENTER Remote Control Executes the menu selection and activates items selected from the menu. When the slidebar or dialog box is diplayed: Pressing this button confirms adjustments/setting and returns to the previous menu display. 5 SELECT (Up/Down/Left/Right) When pressed together, the CTL and buttons work as a Back Space key in the entry screen. -
Page 13: Remote Control Precautions
Remote Control Precautions 17 POSITION Press to display the Blanking screen; press again to display the Posi- • Use the remote control within a distance of about 7m (23feet) and at tion screen. an angle of 30˚ above, below, to the left and to the right of the remote While pressing and holding CTL, pressing this button displays the Lens control sensor located at the front of the main unit. -
Page 14: Installation
2. INSTALLATION This section describes how to set up your projector and how to connect Screen Size and Projection Distance video and audio sources. Applicable lens and throw distance/ List of screen sizes Setting Up Your Projector Your Projector is simple to set up and use. But before you get started, you must first: 1. -
Page 15: Lens Shift Adjustable Range
Lens Shift Adjustable Range Lens Shift Adjustable Range for Desktop and Ceiling Mount Application The diagram below shows the location of the image position in the lens. The lens can be shifted within the shaded area as shown using the normal projection position as a starting point. -
Page 16: Moving The Projector
Moving The Projector Selecting A Location Always carry your projector by the handle. Ensure that the power cord The further your projector is from the screen or wall, the larger the im- and any other cables connecting to video sources are disconnected age. -
Page 17: Basic Operation
3. BASIC OPERATION Using the Power Cable Stopper Connecting the Power Cable and Turn The Power cable wire stopper is provided on the projector so that the on the Projector cable cannot be accidentally unplugged from the AC IN. Before you turn on your projector, ensure that the computer or video 1. -
Page 18: About Startup Screen (Menu Language Select Screen
About Startup Screen (Menu Language Select screen) When you first turn on the projector, you will get the Startup screen. POWER This screen gives you the opportunity to select one of the seven menu languages: English, German, French, Italian, Spanish,Swedish and Japanese. MENU To select a menu language, follow these steps: 1. -
Page 19: Set Up The Projector
(2) Press and hold the CTL and press the ZOOM + or - button to adjust the Set up the projector image size. You can also adjust the image size by using the ZOOM + or - button on the projector cabinet. 1. -
Page 20: Keystone
Keystone 2) Hookup 2-1. Use the supplied DVI-D cable to connect the RGB DIGITAL output of the master projector to the RGB DIGITAL input (INPUT9 )of the slave projector (the second and third stack) until all the projectors are connected. Keystone distortion Normal 2-2. - Page 21 3-1-6-3. Remove the PC card from the slave projector. 6-4 Project a source image from all projectors 6-4-1. Display any signal onto the screen. NOTE: If you select the RGB1 input on the master projector, you must select the same input on the slave projector and the RGB2 on the master projector 6-4-2.
-
Page 22: Projector Orientation
Projector Orientation WARNING • Installing your projector on the ceiling must be done by a qualified An image can be projected from in front or behind a screen, and the technician. Contact your Digital Projection dealer for more information. projector can be installed on the ceiling*. * Do not attempt to install the projector yourself. -
Page 23: Connections
When used in standalone operation Use common RCA cables (not provided) to connect your VCR or laser Connecting Your PC Or Macintosh Computer disc player to your HIGHlite 4000Dsx/6000Dsx Projector. To make these Connecting your PC or Macintosh computer to HIGHlite 4000Dsx/ connections, simply: 6000Dsx Projector will enable you to project your computer's screen image for an impressive presentation. -
Page 24: When Used With One Switcher (Iss-6020/Iss-6020G
When Used with One Switcher (ISS-6020/ISS-6020G) Up to 10 input signals can be accepted when the projector is connected to one Switcher. Using the projector with the Switcher allows easy adjustment and signal selection. INPUT3 INPUT2 INPUT1 INPUT4 R/Cr R/Cr OPTION B/Cb B/Cb... - Page 25 NOTE: When Used with Two or More Switchers (100 • Be sure to set all the slide switches (S8603) of the Switcher to RS-422 posi- Inputs) tions. Set the one on the last slave Switcher to the appropriate position to match the connected equipment such as a personal computer.
- Page 26 Set the DIP switch (S8601) of the Switcher as follows: NOTE: Slave numbers 1 to 10 must correspond to the master’s slot numbers 1 to 10. ISS-6020 Setting of S8601 Output to ISS-6020G OPEN Master The Projector 1 2 3 4 5 6 7 8 SHORT OPEN Slave 1...
-
Page 27: Remote 1 Connector
REMOTE 1 Connector This connector is used for either connecting the ISS-6020/ISS-6020G Switcher or a third party external control device. When the Switcher is used, connect it with the optional control cable (15-15 pin; 50 ft./16m; CTL-6010) to this connector. When used with the Switcher. - Page 28 When used in stand alone operation. Pin No. SHORT/OPEN FUNCTION SHORT External control mode ON External control mode OFF OPEN POWER ON SHORT POWER OFF OPEN PICTURE MUTE ON SHORT OPEN PICTURE MUTE OFF 12pin 8pin 11pin 4pin 4,8,12,11 OPEN OPEN RGB 1 (INPUT 1) OPEN...
-
Page 29: Operating Multiple Projectors With Remote Control
Operating Multiple Projectors with Remote Control You can operate multiple projectors with the same remote control in wireless operation. To do so: 1. Select [Menu] → [Projector Options] → [Setup] → [Page 5] → [Projector ID] and assign an ID number to each projector. See also page E-39. 2. -
Page 30: Using The Rgb Digital (Dvi-D) Connectors
Using the RGB DIGITAL (DVI-D) connectors (standard on HIGHlite 6000Dsx, option on 4000Dsx) The Link mode function allows you to adjust or set multiple projectors using the RGB DIGITAL and OPTION connectors. The DVI DIGITAL input accepts up to the SXGA (1280 x 1024 @75Hz) signal. NOTE: The Auto Adjust feature does not work for DVI digital signal. -
Page 31: Operation
5. OPERATION This section describes how to select a computer or video source, adjust NOTE: The change is stored automatically when any one of the following pro- the picture and sound, edit a signal and adjust all other settings and cedures is performed: adjustments for proper projector set-up. -
Page 32: Customizing Basic/Custom Menu
Customizing Basic/Custom Menu NOTE: If the "Advanced Menu" item has been selected on the Menu mode, The Basic/Custom menu can be customized to meet your requirements. you get the "Confirmation Change Menu" upon completion of "Basic/Custom Menu" editing. In this case, selecting "Yes" then "Enter" will close all the menus Selecting a menu item from the "Basic/Custom Menu Edit"... -
Page 33: A List Of Direct Key Combinations
A List of Direct Key Combinations CTL+ INPUT (1-10) Switches to any selected signal found in the Entry List. To enable this combination, you must first assign specific remote keys for direct input selection in the Entry Edit window. CTL+ ENTER (While displaying Entry list) Displays the Entry Edit Command window. -
Page 34: Menu Tree
Menu Tree When Switcher Control is turned on: Switcher Brightness Advanced Menu Entry List Contrast Source Select Saturation Adjust (Source) 0 – 100 Stand alone Color Ref Adj RGB1 Factory Default RGB2 Sharpness Projector Options RGB3 V-Aperture Help Component (YCbCr) Gamma Correction Test Pattern NTSC, Graphics NTSC, PAL/SECAM2.8,... - Page 35 Keystone Lamp Mode 6000Dsx: Auto / High-Bright / Variable / Long Life 4000Dsx: Auto / Variable / Long Life Advanced Menu Lamp Lamp Output Source Select Ref. White Bal. Adjust (Source) Brightness R/G/B, Contrast R/G/B Ref Adj All Data / Current Signal Factory Default On / Off Timer Execute Switch (Active / Inactive)
-
Page 36: Menu Elements
Menu Elements Help Button Title bar Highlight Radio button OK Button Cancel Button Solid triangle Check box Slide bar Menu windows or dialog boxes typically have the following elements: Title bar: Indicates the menu title. Highlight: Indicates the selected menu or item. Solid triangle: Indicates further choices are available. -
Page 37: Menu Descriptions & Functions
Entry List Menu Descriptions & Functions Displays the list of the entry signals. Use the buttons on your re- Source Select mote control or the projector cabinet to select the signal and press the ENTER button on the remote control or the projector cabinet to project the image of the selected source. -
Page 38: Adjust (Source
Select "List" and press ENTER to display the direct Key assignment White Balance list. Select "OK" and press ENTER to close the window. To close the List window, press CANCEL on the remote. Color Temperature This feature adjusts the color temperature using the slide bar. Move the slide bar to the right to increase the color temperature for a bluish image;... -
Page 39: Horizontal/Vertical Position
Horizontal/Vertical Position (when Auto Adjust is off): Video Filter This feature reduces video noise. Select the appropriate filter for your signal. Bar 0 .... Off Adjusts the image location from left to right. Bar 1/3 ..High This adjustment is made automatically when the Auto Adjust is turned Bar 2/3 .. -
Page 40: Color Matrix
Color Matrix Option Adj Clamp Timing: First, select an appropriate color matrix for your input signal, either HDTV or SDTV. Then select an appropriate matrix type from B-Y/R- Y, Cb/Cr, Pb/Pr or IVX. NOTE: The Color Matrix feature is available for component video signal only. Y/C Delay (not available for RGB) According to the signal, this function sets the detection position (i.e., clamp position) of the black level reproduction of the analog input... -
Page 41: Lens Memory
Lens Memory Switcher (available only when used with ISS-6020) Switcher Gain This function serves to store the adjusted value when using the Shift, Focus, and Zoom buttons of the main unit or the remote control. Usage Example When you wish to display on a screen having a 4:3 aspect ratio an NTSC or other 4:3 aspect ratio signal and an SXGA or other 5:4 aspect ratio signal: Perform shift, focus, and zoom adjustments to set the vertical screen... -
Page 42: Lamp
Lamp Projector Options Lamp Mode Enables you to set preferences and other operating options. This feature allows the lamp power supply to operate under three set- Timer tings. Auto ..... This setting keeps the projector's original light output level for a certain period of time. Enables you to turn on or off your projector automatically at a specified High-Bright (HIGHlite 6000Dsx only) time. -
Page 43: Sleep Timer
5. To enable your setting, select Active on the Execute Switch. Menu Display Time : This option allows you to select how long the projector waits after the 6. Select OK and press the ENTER button on the remote control to complete last touch of a button to turn off the menu. -
Page 44: Setup
Setup [Page 3] Enables you to set operating options. Press "OK" to save your changes for all the features of Page1, Page2, Page3, Page 4 and Page5. [Page 1] Signal Select (VIDEO 1/2, S-VIDEO1/2 and Switcher) This feature enables you to select composite video standards manu- ally. -
Page 45: Last Memory/Seamless/Auto White/Lens Memory/User Name
Last Memory Communication Speed The projector stores the last signal data in memory for each input This feature sets the baud rate of the PC CONTROL connector (Mini D-Sub 9 Pin). (RGB1, RGB2, RGB3, Component [YCbCr], Video 1, Video2, S- It supports data rates from 4800 to 38400 bps. -
Page 46: Source Information
Provides an online help about how to use the menus. An underlined link Status items: Running ...... The projector is now working means that you can move to an adjustment item directly. Selecting the underlined link and pressing ENTER moves to the corre- Cooling Lamp ..... -
Page 47: Specifications
Built in: Overheat Protection Lamp Over-Usage Protection Light Output HIGHlite 6000Dsx : 5000 ANSI Lumens (High Bright mode) HIGHlite 4000Dsx : 3500 ANSI Lumens (Variable mode at max) Full Light Output at 200- 240V Brightness Uniformity >80% edge to center... - Page 48 *1: HIGHlite 6000Dsx: Permissible deviation for RGB convergence (Pixel deviation) is 3/4 pixel or less at center; 1 pixel or less around the perimeter (when projection upward angle is 0˚). HIGHlite 4000Dsx: Permissible deviation for RGB convergence (Pixel deviation) is 1 pixel or less at center; no space between two color pixels around the perimeter (when projection upward angle is 0˚).
-
Page 49: Optional Accessories
7. OPTIONAL ACCESSORIES Lens TL-08SF (Short Focal Lens 0.84) : 10kg LA00111 TL-1Z/1ZX (Zoom Lens 1.5 - 2.5:1) :5.6kg Normal - LA00107, High Contrast - LA00282 TL-2Z/2ZX (Zoom Lens 2.5 - 4.0:1) : 4.5kg Normal - LA00108, High Contrast - LA00281 TL-4Z (Zoom Lens 4.0 - 7.0:1) : 5.5kg LA00109 Interface Board SD SDI BOARD - LA00105... -
Page 50: Compatible Input Signal List
NOTE 2: UXGA can be supported for separate sync signal only. NOTE 3: DVI digital signal can support a maximum resolution of SXGA@75Hz. NOTE 4: Digital signals are indicated in shaded areas. HIGHlite 4000Dsx requires the optional DIGITAL RGB BOARD (DVI-D) to accept these digital signals. E – 44... -
Page 51: List Of Menu Items Available In Link Mode
9. LIST OF MENU ITEMS AVAILABLE IN LINK MODE See the table below for available functions in the digital link mode and the analog link mode. See the table below for available functions in the digital link mode (HIGHlite 6000Dsx only) and the analog link mode. * The digital signals available in the Link mode are the VESA compatible-signals except interlaced signals of VGA@60Hz to SXGA@75Hz. -
Page 52: Appendix
APPENDIX Dimensions 30 (1.18) 506 (19.92) 35.5 (1.40) (2.76) 300 (11.81) 326 (12.83) The drawings do not include the lens part. Unit: mm (inch) E – 46... -
Page 53: Tips On Adjusting Focus For Lens Memory Function
Tips on Adjusting Focus for Lens Memory Function Optimum focus for lens memory function can be achieved on the projector by paying special attention in a few areas. Focus adjustment after the projector has warmed up to normal operating temperature is better than doing so when the projector is cold. Lens mechanics interact differently when adjusting focus from one direction to the other.
