- Page 1 LSI® SAS 9300-16e PCI Express® to 12Gb/s Serial Attached SCSI (SAS) Host Bus Adapter User Guide Version 2.0 May 2013 DB15-000982-01...
- Page 2 LSI Corporation reserves the right to make changes to the product(s) or information disclosed herein at any time without notice. LSI Corporation does not assume any responsibility or liability arising out of the application or use of any product or service described herein, except as expressly agreed to in writing by LSI Corporation; nor does the purchase, lease, or use of a product or service from LSI Corporation convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Corporation or of third parties.
-
Page 3: Table Of Contents
LSI SAS 9300-16e PCI Express to 12Gb/s SAS Host Bus Adapter User Guide Table of Contents May 2013 Table of Contents 1 Overview ..........................4 2 Features . -
Page 4: Overview
Functional Descriptions PCI Express Interface The LSI SAS 9300-16e HBA uses two LSI SAS 3008 controller chips and one PCI Express switch to provide high-bandwidth interconnection ability. PCIe is a high-speed standard local bus for point-to-point interfacing of I/O components to the processor and the memory subsystems in high-end computers and servers. -
Page 5: Operating System Support
Physical Characteristics The LSI 12Gb/s SAS HBA is a 6.6-in. × 4.4-in board. The component height on the top and bottom of the LSI 12Gb/s SAS HBA is in accordance with the PCIe specification. The following figure shows the HBA board layout. -
Page 6: Electrical Characteristics
J6, J7 – SFF-8644 mini-SAS HD, external, right-angle connectors Electrical Characteristics The maximum power requirements for the LSI SAS 9300-16e HBA under normal operation are as follows: PCIe 12.0 V = 2.35 A PCIe 3.3 V = 0.13 A ... -
Page 7: Lsi 12Gb/S Sas Hba Certifications And Safety Characteristics
LSI 12Gb/s SAS HBA Certifications and Safety Characteristics All LSI 12Gb/s SAS HBAs meet or exceed the requirements of UL flammability rating 94V-0. Each bare board is marked with the supplier’s name or trademark, type, and UL flammability rating. Because these boards are installed in a PCIe bus slot, all voltages are less than the SELV 42.4-V limit. -
Page 8: Technical Support
Replace the cover of the chassis. Connect SAS cables between the HBA and the SAS enclosure that contains SATA or SAS devices. The LSI 12Gb/s SAS HBA has four SFF-8644, external x4 mini-SAS HD connectors. Use a cable with an external mini-SAS HD connector (SFF-8644) on one end (to connect to the HBA) and the appropriate connector to attach to the enclosure that contains SAS or SATA devices on the other end.
