- Page 1 PXI-8231...
- Page 2 Note Visit and enter for more information about ni.com/info rdvisionvista National Instruments interface device compatibility with Windows Vista. ❑ NI Vision Acquisition Software 8.2.1 or later, which includes the NI-IMAQdx driver software ❑ Optional software for developing applications: – NI Vision Builder for Automated Inspection –...
- Page 3 Remove power from signal lines before connection to or disconnection from the device. Caution National Instruments measurement products may be classified as either Measurement Category I or II. Operate products at or below the Measurement Category level specified in the hardware specifications.
- Page 4 Never touch the exposed pins of connectors. Remove the device from the package and inspect it for loose components or any other signs of damage. Notify National Instruments if the device appears damaged in any way. Do not install a damaged device in the computer.
- Page 5 Insert the NI PXI-8231 into the selected slot. Use the injector/ejector handle to fully inject the device into place. Secure the front panel of the NI PXI-8231 to the front panel mounting rails of the PXI or CompactPCI chassis. Connect the Ethernet cable to your camera. Refer to your camera manufacturer documentation for specific instructions about how to connect the cable to your camera.
- Page 6 10. Connect the Ethernet cable to the RJ-45 connector on the NI PCIe-8231 front panel. 11. Plug in and power on the computer. The NI PCIe-8231 is now installed and the camera is connected. © National Instruments Corporation Getting Started with the NI PXI/PCIe-8231...
- Page 7 After you have installed the NI 8231 and powered on your computer, Windows will recognize the device and assign resources to it. Use Measurement & Automation Explorer (MAX), the National Instruments configuration utility, to configure a GigE Vision compliant camera, connected to the NI 8231, for acquisition.
- Page 8 IV. Approved at altitudes up to 2,000 m. Storage Environment Ambient temperature range NI PXI-8231 ..........–20 °C to 70 °C NI PCIe-8231..........–40 °C to 70 °C Relative humidity NI PXI-8231 ..........5% to 95%, noncondensing NI PCIe-8231..........50% to 85%, noncondensing...
- Page 9 Waste Electrical and Electronic Equipment (WEEE) EU Customers At the end of their life cycle, all products must be sent to a WEEE recycling center. For more information about WEEE recycling centers and National Instruments WEEE initiatives, visit ni.com/environment/weee.htm Getting Started with the NI PXI/PCIe-8231...
- Page 10 National Instruments corporate headquarters is located at 11500 North Mopac Expressway, Austin, Texas, 78759-3504. National Instruments also has offices located around the world to help address your support needs. For telephone support in the United States, create your service request at and follow the calling instructions or dial 512 795 8248.
- Page 11 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt...
