This manual contains important information concerning the
installation and operation of the crusher listed below.
Herkules Equipment Corporation
2760 Ridgeway Court
Walled Lake, MI 48390-1662 USA
Page 1 of 16
Part# 1011189
Made in USA
800-444-4351
Toll Free:
248-960-7100
Phone:
248 960-7109
Fax:
1/27/2021
Advertisement
Table of Contents
Related Manuals for HERKULES OFC6
Summary of Contents for HERKULES OFC6
- Page 1 Part# 1011189 1/27/2021 Made in USA This manual contains important information concerning the OWNERS MANUAL installation and operation of the crusher listed below. www.herkules.us Herkules Equipment Corporation 800-444-4351 Website: Toll Free: info@herkules.us 2760 Ridgeway Court 248-960-7100 Phone: E-mail: Walled Lake, MI 48390-1662 USA...
-
Page 2: Table Of Contents
..................................... 15 Herkules Equipment Corporation A U.S.-based manufacturer, Herkules Equipment Corporation offers a diverse line of products that support multiple industries by improving efficiency, productivity, ergonomics, comfort, and safety in the work environment. The company consists of the three product lines: Herkules, Enkon and BossLifts. -
Page 3: Warranty
In the event of product failure, the defective item must be returned, freight prepaid, to the Herkules manufacturing plant for repair or replacement. If repairs are required, Herkules will not be liable for these repairs to take place in the field regardless of the application. -
Page 4: Warnings
FAILURE TO HEED THE FOLLOWING WARNINGS MAY RESULT IN PERSONAL INJURY AND/OR PROPERTY DAMAGE. 1. Herkules will not be held responsible for any personal injury and/or property damaged caused due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 5: Model Information
3.75" maximum filter diameter (single) 8" maximum height Model OFC6 crusher is capable of crushing filter under 8" tall per cycle. The crusher is designed for automotive and light truck shops to crush and dispose of used oil filters in an environmentally correct manner. -
Page 6: Important Instructions
Any other procedures should be done only by trained crusher service personnel. 5. Herkules will not be held responsible for any personal injury and/or property damage due to owner/operator failure to follow the warnings and cautions listed in this manual. -
Page 7: Installation
Installation Read this manual thoroughly before installing, operating, or maintaining this crusher. DO NOT attempt to operate the unit while on a skid. The initial crush of the oil filter will cause the unit to move or jump if not secured properly. The crusher must be anchored to the floor or bench before operating. 1. -
Page 8: Schematic
Schematic Page 8 of 16... -
Page 9: Operation
Operation Connect the external air supply. Push on Pin Button and swing the door open to gain access to the crushing chamber. Place a single oil filter to be crushed gasket side down on the screen with the filter centered on bolt head. Close the door (allowing the pin button to securely latch the door closed). -
Page 10: Maintenance
Maintenance Regularly check the waste oil drain to prevent oil backing up in the crusher cabinet and causing an oil spill. Clean, repair as required. Regularly clean the crusher chamber to remove any accumulated oil sludge, metal particles or any other debris that could affect the crusher operation or block the waste oil drain system. -
Page 11: Safety Tips
Safety Tips WARNING Read all instructions. INSPECT your crusher daily. Never operate if it malfunctions or if it has broken or damaged parts. Repairs should be made with original equipment parts. Operating controls are designed to close when released. Do not block open or override them. NEVER overload your crusher. -
Page 12: Troubleshooting Chart
Troubleshooting Chart Warning: There is a danger of personal injury during repair by moving crusher parts. Warning: Competent, trained, and instructed staff may perform repair and maintenance work only. Warning: Follow all safety instructions during maintenance work. Troubleshooting Check List Kind of trouble Possible causes Action Required... -
Page 13: Drawings With Part Lists
OFC6 Parts Layout 20 21 Page 13 of 16... - Page 14 Clip - Crusher Dome 1010208 (Not Shown) Spacer 3/8 OD x 1/4" LG 1010211 Sticker - Herkules 1010213 Sticker - OIL FILTER CRUSHER OFC6 1010214 Sticker - UP / DOWN 1010216 Sticker - WARNINGS 1010217 Sticker - CRUSHER Decal 1010401 (Not Shown) Washer Bonded Sealing 3/4"...
-
Page 15: Available Options
OFC6 Available Options Floor Mount Kit #18969 Part# Description Qty. Unit 18969 Floor Mount Kit Page 15 of 16... - Page 16 Deliberately Left Blank Page 16 of 16...
