Summary of Contents for Fluance RT81P
- Page 1 RT80/RT81/RT81P - High Fidelity Vinyl Turntable User Manual v2.6 Serious Performance Fluance.com ™...
- Page 2 Fluance RT80/RT81/RT81P User Manual Introduction Thank you for your purchase of your Fluance product. We hope you enjoy your experience. If you have any questions please visit us at: Fluance.com/support Fluance believes everyone should experience audio in its truest form, recreating the performance the way the artist intended.
- Page 3 Step One: Installing the Platter Step Two: Installing the Counterweight Step Three: Installing the Headshell Step Four: Dust Cover Installation Step Five: Leveling the Turntable (RT81P) Step Six: Balancing the Tonearm Step Seven: Setting the Preamp Switch Step Eight: Connecting the Power...
- Page 4 Fluance RT80/RT81/RT81P User Manual What’s Included Dust Cover & Platter with Turntable Mat Headshell with RT80 - Felt Turntable Rubber Belt Stylus RT81 - Rubber RT81P - Acrylic Counterweight 45 Adapter Power RCA Audio Bubble Level Adapter Cable with (RT81P Only)
- Page 5 Fluance RT80/RT81/RT81P User Manual Components and Connections RT81P Only Platter 11. Tonearm Lock 2. Rubber Belt 12. Tonearm 3. Motor Pulley 13. Headshell & Stylus 4. Spindle 14. RCA Audio Outputs 5. Turntable Mat 15. Ground Terminal 6. Speed Selection 16.
- Page 6 Remove the installation Note: When using the Fluance rubber turntable mat ribbon and rotate the platter several ensure the Fluance logo is facing up when placing times to ensure the rubber belt is the mat. When using the acrylic turntable mat ensure secure and not twisted.
- Page 7 Fluance RT80/RT81/RT81P User Manual Step Two: Installing the Counterweight Secure the tonearm using the 2. Slide the counterweight onto the end tonearm lock. of the tonearm with numbers facing forward until it clicks on. Counterweight Tonearm Tonearm Lock Step Three: Installing the Headshell Remove the headshell from the 2.
- Page 8 Fluance RT80/RT81/RT81P User Manual Step Four: Dust Cover Installation Install the hinges on the provided grooves located on the back of the dust cover. Important: Place dust cover on a soft surface to avoid scratching it. CAUTION: The hinges are spring loaded and can close with strong force.
- Page 9 Fluance RT80/RT81/RT81P User Manual Step Five: Leveling the Turntable (RT81P Only) 1. The RT81P turntable features 3 adjustable feet to ensure the turntable is level regardless of the surface the turntable is resting upon. Lower Raise Turntable Turntable Bubble Level...
- Page 10 Step Six: Balancing the Tonearm Important! Complete all steps for balancing the tonearm. Incorrect tonearm balancing can cause damage to the stylus and to your records. For additional assistance go to: www.fluance.com/support to watch a tutorial video for this process Remove the stylus protector.
- Page 11 Fluance RT80/RT81/RT81P User Manual Step Six (Continued): Balancing the Tonearm Rotate the entire counterweight 8. Set the anti-skating control to “2” to counterclockwise until the indicator match the tracking force. ring is set to “2” on the center line. This will set the tracking force to the recommended 2.0 gram tracking...
- Page 12 Connect the RCA cables to the audio outputs on the back of the turntable and then plug the other end into your preamp. Ground Cable (Optional) The turntable setup is now complete! Enjoy your Fluance turntable. Should you require any further assistance please contact us at: www.fluance.com/support...
- Page 13 33 RPM) Fluance recommends burning in your record player for 24 hours. To do this turn off Auto Stop on the back of your record player and then select either the 33 or 45 speed setting. Your platter should begin spinning and start the burn-in process.
- Page 14 RT81P AT-VMN95E AT-VMN95E Replacing the Cartridge Replacement cartridges and a helpful cartridge installation guide and video are available on www.fluance.com. There is also a Cartridge Alignment Protractor at the end of this manual for convenience. Cartridge Connections Wire Channel White...
- Page 15 Fluance RT80/RT81/RT81P User Manual Replacing the Rubber Belt Remove the defective rubber belt from the motor pulley. 2. Lift and remove the platter from the spindle. Remove and discard the defective rubber belt. 3. Wrap the new rubber belt around the inner ring on the underside of the platter and ensure the rubber belt is not twisted.
- Page 16 Fluance RT80/RT81/RT81P User Manual No Power • The turntable should be connected to a known good power outlet and the power cable should be securely inserted into the unit. • The power LED should light up when the speed selection knob is set to 33 or 45.
- Page 17 Fluance RT80/RT81/RT81P User Manual Low Volume • Check the RCA connections are correct and fully inserted. • Ensure that the Preamp Switch is set to the LINE position if not using an external preamp. • If low volume persists more information is available at: www.fluance.com/support Audio From Only One Channel •...
- Page 18 Fluance RT80/RT81/RT81P User Manual Specifications Specifications RT80 RT81 RT81P Cabinet Specifications Material Dust Cover Yes - Tinted Yes - Tinted Yes - Tinted Turntable Specifications Drive System Belt Drive Belt Drive Belt Drive Motor DC Motor DC Motor DC Motor...
- Page 19 Fluance RT80/RT81/RT81P User Manual Specifications RT80 RT81 RT81P Cantilever Carbon Fiber Aluminum Aluminum Mount Half inch Half inch Half inch Frequency Response 20-20,000Hz 20-20,000Hz 20-22,000Hz Channel Separation 18dB at 1kHz 20dB at 1kHz 20dB at 1kHz Channel Balance 2.5dB or less at 1kHz 2.0dB or less at 1kHz...
- Page 20 Fluance RT80/RT81/RT81P User Manual Important Safety Instructions WA R N I N G WARNING: RISK OF ELECTRIC SHOCK TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS DO NOT OPEN APPARATUS TO RAIN OR MOISTURE The lightning flash with arrowhead symbol within an...
- Page 21 Fluance RT80/RT81/RT81P User Manual FCC & IC Information WARNING: To reduce the risk of fire or electrical shock, do not expose this appliance to rain or moisture. Electrical equipment should NEVER be kept or stored in damp environments. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
- Page 22 Fluance RT80/RT81/RT81P User Manual Cartridge Alignment Protractor Correct cartridge alignment ensures the stylus is positioned properly relative to the grooves on the record. Incorrect alignment can cause distortion and can also cause unwanted wear and tear on your stylus. Follow the instructions below to ensure your cartridge is mounted correctly.
- Page 23 Fluance RT80/RT81/RT81P User Manual Cartridge Alignment Protractor Cutout Note: Only 1 protractor is required for the cartridge alignment process. 3 cutouts have been provided for convenience.
- Page 24 This warranty does not cover the shipping cost, insurance, or any other incidental charges. Products shipped for warranty service must be pre-paid by the customer, and Fluance will cover the cost to ship the repaired or replaced product back to the customer.
- Page 25 Fluance.com...
