This manual contains important information concerning the
installation and operation of the crusher listed above.
Read manual thoroughly and keep for future reference
INSTRUCTIONS
2760 Ridgeway Court
800-444-4351
e-mail: info@herkules.us
Page 1 of 8
Part# 1002437
6/28/05
Model: OFC3
Walled Lake, MI 48390-1662 USA
Fax 248 960-7109
Advertisement
Table of Contents
Related Manuals for HERKULES OFC3
Summary of Contents for HERKULES OFC3
- Page 1 Part# 1002437 6/28/05 Model: OFC3 This manual contains important information concerning the installation and operation of the crusher listed above. Read manual thoroughly and keep for future reference INSTRUCTIONS Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA...
-
Page 2: Table Of Contents
Table of Contents Warnings …………………………………………………………………………………………………………………. 3 Model Information (List of models with descriptions and data) ……………………………………………… 4 Installation ……………………………………………………………………………………………………………….. 5 Inspection ………………………………………………………………………………………………………………… 6 Operation ………………………………………………………………………………………………………………… 6 Maintenance …………………………………………………………………………………………………………. 7 Repair …………………………………………………………………………………………………………………….. 7 Drawings with part lists: ……………………………………………………………………………………………. 7-8 Warning Symbol Caution Symbol WARNING CAUTION... -
Page 3: Warnings
FAILURE TO HEED THE FOLLOWING WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. Herkules will not be held responsible for any personal injury and/or property damaged caused due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 4: Model Information (List Of Models With Descriptions And Data)
550 Ibs. DESCRIPTION Model OFC3 is a production crusher capable of crushing four filters at one time. The crusher is designed for automotive and light truck shops to crush and dispose of used oil filters in an environmentally correct manner. The crusher provides the following features: •... -
Page 5: Installation
OWNER/OPERATOR RESPONSIBILITY It is the responsibility of the owner/operator to properly use and maintain this equipment. The instructions and warnings contained in this manual shall be read and understood by the owner/operator prior to operating this equipment. If an owner/operator does not understand English, the contents of this manual shall be explained in the owner/ operator native language to assure the owner/operator comprehends. -
Page 6: Inspection
INSPECTION Prior to operation a visual Inspection shall be made. Check crusher for leaks, worn or missing parts. Any crusher that appears to be damaged in any way, is badly worn or operates abnormally shall be removed from use until repairs are made. Contact a factory authorized service center for repairs. If over pressurizing of the equipment is believed to have occurred, contact a factory authorized service center for inspection of the crusher. -
Page 7: Maintenance
Apply motor oil to door latch pivot points on a regular basis to prevent latch from binding. REPAIR No service parts are available for this oil filter crusher. Special tools and procedures are required for repair. If repair is required, contact Herkules Equipment Corporation Customer Service, (800-444-4351) for your nearest authorized service center. SERVICE PARTS... - Page 8 SERVICE PARTS Handle Assembly #11844 Grating Assembly #11843 Clean Out Rod #10028 Piston Assembly #11846 Tee Assembly Drain Pan #C12EB #11857 Air Bag #11859 Reservoir Assembly #10031 Page 8 of 8...
