- Page 1 OWNERS MANUAL concerning the installation and operation of the equipment listed below. INSTRUCTIONS 1011194 (OFC7).xlsx Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA 248-960-7100 800-444-4351 Fax 248 960-7109 Patents USA 7070167 4793369, 4960142, 5174317, 5193561, 5485860 Canada 1299468 & Patents Pending website: www.herkules.us...
-
Page 2: Table Of Contents
The limited liability warranty applies to other components of our Herkules crushers to the initial user against defective materials for a period of one year from the proof of purchase date. -
Page 3: Warnings
FAILURE TO HEED THE FOLLOWING WARNING MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. 1. Herkules will not be held responsible for any personal injury and/or property damaged caused due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 4: Model Information
Model Information SPECIFICATIONS Maximum crushing pressure 35,000 Ibs. Filter capacity One heavy duty filter or four auto filters Filter type Heavy duty Filter crush Up to 80% Residual oil removed from crushed filter 95 - 98% Time to crush filter 35 - 55 seconds Overall width 28-5/16"... -
Page 5: Important Instructions
Any other procedure should be done only by trained crusher service personnel. 5. Herkules will not be held responsible for any personal injury and/or property damage due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 6: Installation
INSTALLATION Read this manual thoroughly before installing, operating, or maintaining this crusher. DO NOT attempt to operate the unit while on a skid. The initial crush of the oil filter(s) will cause the unit to move or jump if not secured properly. The crusher must be anchored to the floor before operating. 1. -
Page 7: Operation
OPERATION 1. Connect the external air supply. Lift the door latch and pull the door down to gain access to the crushing chamber. Place the oil filter(s) to be crushed gasket side down on the bottom of the crushing chamber. Arrange the filters as follows: Quantity &... -
Page 8: Maintenance
MAINTENANCE 1. Prior to performing any maintenance on this crusher, the plunger MUST BE in the DOWN position with all air pressure released from the system! 2. Remove air line from crusher - ONLY when step #1 has been completed! 3. -
Page 9: Safety Tips
SAFETY TIPS WARNING Read all instructions. INSPECT your crusher daily. Never operate if it malfunctions or if is has broken or damaged parts. Repairs should be made with original equipment parts. Operating controls are designed to close when released. Do not block open or override them. NEVER overload your crusher. -
Page 10: Bill Of Material
18773 SPACER WELDMENT 15 OD X 5.62 ID X 1.0 1000315 ELBOW 1/2 NPTF Z 1001229 NUT HEX 3/4-10 PLAIN 1001902 DECAL HERKULES WHITE 2.68 X 12.88 1001941 WASHER FLAT 3/4 SAE Z 1002404 STICKER WARNING INSTRUCTIONS 1002644 BULKHEAD FITTING... -
Page 11: Available Options
OFC7 AVAILABLE OPTIONS Regulator Kit #19945 Qty. Per Qty. Per DET# PART# DESCRIPTION UNITS Assembly Crusher 19945 REGULATOR KIT Assy Includes: 18828 REGULATOR 1003586 HOSE BARB 1/2 X 1/2NPT Page 11 of 11...
