  • Page 1 Wash Center® D1 Base User Manual serial # D1B–01 00001 Art. no EN31053 Granuldisk AB retains the right to make technical changes to the products. No responsibility is taken for any printing errors. www.granuldisk.com Tel. +46 40 671 50 60...

  • Page 3: Table Of Contents

    Contents EC DECLARATION OF CONFORMITY FOR MACHINERY 1 General description and safety 1.1 Notes and warnings 1.2 Technical data D1 Base 1.3 SIMpel — easy access to information 2 Operating 2.1 Control panel 2.2 Start and operation 2.3 Loading washware 3 Daily cleaning 4 Error icons and troubleshooting 4.1 Error icons in the display...

  • Page 5: Ec Declaration Of Conformity For Machinery

    EC DECLARATION OF CONFORMITY FOR MACHINERY Original Directive 2006/42/EC, Annex II 1A Manufacturer (and where appropriate his authorised representative): Representative: Granuldisk Address: Jägershillsgatan 13, 213 75 Malmö Hereby declares that Type of machinery: Ware washing machine for com- mercial kitchens No.

  • Page 7: General Description And Safety

    This manual is your guide for the correct use of Lean Wash Center® D1 Base. Granuldisk recommends that you study the manual thor- oughly to be sure that Lean Wash Center® D1 Base is in- stalled and used correctly and safely.
  • Page 8 1 General description and safety 1.1 Notes and warnings WARNING The following fundamental rules must be observed when using this appliance: • Never use the appliance with bare feet. • Do not put your bare hands into water containing detergent. Wash the hands thoroughly under running water straightaway if by accident this happens.

  • Page 9: Technical Data D1 Base

    1.2 Technical data D1 Base 1 General description and safety Technical data D1 Base General Design Undercounter dishwashing machine Polypropylene dishware washing basket - Polypropylene glassware washing basket. External dimensions External dimensions H x W x D (Door open) 844 mm (+11 mm) x 600 mm x 633 mm (1072 mm) Weight (empty / filled) 54 / 74 kg (Standard machine)
  • Page 10 1 General description and safety 1.2 Technical data D1 Base Frequency 50 Hz Maximum output 5,1 kW 0,55 kW Dishwashing pump Rinse pump 0,18 kW Heater wash tank* 2 kW Heater rinse tank* 4,5 kW Enclosure rating IPX5**** WATER CONNECTION Total hardness: <...
  • Page 11 1.2 Technical data D1 Base 1 General description and safety **** Do not clean the machine with high-pressure water. Rev. 2023-05...

  • Page 12: Simpel - Easy Access To Information

    1.3 SIMpel — easy access to 1 General description and safety information SIMpel — easy access to information To make it easier for the operator to find information and how to use the unit there is a QR-code on Lean Wash Center® D1 Base. The sticker is placed in the upper right corner of the unit.
  • Page 13 1.3 SIMpel — easy access to 1 General description and safety information 2 2 When you scan the QR code, you enter the following menu. (Note that the interface may vary depending on the de- vice used). See Fig. 2 Menu Fig.
  • Page 14 1.3 SIMpel — easy access to 1 General description and safety information 5. ABOUT GRANULDISK Link to Granuldisk.com 6. CONTACT INFORMATION Contact information to service partner Rev. 2023-05...

  • Page 15: Operating

    Operating Control panel 1. ON/OFF 2. P — choose program 3. CONFIRM — start the machine Rev. 2023-05...

  • Page 16: Start And Operation

    2 Operating 2.2 Start and operation 2.2 Start and operation Insert the overflow pipe, if removed from the tank. Make sure it is posi- tioned correctly. 2 2 Switch on the main electrical switch. The machine goes in OFF mode. 3 3 Start Lean Wash Center®...
  • Page 17 2.2 Start and operation 2 Operating The wash program is ready when END flashes in the display for a couple of seconds and the CONFIRM button turns green again. NOTE As long as correct temperature in the wash tank is not achieved, thermostop for wash tank will be activated.
  • Page 18 2 Operating 2.2 Start and operation Fig. 7 Economy mode Rev. 2023-05...

  • Page 19: Loading Washware

    2.3 Loading washware 2 Operating 2.3 Loading washware Dishware basket for dinner or soup plates (28148) Capacity: 18 dinner or 12 soup plates ø 240 mm. See Fig. 8 Dishware basket Fig. 8 Dishware basket Glassware basket for glasses and mugs (28149) Capacity: 25 glasses/mugs ø...

  • Page 21: Daily Cleaning

    Daily cleaning Push ON/OFF button to empty the Lean Wash Center® D1 Base. If option without drain pump: remove the overflow pipe. See Fig. 10 Remove overflow pipe If option with drain pump: the machines starts to drain automatically. Fig. 10 Remove overflow pipe 2 2 Take out the tank grid (A) and remove the filter (B).
  • Page 22 3 Daily cleaning 3 3 Take out the filter at the bot- tom of the tank See Fig. 13 Remove filter If option drain pump, the filter looks differently. See Fig. 14 Filter when option drain pump Fig. 13 Remove filter Fig.
  • Page 23 3 Daily cleaning 8 8 Leave the door open to let air circulate. NOTE Do not leave Lean Wash Center® D1 Base switched on if it is not used for some time or if the operator is not able to monitor it directly.

  • Page 25: Error Icons And Troubleshooting

    Error icons and troubleshooting Error icons in the display ERROR ICONS MEANING SOLUTION Pressing start resets Failed filling wash/ the time hence re- rinse tank charging peating the load. time exceeded. Check the mains water inlet. Check that the over- flow pipe is in place (for machines without drain pump).

  • Page 26: Troubleshooting

    4 Error icons and troubleshooting 4.2 Troubleshooting 4.2 Troubleshooting PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The mains light fails to Mains are not Check the electric switch on. connected. mains connection. The wash cycle fails to The machine has not Wait until the CONFIRM start.
  • Page 27 4.2 Troubleshooting 4 Error icons and troubleshooting The glasses and cut- The rinse aid is unsuit- Check the rinse aid lery are stained. able or is not dis- container and if it is pensed correctly. suitable for the type of mains water.

  • Page 29: Notes

    Notes Rev. 2023-05...

This manual is also suitable for:

D1b-01 00001
