Herkules Equipment Corporation
248-960-7100
Patents USA 7070167 4793369, 4960142, 5174317, 5193561, 5485860 Canada 1299468 & Patents Pending
website: www.herkules.us
This manual contains important information concerning the
installation and operation of the crusher listed above.
Read manual thoroughly and keep for future reference
INSTRUCTIONS
2760 Ridgeway Court
800-444-4351
Made in the USA
Page 1 of 8
Part# 1002513-06
05/6/22
Model: HCR3
Walled Lake, MI 48390-1662 USA
Fax 248 960-7109
e-mail: info@herkules.us
Advertisement
Table of Contents
Related Manuals for HERKULES HCR3
Summary of Contents for HERKULES HCR3
- Page 1 Part# 1002513-06 05/6/22 Model: HCR3 This manual contains important information concerning the installation and operation of the crusher listed above. Read manual thoroughly and keep for future reference INSTRUCTIONS Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA...
-
Page 2: Table Of Contents
Serial Number PATENT NUMBERS Model Number This product has patent protection under one or more of the following patent numbers: 7070167, 5485860, 5193561, 5174317 Purchase Date 4960142, 4793369, 1299468 and Patents Pending website: www.herkules.us 1002742 Distributor Page 2 of 8... -
Page 3: Warnings
FAILURE TO HEED THE FOLLOWING WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. Herkules will not be held responsible for any personal injury and/or property damaged caused due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 4: Model Information
Model Information SPECIFICATIONS Maximum crushing pressure 2.1 tons Can capacity One 1-gallon can Three 1-quart cans Time to crush can 20 seconds Overall width 18.125" Overall height 25.25" Overall depth 13.5" Chamber width 9.25" Chamber height 8.75" Chamber depth 9" Required air pressure 90-120 p.s.i. -
Page 5: Installation
INSTALLATION figure 1 See figures 1 & 2. Install the crusher as follows. Step 1 Set the unit on a bench or table that can support its weight. It is recommended that the unit be lagged or bolted down. Step 2 Assemble the oiler to the valve using Control valve (1) 1/4 NPT hex nipple. -
Page 6: Inspection
INSPECTION Prior to operation a visual Inspection shall be made. Check crusher for leaks, worn or missing parts. Periodically check oil level of oiler. DO NOT RUN WITHOUT OIL. Any crusher that appears to be damaged in any way, is badly worn or operates abnormally shall be removed from use until repairs are made. -
Page 7: Maintenance
Apply motor oil to door latch pivot points on a regular basis to prevent latch from binding. REPAIR No service parts are available for this can crusher. Special tools and procedures are required for repair. If repair is required, contact Herkules Equipment Corporation Customer Service, (800-444-4351) for your nearest authorized service center. Cylinder... -
Page 8: Drawing & Parts
DRAWING & PARTS Screw BHSC 8-32 x 1-1/2 #008-246 Cylinder #008-640 Control Valve #12174 Ram Plate #15395 Crusher Chamber (Complete Weldment for HCR3) #12173 Page 8 of 8...
