USER'S
GUIDE
LSI22915A
PCI to Dual Channel
Ultra160 SCSI
Host Adapter
S e p t e m b e r 2 0 0 3
Version 1.3
®
DB15-000155-03

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LSI22915A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LSI LSI22915A

Summary of Contents for LSI LSI22915A

  • Page 1 USER’S GUIDE LSI22915A PCI to Dual Channel Ultra160 SCSI Host Adapter S e p t e m b e r 2 0 0 3 Version 1.3 ® DB15-000155-03...
  • Page 2 Consult the dealer or an experienced radio/TV technician for help. Shielded cables for SCSI connection external to the cabinet are used in the compliance testing of this Product. LSI Logic is not responsible for any radio or television interference caused by unauthorized modification of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by LSI Logic.
  • Page 3 LSI Logic; nor does the purchase or use of a product from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or third parties.
  • Page 4 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 5 Preface This book is the primary reference and user’s guide for the LSI22915A PCI to Dual Channel Ultra160 SCSI Host Adapter. It lists features and technical specifications of the LSI22915A and has detailed instructions on installing the board and connecting SCSI devices to it.
  • Page 6 Updated to reflect new mechanical drawing, name change, and features. 9/2003 Corrections made to names and descriptions of some jumpers. Some unneeded technical information removed. General editing and cleanup. Preface Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 7: Table Of Contents

    Connecting External SCSI Devices 2-12 2.2.6 Terminating the SCSI Bus 2-15 2.2.7 Setting SCSI IDs 2-20 Completing the Installation 2-22 LSI22915A PCI to Dual Channel Ultra160 SCSI Host Adapter User’s Guide Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 8 Thermal and Atmospheric Characteristics 3.1.4 Safety Characteristics Operational Environment 3.2.1 PCI Interface 3.2.2 SCSI Interface 3.2.3 LED Interface Appendix A Glossary of Terms and Abbreviations Customer Feedback viii Contents Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 9 2-14 2.12 Autotermination Jumpers 2-15 2.13 Internal SCSI Device Termination 2-17 2.14 External SCSI Device Termination 2-18 2.15 Internal and External SCSI Device Termination 2-19 LSI22915A Board Layout Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 10 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 11 Tables SCSI ID Record 2-21 Maximum Power Requirements LED Connector Pinout Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 12 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 13: Chapter 1 Describing The Lsi22915A

    The LSI22915A has two 16-bit Low Voltage Differential (LVD) and Single-Ended (SE) Ultra160 SCSI channels that connect to the PCI local bus on your computer. The LSI22915A is tailored to systems that require on-board BIOS support. When you install the LSI22915A in your PCI system, you can connect up to 15 SCSI disk drives and other SCSI devices to each of its two SCSI channels.

  • Page 14: Features

    ™ SDMS 4.0 User’s Guide, contains product information and installation instructions to help you gain the full benefits of the LSI22915A. Features This section provides a high-level overview of the PCI interface, the SCSI interfaces, and other board characteristics of the LSI22915A.

  • Page 15: Board Characteristics

    Two 68-pin high density (HD) connectors, one for each internal channel • ISA/EISA bracket 1.2.4 LED Interface The LSI22915A LED interface is a four-wire arrangement that allows you to connect an LED harness to the board. The connector on the LSI22915A is HDR2 for both channels. Table 3.2 page 3-4 lists the signal names and pin numbers for this LED interface.

  • Page 16: Double Transition (Dt) Clocking

    LSI53C1010 PCI to Dual Channel Ultra160 SCSI controller. Fully integrated in the SDMS software solution, SureLINK technology provides Domain Validation at boot time, as well as throughout system operation. Describing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 17: Lvdlink™ Technology Benefits

    ™ LVDlink Technology Benefits The LSI22915A supports LVD, a signaling technology that increases the reliability of SCSI data transfers over longer distances than those supported by SE SCSI. The low current output of LVD allows the I/O transceivers to be integrated directly onto the chip. LVDlink technology lowers the amplitude of noise reflections and allows higher transmission frequencies.
  • Page 18 Describing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 19: Chapter 2 Installing The Lsi22915A

    Step 1. Ground yourself before handling the host adapter board. LSI Logic recommends using a static ground strap. Step 2. Remove the LSI22915A from the packaging and check that it is not damaged. Figure 2.1 shows an example of this host adapter board.

  • Page 20: Hardware Connections For The Lsi22915A

    Step 4. Open your PC cabinet. Step 5. Locate the PCI slots in the PC. Step 6. Insert the LSI22915A board into the selected PCI slot. Step 7. Connect the internal and external SCSI devices. Step 8. Connect the LED cable to HDR2 on your SCSI host adapter, if you wish to connect the LED to the SCSI LED connector.

  • Page 21: Detailed Installation Procedure

    Handle plug-in boards by the edge; do not touch board components or gold connector contacts. LSI Logic recommends using a static ground strap. Step 2. Remove the LSI22915A from the packaging and check that it is not damaged. Figure 2.1 shows this host adapter.

  • Page 22: Inserting The Host Adapter

    Step 3. Secure the board with the bracket screw before connecting internal and external SCSI devices. Refer to Figure 2.2. Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 23: Inserting The Host Adapter

    Figure 2.2 Inserting the Host Adapter Bracket Screw 32-Bit Slot 64-Bit Slots Detailed Installation Procedure Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 24: Connecting Scsi Devices

    2.2.3 Connecting SCSI Devices All internal SCSI devices are connected to the LSI22915A with an unshielded, 68-conductor ribbon cable. One side of this cable is marked with a color to indicate the pin-1 side. The connectors on this cable are keyed to ensure proper pin-1 orientation.

  • Page 25: Connecting Internal Scsi Devices

    2.2.4 Connecting Internal SCSI Devices This section provides step-by-step instructions for connecting internal SCSI devices, such as disk drives, to the LSI22915A. If you only have external SCSI devices, skip to Section 2.2.5, “Connecting External SCSI Devices,” on page 2-12.

  • Page 26: Connecting Scsi Ribbon Cable To Internal Scsi Device

    If you have only one internal device, skip to page 2-11. Step 3. Plug the cable into each additional internal SCSI device as shown in Figure 2.6. Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 27: Connecting Additional Internal Scsi Devices

    Connecting Additional Internal SCSI Devices Figure 2.7 shows an example of how to connect multiple internal SCSI devices. Make sure to match pin 1 on all the connections. Detailed Installation Procedure Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 28: Connecting Multiple Internal Scsi Devices

    Figure 2.7 Connecting Multiple Internal SCSI Devices 2-10 Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 29: Scsi Led Connector

    180 degrees on HDR2. If your connector has only two wires, refer to Table 3.2 page 3-4 for connector pinout information. Figure 2.8 SCSI LED Connector Cable Connector HDR2 Detailed Installation Procedure 2-11 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 30: Connecting External Scsi Devices

    Step 2. Plug the 68-pin connector on the other end of the shielded external SCSI cable into the SCSI connector on your external SCSI device. Figure 2.10 shows how to make this connection. 2-12 Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 31: Connecting External Scsi Cable To External

    Step 3. Chain multiple SCSI devices together with shielded external SCSI cables. Figure 2.11 shows an example of how to connect external SCSI devices. Detailed Installation Procedure 2-13 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 32 Figure 2.11 Chaining Multiple External SCSI Devices Together 2-14 Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 33: Terminating The Scsi Bus

    The LSI22915A automatically enables its own termination when it is at the end of the bus. (In other words, the LSI22915A terminates itself if you connect only internal SCSI devices or only external SCSI devices.) LVD SCSI devices are usually terminated with external terminators, but sometimes termination is set with jumpers or with a switch on the device.
  • Page 34 The LSI22915A automatically controls SCSI bus termination for these three different bus configurations: • Section 2.2.6.1, “Internal SCSI Devices Only” • Section 2.2.6.2, “External SCSI Devices Only” • Section 2.2.6.3, “Internal and External SCSI Devices” 2.2.6.1 Internal SCSI Devices Only...

  • Page 35: Internal Scsi Device Termination

    Termination on the host adapter is automatically enabled. Figure 2.14 shows how termination is set for a configuration with external SCSI devices only. Detailed Installation Procedure 2-17 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 36: External Scsi Device Termination

    SCSI bus and disable termination on all other devices. Termination on the host adapter is automatically disabled. Figure 2.15 shows how termination is set for a configuration with internal and external devices. 2-18 Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 37: Internal And External Scsi Device Termination

    SCSI Bus Automatically Unterminated Termination Disabled on Devices in Middle of SCSI Bus Termination Enabled with Terminator on Last External Device on SCSI Bus Detailed Installation Procedure 2-19 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 38: Setting Scsi Ids

    Note: If the LSI22915A is connected to another host adapter or SCSI device that uses the same sensing method for automatic termination, you must override the termination for that channel by installing a jumper or by using software control. 2.2.7...
  • Page 39 Table 2.1 SCSI ID Record SCSI ID SCSI Channel A SCSI Channel B LSI22915A (default) LSI22915A (default) Detailed Installation Procedure 2-21 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 40: Completing The Installation

    4.0 User’s Guide (or to the guide for the software you plan to use) to load the driver software for your particular operating system and to change the configuration of your host adapter, if necessary. 2-22 Installing the LSI22915A Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 41: Chapter 3 Technical Specifications

    Section 3.2, “Operational Environment” Physical Environment This section discusses the physical, electrical, thermal and atmospheric, and safety characteristics of the LSI22915A. It should be noted that this board is compliant with electromagnetic standards set by the FCC. 3.1.1 Physical Characteristics The dimensions of the LSI22915A are approximately 4.2 by 8.4 inches...

  • Page 42: Electrical Characteristics

    At temperatures of at least 25 °C, a current of 4 A is sustained no longer than 30 seconds before the self-resetting TERMPWR short circuit protection device opens. Technical Specifications Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 43: Thermal And Atmospheric Characteristics

    PCI bus slot, all voltages are below the SELV 42.4 V limit. Operational Environment The LSI22915A is designed for use in PCI computer systems with an ISA/EISA bracket type. The SDMS software operates the board, but the board design does not prevent the use of other software.

  • Page 44: Scsi Interface

    Signal Name A_LED+ A_LED− B_LED− B_LED+ Each SCSI channel of the LSI22915A has four activity LEDs that indicate the operating state of the channel: • SCSI Activity – Green LED, left edge of board • TERMPWR Shorted – Yellow LED, left edge of board •...

  • Page 45: Appendix A Glossary Of Terms And Abbreviations

    CRC is used on the Double Transition (DT) Data-In and DT Data-Out phases. LSI22915A PCI to Dual Channel Ultra160 SCSI Host Adapter User’s Guide A-1 Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 46 PCs. ISA allows devices to send and receive data up to 16 bits at a time. Kbyte Kilobyte. A measure of computer storage equal to 1024 bytes. Glossary of Terms and Abbreviations Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.

  • Page 47: Scsi Device

    Wide SCSI). The host adapter is normally assigned the highest ID (7 or 15), giving it priority to control the bus. SDMS Storage Device Management System. An LSI Logic software product that manages SCSI system I/O. Version 1.3 Copyright © 2000–2003 by LSI Logic Corporation. All rights reserved.
  • Page 48 Synchronous data transfers are negotiated between the SCSI host adapter and each SCSI device. TolerANT A technology developed and used by LSI Logic to improve data integrity, data transfer rates, and noise immunity, through the use of active negation and input signal filtering.
