REVELL Ultima Voice Unpacking Instructions

Thank you for purchasing the Ultima Voice
Follow the instructions below to unpack the pedestal.
UNPACKING
Step 1: Place the packing carton upside-down
and fully open the bottom flaps.
Step 2: Without allowing the flaps to close,
invert the packing carton. Lift the packing
carton off of the pedestal, leaving the packing
material in place.
Step 3: To complete unpacking the pedestal,
r e m o v e t h e U n p a c k i n g & I n s t a l l a t i o n
Instructions sheet from the end pad and refer
to the "Unpacking" instructions.
Step 4: Remove the Top End Pad from the top of the pedestal.
Step 5: Lift the pedestal from the Bottom End Pad. Put both end
pads aside.
Step 6: Remove the cloth bag. Handle carefully to ensure that the
pedestal isn't scuffed or bumped.
You are now ready to begin the Pedestal installation procedure.
Turn this sheet over to begin.
NOTE: Save all original packaging materials.
Harman Specialty Group
3 Oak Park Drive
Bedford, MA 01730-1413
USA
Revel Part No. 353273-001 | Rev 0 | 03/07
®
Revel Ultima Voice

Unpacking Instructions

™
2 Pedestal for your Revel
Tel 781-280-0300 Customer Service
Fax 781-280-0490 Tel 781-280-0300
www.revelspeakers.com Fax 781-280-0495 (Sales)
Fax 781-280-0499 (Service)
™
2 Pedestal
® ™
Ultima Voice 2 Loudspeaker.
Accessory
Bag
Top End
Pad
Protective Bag
Bottom End Pad
Pedestal
